TOPEX MobiLink ISDN2GSM
Settings for configuration of the SIM cards
Description
Select "OFF" for "Dial again – Interval".
Select "OFF" for "Auto Answering"
Select "OFF" for "Call Waiting"
3.3.

Inserting the SIM cards

The ISDN 2 GSM interface needs SIM cards for the corresponding
GSM operators.
Each SIM card must be inserted in the corresponding slot of the
MobiLink ISDN 2 GSM unit. Depending upon the equipment model,
it may feature one or two GSM modules, hence one or two slots for
SIM cards.
The slots for SIM cards are located on
the upper right side of the MobiLink
case, under the LED indicators. To
insert/ remove the SIM, use the
removable tray (SIM holder) which is
activated by a small
pushbutton.

Figure 3-2 Location of SIM slots

Note:
To push the ejector button, because of its small size,
you may need to use a tool with a small, hard tip (keys,
pen, screwdriver or tweezers). Handle the SIM cards
with care!
WARNING!
Unplug the MobiLink unit from the main outlet before
insert or replace a SIM card!
For each of the SIM card, follow these steps:
User`s Manual
Option
If this option exists
required
required
yellow
14
