Telex LT-1000 Operating Instructions

LT-1000 SPECIFICATIONS

Radiated Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 mW Typical
Standard Lavalier Microphone . . . . . ELM-22 Omni-Directional Condenser
TA4F Connector Wiring . . . . . . . . . . . . . . . . P in 1: Ground; Pin 2 Mic Input;
Audio Gain Adjustment Range . . . . . . . . . . . . . . . . . . . . . . .40 dB WT-500
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . .9 Volt Alkaline Battery
Battery Life . . . . . . . . . . . . . . . . . . . . .>8 hours with 9-Volt Alkaline Typical
Antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Flexible external 1/4 wave
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 3.8 in. H x 2.38 in. W x 0.92 in. D

ACCESSORIES and PARTS

Premium Omnidirectional Lapel Microphone
Unidirectional Lapel Microphone
Premium Lapel
Unidirectional Microphone
Presenter's Headworn Microphone
Singer's Headworn Microphone
Bodypack Pouch
Beltclip Kit
TELEX COMMUNICATIONS, INC. 12000 Portland Ave. So., Minneapolis, MN 55420, U.S.A.
PN 803972
Pin3: +5V bias; Pin 4: +5V bias
through a 3k Ω resistor
96.5 mm H x 60.5 mm W x 23.4 mm D
Model No. Order No.
ELM-22 70925006
UML21 ULM21
ELM-33 70926001
HM2 HM2
HM7 HM7
WP-1000 879553
WP-1000 879518-1
Made in U.S.A.
Telex

Operating Instructions

LT-1000
BODY PACK TRANSMITTER
FOR USE WITH
ENG-100
DEC 2003
®
