REV.6
AL.3
AUTO SECURITY SYSTEM
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user's authority to operate
this device.
USER'S OPERATION GUIDE
FCC ID NOTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tarantula AL.3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Soundstream Tarantula AL.3

Summary of Contents for Soundstream Tarantula AL.3

  • Page 1 REV.6 AL.3 AUTO SECURITY SYSTEM USER’S OPERATION GUIDE FCC ID NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user’s authority to operate this device.
  • Page 2 AL.3 OWNER'S MANUAL QUICK VIEW (2WAY REMOTE) BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH 1 SECOND ARM ALARM / LOCK DOOR’S 3 SECONDS ACTIVATE PANIC MODE PRESS THEN ACTIVATE CONSTANT LOCK RELEASE THEN OUTPUT PRESS & HOLD 1 SECOND DISARM ALARM / UNLOCK DOOR’S DRIVER’S DOOR PRIORITY 1 SECOND - 1 SECOND...
  • Page 3 AL.3 OWNER'S MANUAL REMOTE) BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH PRESS TOGETHER FLASH SILENT LOCK/ UNLOCK & FOR 1 SECOND ONLY PRESS TOGETHER AUX-2 OUTPUT & FOR 3 SECONDS PRESS TOGETHER & AUX-3 OUTPUT FOR 3 SECONDS PRESS TOGETHER TUNE ENTER CLOCK ADJUST MODE &...
  • Page 4 AL.3 OWNER'S MANUAL QUICK VIEW (1WAY REMOTE) BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH 1 SECOND ARM ALARM / LOCK DOOR’S 3 SECONDS ACTIVATE PANIC MODE PRESS THEN ACTIVATE CONSTANT LOCK RELEASE THEN OUTPUT PRESS & HOLD 1 SECOND DISARM ALARM / UNLOCK DOOR’S DRIVER’S DOOR PRIORITY 1 SECOND - 1 SECOND...
  • Page 5 AL.3 OWNER'S MANUAL BUTTON BUTTON CHIRP/ SYSTEM FUNCTION ICON DURATION FLASH PRESS TOGETHER AUX-2 OUTPUT & FOR 3 SECONDS PRESS TOGETHER & AUX-3 OUTPUT FOR 3 SECONDS LOCK THEN START TEMPORARY SHOCK WITHIN 3 SECONDS SENSOR BYPASS...
  • Page 6 AL.3 OWNER'S MANUAL LOCK/ ARM ALARM Press and release the Lock Button to lock the vehicle’s doors (if door locks are connected). The park lights will flash once and the siren/horn will honk/chirp once. The LED’s on the antenna will begin to flash (Programmable). The system will arm then monitor the vehicle’s doors, hood and shock sensor.
  • Page 7 AL.3 OWNER'S MANUAL AUXILIARY OUTPUTS The auxiliary outputs can be used to control options such as power windows, sun roofs, power lift gates, etc. (Some options will require additional parts and/or labour). AUXILIARY 1 OUTPUT Press and hold the Star Button for 3 to 5 seconds to activate the auxiliary 1 output. When activated the park lights will flash twice, the siren/horn will honk/chirp twice, the doors will unlock then the auxiliary will activate.

  • Page 8: Transmitter Learning

    AL.3 OWNER'S MANUAL TRANSMITTER TRANSMITTER LEARNING The system can lean up to 4 different remote transmitter codes. Each remote to be used MUST be programmed together during the same sequence. For security, when a new remote is programmed all previous remote’s that are not reprogrammed at this time will be deleted. 1- Cycle the ignition key ON-OFF-ON-ON.
  • Page 9 AL.3 OWNER'S MANUAL Clock Adjustment The clock must be set when the remote battery is removed or replaced. Follow the steps below to set or adjust the clock. Enter Clock Adjustment Mode, 12:45 1- Press and Hold the Lock and # Buttons for 3-5 seconds. 2- The remote will play the Program tune.

  • Page 10: Remote Programmable Features

    AL.3 OWNER'S MANUAL REMOTE PROGRAMMABLE FEATURES This feature allows the user to Program certain system features using the remote transmitter. Enter Program Mode, 12:15 1- Press and Hold the # Button for 3-5 seconds. 2- The remote will play the Program tune. 3- The PROGRAM icon will turn on and start to flash.
  • Page 11 AL.3 OWNER'S MANUAL LCD TRANSMITTER 1- Select Car 1 or Car 2 Operation. 1:15 1- Press and release the Lock Button to select the 1 icon. 2- Press and release the Unlock Button for CAR-1 (Default). 3- Press and release the Trunk Button for CAR-2. 4- Press and release the # Button to exit or Lock to continue to the next programmable setting.
  • Page 12 AL.3 OWNER'S MANUAL LCD TRANSMITTER ALARM PAGER If the alarm is triggered the remote will begin to beep on and off (Vibrate in Vibration Mode) and the LCD screen with display the alarm trigger. The PAGER icon must be on for the remote to receive and display alarm triggers.

  • Page 13: Battery Replacement

    AL.3 OWNER'S MANUAL BATTERY REPLACEMENT If you notice decreased range while using your remote transmitter, it is possible that your transmitter battery needs to be replaced. To replace your battery follow the steps below. 1-WAY REMOTE TRANSMITTERS Remove the small Phillips screw on the back side of the remote then gently pull the remote transmitter apart.

  • Page 14: Disarming Anti Car Jack Feature

    AL.3 OWNER'S MANUAL ANTI CAR JACK MODE ACTIVATING ANTI CAR JACK MODE This feature requires that the user must be fully aware of the operation of this feature. If the system goes into full alarm the remote’s will no longer function until the Anti Car Jack Feature is disabled.

  • Page 15: Additional Led Functions

    AL.3 OWNER'S MANUAL ALET MODE / EMERGENCY OVERRIDE This feature will disable or re-enable the alarm without the use of the remote transmitter. This feature will work when alarm in either an armed, disarmed or triggered state. When the system's override had been activated, door lock and trunk features will still be operational however the alarm will be deactivated.
  • Page 16 LED FLASHES OUTPUT DIAGNOSTICS LOCK OUTPUT OVERLOAD UNLOCK OUTPUT OVERLOAD TRUNK OUTPUT OVERLOAD STARTER DISABLE OVERLOAD NOT USED AUX 5 OUTPUT OVERLOAD 2ND UNLOCK OUTPUT OVERLOAD SOUNDSTREAM CAR ALARMS CAR SECURITY SYSTEM...
