INSTALLATION & OPERATING
Clean Air Freestanding Wood Fires
1.
This Kent freestanding wood fire must be installed by an approved installer, ideally
registered with the New Zealand Home Heating Association. Do not allow any
makeshift or compromising installation methods as this could result in a house fire.
This Kent freestanding wood fire must be installed according to these instructions.
2.
A Building Consent from the Local Authority must be obtained before installing
this wood fire, and we suggest that the Insurance Company covering building
insurance be advised of the installation.
3.
This Kent freestanding wood fire, when installed according to these instructions,
complies with the provisions of AS/NZS 2918-2001 "Installation of Domestic Solid Fuel
Burning Appliances".
4.
The clearances given in these instructions are necessary to prevent overheating
of nearby combustibles and drying out of the house structure. They may not be
reduced without authorisation.
5.
Important: Read all instructions carefully before starting installation. Failure to follow
these instructions could result in a fire hazard, and may void warranty.
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Important: the installer or seller must leave these instructions with the purchaser
INSTRUCTIONS
CONTENTS
General Information ........................ 1
Specifications ................................... 2
Installation ...................................... 4-6
Operation ....................................... 6-8
Maintenance .................................... 9
Replacement Parts ................... 10-11
Warranty .......................................... 12
GENERAL INFORMATION
Advertisement
Related Manuals for KENT Cardrona
Summary of Contents for KENT Cardrona
-
Page 1: Table Of Contents
Warranty .......... 12 GENERAL INFORMATION This Kent freestanding wood fire must be installed by an approved installer, ideally registered with the New Zealand Home Heating Association. Do not allow any makeshift or compromising installation methods as this could result in a house fire. -
Page 2: Specifications
Ruapehu KWF295-6965 0.54g/kg 191312 TABLE 1 * ECAN NO = Environment Canterbury authorisation number. RECOMMENDED FLUE KITS FOR KENT FREE STANDING WOOD FIRES Description Model No. Standard - 4.2m KWF298-7005 Tested to AS/NZS 2918, Appendix F, ARS report No;02/649 Energy Saver - 4.2m KWF298-7006 Tested to AS/NZS 2918, Appendix F, ARS report No;02/649... - Page 3 Kent single length stainless steel flue 150 x 1200mm KWF298-6022 Kent stainless steel flue reflector KWF298-6029 Kent stainless steel flue twin pack 150mm KWF298-6049 Kent black stainless steel flue twin pack 150 x 1200mm KWF298-6051 Kent floor penetration 200/250mm diameter KWF298-6053 Kent 360 degree flue pipe guard KWF298-6328...
-
Page 4: Installation
An insulating floor protector is not required for the Kent freestanding wood fire, but a single layer ash floor protector of non-combustible material must be used. The floor protector must extend under the appliance and not less than 300mm in front of the fuel-loading and ash removal openings. - Page 5 Where the flue terminates more than one full section above the roof penetration, it must be restrained with guy wires or bracing support bars for stability in high wind conditions. NOTE: The flue pipe shall extend not less than 4.6m above the top of the floor protector. The flue cowl must be at least 0.6m above the highest point of the roof, if within 3 metres of the ridge.
-
Page 6: Operation
Thank you for purchasing a Kent wood fire. Used and maintained correctly, it will provide you with many years of warmth in your home. Kent wood fires have been the main source of heating for many Kiwi homes, for over 40 years. - Page 7 NORMAL OPERATION ONCE THE FIRE IS ESTABLISHED The Kent wood fire requires fresh air for optimal burning, and this must come from outside the house. A normal house will allow enough air in through incidental openings to satisfy this. We recommend that a source of air be located near the wood fire for best performance.
- Page 8 FOR FIRST FIRE All Kent wood fires are finished in a high temperature quality stove paint. The paint has not been fully cured until it has been heated. If the fire is run too hot, too fast, the paint will burn off before it has had a chance to fully bond to the steel.
-
Page 9: Maintenance
RE-PAINTING All Kent wood fires are finished in high temperature paint. If marks and scratches occur, or the paint is damaged by over firing or aggressive cleaning agents the appliance can easily be touched up by using stove paint. Any rust or other stubborn marks that may appear can be cleaned up and removed with the help of a steel wool pad and hot soapy water, then repainted if necessary. -
Page 10: Replacement Parts
KWF299-6257 KWF299-6900 The air tube in your Kent wood fire is an important part of the appliance and helps ensure a clean, efficient and controllable burn. However, air tubes are a consumable item and are designed to be replaced as they are likely to degrade with use due to the exposure to the extreme heat of the fire. - Page 11 KWF299-7233 材料 版本号 更改描述 签名 年月日 KWF295-6965总 王从坦 设计 审核 The baffle in your Kent wood fire is an important part of the appliance and helps ensure a clean, 原图号/物料号 数量 比例 顶部隔热板接 技术要求： 日期 2018/10/16 日期 1、未注公差按GB/T1804-2000 m级执行； 1:10 efficient and controllable burn.
-
Page 12: Warranty
This warranty is for normal domestic use. Your Kent wood fire is warranted for up to 15 years, with the exception of the following parts; door glass, door and glass seals, fire bricks, flue, secondary air systems and baffle plates, which all have a 12 month (part only) warranty.
