Summary of Contents for Telex PST-170
-
Page 1: Operating Instructions
Telex Operating Instructions elex Personal Listening Systems PST-170 PST-170 17 Channel Synthesized Transmitter... -
Page 2: Channel Assignment
PST-170 SPECIFICATIONS Number of Channels · · · · · · · · · · · · · 17 User Selectable Channels Power Output · · · · · · · · · · · · · 80,000 uV/M at 3 meters, maximum Antenna ·... - Page 3 8 hours of operation from alkaline batteries and 4 hours on nickel-cadmium batteries. Charge Pins are provided on the bottom of the unit that fit Telex drop in chargers. CAUTION: Do not attempt to recharge alkaline batteries as this may result in personal injury.
- Page 4 Transmitter Channel The PST-170 Transmitter may be set to any one of 17 channels. Two Transmitters cannot operate on the same channel un- less separated by 300 feet (91 m) or more (which is the aver- age maximum operating range). If two transmitters are...
- Page 5 If the interfer- ence is weak on all channels, this is probably acceptable since the PST-170 will cover the interference and is unlikely to interfere with other users. Multiple Channel Systems re- quire other considerations but each channel should be...
- Page 6 Place the microphone about 10 to 12 inches below the mouth of the user. Transmitter Operation Turn on the transmitter with the toggle switch on top of the PST-170. LCD Display Channel Display A through Q, low battery indicator and input level Lock Indicator (see Change Lock Out)
- Page 7 Channel Selection and Input Adjustment Turn the receiver on and plug a microphone into the mic jack. A channel letter will show in the display. Press the set button once and the Channel indicator will flash. Press the button and the Channel will cycle up. Match the channel to the receivers being used (SR-50, SR-100, SR-400 or check frequency chart to match other brands).
- Page 8 Telex Model SR-400 receiver. The E.D.R. mode must be selected on both the transmitter and receiver to be effec- tive. To engage the E.D.R. function turn the PST-170 off with the toggle switch. Press and hold the SET button while you turn the PST-170 back on.
- Page 9 Low Battery Indication When there is approximately 10% of the battery life left, a bat- tery symbol will flash alternately with the Channel letter in the LCD display. When there is only 5% battery life left, the battery symbol will constantly flash in the display.
-
Page 10: Fcc Information
ACCESSORIES Description OLM-10 microphone (supplied with PST-170) ..OLM10 ELM-22 Micro Mini lapel microphone ....70925-001 RE92Tx Unidirectional lapel microphone ... 301456000 SCHS-745 headworn microphone . -
Page 11: Warranty Information
Material 36 months, workmanship 36 months. Micro- phones, earphones, neckloops, cables & connectors are warranted for ninety days. Telex will, at its option, repair or replace free of charge such defective products subject to the following conditions: Delivery of the product or parts postage prepaid to the Telex dealer, authorized ser- vice facility or factory. - Page 13 TELEX COMMUNICATIONS, INC. 12000 Portland Ave. South, Burnsville, MN 55337 PN 38110370 June 2004 Made in U.S.A.
