- Page 1 User Manual MODEL: HPI 110...
-
Page 2: Table Of Contents
Contents Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General Description . -
Page 3: Safety Precautions
HPI110 User Manual Safety Precautions • Be sure to read the instructions in this section carefully before use. • Make sure you observe the instructions in this manual as the conventions of safety symbols and messages are very important. • We also recommend you keep this instruction manual handy for future reference. Safety Symbol and Message Conventions Safety symbols described below are used in this manual to prevent bodily injury and property damage which could result from mishandling. -
Page 4: When Installing The Unit
HPI110 User Manual WARNING When Installing the Unit When the Unit is in Use • Do not expose the unit to rain or an • Turn down the amplifier before switching environment where it may be exposed to on the amplifier. If there is no sound, water or other liquids, as doing so may check the speaker connections. -
Page 5: General Description
The high efficiency 10” neodymium magnet mid-bass transducer has been designed to function in a relatively large volume enclosure The HPI 110 is a full frequency range to maximize low frequency output. The cone multi-purpose 2-way passive speaker system geometry and driver dynamic parametersare... -
Page 6: Getting The Best From Your Hpi110
SIGNA L - HIGH PASS -B 35Hz 80Hz LOW PASS -B LIMITER GROUND 80Hz 110Hz LIFT GROUND OUTPUT B DESIGNED BY QUEST ENGINEERING,AUSTRALIA ~ 220 240V 10A 50/60Hz LINK B INPU T B Recommended HPI110 Amplifier Configuration User Manual HPI Series HPI110... -
Page 7: Speaker Cables
HPI110 User Manual Speaker cables When positioning the speaker system on a stage, make sure the HF horn at the top of Speaker cable needs to be as heavy gauge the speaker box is above the heads of the as conveniently possible for low-loss results. audience. -
Page 8: Flying The Hpi110
HPI110 User Manual Flying the HPI110 The HPI 110 can be flown in a permanent Rotating the Horn Flare installation by attaching the designed flying The asymmetrical horn flare can be rotated hardware. The HPI-110 can be wall mounted through three separate planes of dispersion... - Page 9 HPI110 User Manual HPI 110 Wave Guide Examples 30˚ 45˚ HPI110 Vertical Side HPI110 Vertical Front 3 0 ˚ 45˚ HPI110 Horizontal Front HPI110 Horizontal Side HPI Series User Manual HPI110...
-
Page 10: Hpi110 Specifications
HPI110 User Manual HPI110 Specifications Typical Frequency Reponse Frequency (Hz) HPI 110 - Frequency Response - 2.83V/1m Technical Specifications Power Handling 600W RMS Frequency Response 60-18kHz (+/-3dB) Sensitivity 95dB @ 1kHz Maximum SPL @ 1m 130dB Impedance 8 ohms Connections and Wiring... -
