- Page 1 User Manual MODEL: QM 700...
-
Page 2: Table Of Contents
Functional Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Getting The Best From Your QM700 . . . . . . . . . . . . . . . 4 Connections . -
Page 3: Safety Precautions
QM700 User Manual Safety Precautions • Be sure to read the instructions in this section carefully before use . • Make sure you observe the instructions in this manual as the conventions of safety symbols and messages are very important . -
Page 4: When Installing The Unit
QM700 User Manual WARNING When Installing the Unit When the Unit is in Use • Do not expose the unit to rain or an • Turn down the amplifier before switching environment where it may be exposed to on the amplifier . If there is no sound, water or other liquids, as doing so may check the speaker connections . -
Page 5: General Description
The QM700 is available as mirrored pairs which the WB700 wall bracket . is a great aid for minimising interferences effect when the QM700 is used as a large stage QM Range Accessories monitor . (See section on Fold-back monitor Two optional accessories are available for the technique) . -
Page 6: Getting The Best From Your Qm700
8Ω load or up to 1,600W RMS into a 4 ohm The connector input is wired pin 1+ and pin 1- . load . A suitable partner to the QM700 is the Quest QA3004 or QA4004 amplifiers . Setting Pin 2 is not connected . -
Page 7: Speaker Placement For Maximum Stage Monitor Performance
QM700 User Manual Speaker Placement for Maximum Stage Monitor Performance The QM 700 is primarily intended for use as Fig 1: Conventional monitors a stage monitor in mirrored pairs or as single speaker boxes . Why Mirrored Pairs? When two standard design fold-back monitors are placed in close proximity to each other and are reproducing the same signal, “interference... -
Page 8: Speaker Cables
QM700 User Manual Speaker cables If you intend to set up the QM700 as part of a multiple box array, see the section ‘Flying the Speaker cable needs to be as heavy gauge QM700’ . as conveniently possible for low-loss results . -
Page 9: Flying The Qm700
. the back of the room . The QM700 horizontal horn covers both “short-throw” and “long-throw” requirements in a single system . For the majority of installations (where the box is installed Ensure the box is securely located . -
Page 10: Qm700 Wave Guide Examples
QM700 User Manual QM700 Wave Guide Examples 45˚ +15˚ -45˚ 60˚ QM700 FOH Configuration (front) QM700 FOH Configuration (side) 60˚ 45˚ QM700 Foldback Configuration (front) QM700 Foldback Configuration (side) 45˚ 60˚ QM700 Horiztonal Configuration (front) QM700 Horizontal Configuration (side) User Manual... -
Page 11: Qm700 Specifications
QM700 User Manual QM700 Specifications Frequency (Hz) QM700 - Frequency Response - 2 .83V/1m Technical Parameters Power Handling 700W program ; 1400W peak Frequency Response 50-16kHz Sensitivity 98dB @ 1kHz Maximum SPL @ 1m 130dB Impedance 8 ohms Connections and Wiring... -
Page 12: Qm700 Reference Diagram
QM700 User Manual QM700 Reference Diagram 3bis 2bis No . Description Spare Part Complete Grill (with Acoustic Foam) HGQM700 15” Woofer (3” voice-coil, 500Wrms, 8ohms) T15005 2bis Recone kit to suit 15” woofer RT15005 Compression Driver 1 .4” exit (3”voice-coil, 80Wrms, 8ohms) -
Page 13: Tech Tips And Troubleshooting
QM700 User Manual Tech Tips and Troubleshooting will depend on a number of factors, but it is You can never know too much when it comes enough to say that by the time you get to the to the variety of technical issues that can end of the red, your mixer is now clipping and appear at your gig . -
Page 14: Buzzes And Noises In The Sound System
QM700 User Manual Powering up the PA system saving investment is a domestic power tester to check that the power supply sockets are correctly wired . Faulty or incorrectly wired It is wise to avoid switching on or off devices... - Page 15 QM700 User Manual Q Motion Series User Manual QM700...
- Page 16 Thank you for choosing Quest. Please take the time to complete your product registration card which is included with the packaging. Registering your Quest Engineering product will: • CONFIRM YOUR WARRANTY • REGISTER YOUR PRODUCT • PROTECT YOUR NEW PRODUCT REGISTER ONLINE: www.questaudio.net/registration...
