TOPEX MobiLink ISDN2GSM User`s Manual
Outgoing calls
In this case calls coming from PABX junction through NT connector
of ISDN-2- GSM can be routed through one of the three directions:
GSM0, GSM1 and TE (which goes to the public ISDN network).
The routing is performed by the MobiLink ISDN-2- GSM unit.
Incoming to PABX from ISDN network
The calls from the public ISDN are transferred transparently
towards the PABX. For this, in the TE configuration window check
"PassThrough" options.
Incoming to PABX from GSM network
The calls from GSM network are treated according to the
specifications presented on paragraph "a".
5.2.4

MobiLink connected to PABX via TE only

The TE interface of the MobiLink is connected to the NT of a local
board of the PABX.
The NT interface of ISDN-2- GSM is not used in this case.
The PABX connects to the public ISDN via another TE junction.

Figure 5-4 MobiLink connected to NT local of PBX

34
