Main Menu → Record Settings → Video Quality
o
Use the Arrow buttons to select the desired Record Quality. Select High,
Med or Standard.
Higher record qualities use lower compression, requiring more disk space.
Press the Enter button to confirm the selection and exit the menu.
Press the Menu button to exit the menu without making changes.
4.5 Main Menu → Display Settings
Use this menu to specify what status information will be displayed on
the primary monitor. Select On or Off, for the following items.
•
The current time and date.
•
The remaining amount of time before the hard disk runs
out of record space.
•
The time and date of the last alarm.
•
The Record or Playback Speed.
•
During Playback, the time and date the recording was
made.
Main Menu → Display Settings → Current Time / Date
o
To display the current Time and Date near the upper right hand corner of the primary monitor,
select ON. Use the Arrow buttons to select On or Off.
Press the Enter button to confirm the selection and exit the menu.
Press the Menu button to exit the menu without making changes.
Main Menu → Display Settings → Record Capacity
o
Select ON, to display the amount of time remaining before the hard disk runs out of record
space. The data is displayed near the upper left hand corner of the primary monitor. The unit
displays the Record Capacity with two measures of time, and switches automatically
depending on the amount of time remaining:
•
Days and Hours
•
Hours and Minutes
•
Minutes and Seconds
Use the Arrow buttons to select ON or OFF.
Press the Enter button to confirm the selection and exit the menu.
Press the Menu button to exit the menu without making changes.
Kalatel VDR
--OR—
--OR—
--OR—
4-6
Record Quality
Select Quality
High
Current Time / Date
Record Capacity
Last Alarm
Record Playback Speed
Playback Time / Date
0150-0255B
OFF
ON
OFF
ON
