AL.1
AUTO SECURITY SYSTEM
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user's authority to operate
this device.
INSTALLATION GUIDE
FCC ID NOTICE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Soundstream AL.1
Summary of Contents for Soundstream AL.1
- Page 1 AL.1 AUTO SECURITY SYSTEM INSTALLATION GUIDE FCC ID NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 2: Program Switch
AL.1 INSTALL MANUAL POSITIVE PARK LIGHT OUTPUT (+15amp) WHITE: 16 Awg SYSTEM CHASSIS GROUND INPUT BLACK: 20 Awg CONSTANT 12 VOLT INPUT RED: 20 Awg OUTPUT TO ACTIVATE SIREN (+2amp) BROWN: 20 Awg OUTPUT FOR TRUNK RELEASE (-) RED/WHITE: 22 Awg... - Page 3 AL.1 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM WIRING 10 PIN CONNECTOR OUTPUT TO ACTIVATE SIREN (+2amp) BROWN OUTPUT FOR TRUNK RELEASE (-) RED/WHITE AUX 1 OUTPUT (-) WHT/BLUE STARTER DISABLE (-) WHEN ARMED ORANGE DOME LIGHT (-) WHEN DISARMED (30sec)
- Page 4 AL.1 SYSTEM WIRING INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 10 PIN CONNECTOR - DESCRIPTION Pin 1- Brown Wire- Siren Output (3amp Maximum) Connect this wire to the brown or red wire from the alarm siren. Pin 2- Red/White Wire- Trunk Release This output activates for 0.75 sec when the Trunk Button is held for 5 seconds.
-
Page 5: System Reset
AL.1 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SYSTEM WIRING 3 PIN KEYLESS CONNECTOR GREEN NEGATIVE OUTPUT FOR LOCK 12+ OUTPUT FOR DOOR LOCK MODULE NEGATIVE OUTPUT FOR UNLOCK BLUE SYSTEM RESET System Reset will set all program menu’s to the default factory setting. -
Page 6: Entering Program Mode
AL.1 SYSTEM RESET INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 3 PIN KEYLESS CONNECTOR This connector is used when installing the optional keyless entry feature. If the door lock type of the vehicle is not negative you may need to install a voltage inverter, relays or a door lock module to install this feature. -
Page 7: Program Mode
AL.1 INSTALL MANUAL SYSTEM PROGRAMMING - QUICK VIEW PROGRAM CHART ENTERING PROGRAM MODE 1 - Cycle the Ignition Key On/Off On/Off On (Leaving the key ON) 2 - Press and release the Program Switch 1 time. (The siren will chirp one time) -
Page 8: Programming Remote's
AL.1 TRANSMITTER PROGRAMMING INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 TRANSMITTER PROGRAMMING The system can lean up to 3 different transmitter codes. Each remote to be used MUST be programmed together during the same sequence. For security, when a new remote is programmed all previous remote’s are deleted. -
Page 9: Enter Shock Sensor Adjustment Mode
AL.1 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 SHOCK SENSOR SHOCK SENSOR ADJUSTMENTS 1 - ENTER SHOCK SENSOR ADJUSTMENT MODE Press and HOLD the Lock and Unlock buttons Hold both buttons until the siren chirps 3 times. *The system will Arm or Disarm via silent arming prior to 3 CHIRPS entering adjustment mode. - Page 10 AL.1 DIAGNOSTICS INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 ALARM STATUS / DIAGNOSTICS If the alarm system is triggered, the system will retain in memory the cause of the trigger. When disarming the alarm, the siren will chirp 3 times to indicate the alarm had been triggered.
