Telex HTV Owner's Manual And Operating Instructions

Vhf transmitter

TELEX

Owners Manual/Operating Instructions

Telex/Electro-Voice (Ev) Model HTV VHF Transmitter

General......

The Telex/Ev HTV is a Hand Held Transmitter operating within the VHF

FCC Part 74 frequency range. ( 174.0 to 216.0 MHz )

The transmitter is especially suited for use wherever a small, reliable hand

held wireless microphone is required. Versions are available with optional

microphone capsules.

Please note that each transmitter requires a matching receiver on the same

operating frequency. Standard "off the shelf" frequencies are available. Please see

the Electro-Voice Price List for information.

The Telex Ev HTV Series features single channel crystal controlled units for the

ultimate stability and clarity as well as economy.

Before setting up the transmitter, it is necessary to set up the receiver or at least

check the receiver operation if the receiver has been installed previously.

Place the receiver in an area with the antennas in clear view of the transmitter

operating area. Connect the receiver audio output to the audio input of the mixer,

amplifier or other device. Turn the input to these items down at this point.

Apply power to the receiver. Note that there should be no "Carrier" or TX light on

at the receiver at this time. If there is a light on, this indicates that other users

nearby may be using the frequency or that RF interference is present on the

frequency.

Table of Contents

Do you have a question about the HTV and is the answer not in the manual?

Page 1 Please note that each transmitter requires a matching receiver on the same operating frequency. Standard “off the shelf” frequencies are available. Please see the Electro-Voice Price List for information. The Telex Ev HTV Series features single channel crystal controlled units for the ultimate stability and clarity as well as economy. SETUP: Before setting up the transmitter, it is necessary to set up the receiver or at least check the receiver operation if the receiver has been installed previously.
Page 2 FCC REGULATIONS The Telex/Ev Model HTV is Type Accepted under United States Federal Communications Part 74. Licensing of Telex equipment is the users responsibility and licensibility depends upon the users classification and the frequency selected.
