Copyright 2004 Carrier Corporation
Product
Data
Performance™ 13
38TXA (60 Hz)

Air Conditioner

®
with Puron
Refrigerant
Sizes 024 thru 060
Carrier's Performance™ 13 Air
Conditioners with Puron® refrigerant
provide a collection of features unmatched
by any other family of equipment. The
38TXA has been designed utilizing
Carrier's Puron refrigerant. The
environmentally sound refrigerant allows
you to make a responsible decision in the
protection of the earth's ozone layer.
Carrier's Performance™ 13 system with
Puron refrigerant meets the Energy Star®
guidelines for energy efficiency.
FEATURES
Puron Environmentally Sound
Refrigerant — Is Carrier's exclusive
refrigerant designed to help protect the
environment. Puron is an HFC refrigerant
which does not contain chlorine that can
harm the ozone layer. The most important
advantage of Puron refrigerant is that it
has not been banned in future air
conditioning systems as the traditional
refrigerant R-22 has been. Puron
refrigerant is in service in thousands of
systems providing highly reliable,
environmentally sound performance.
Carrier's Infinity® Controls — These
industry-leading controls, when installed
with Carrier's Ideal Humidity™ variable-
speed furnaces or fan coils, provide the
homeowner with:
–Unparalleled control of temperature,
humidity, indoor air quality, and zoning
–unprecedented ease of use
–simple operation through on-screen, text-
based service reminders
Optional remote access through telephone
or Internet is also available when combined
with a remote connectivity kit.
WeatherArmor™ III Protection
Package — This three-part protection
system begins with the galvanized steel
cabinet. Once coated with a layer of zinc
phosphate, a modified polyester powder
coating is then applied and baked on,
providing each unit with a hard, smooth
finish that will last for many years.
Additionally, the coil protector, made of a
coated steel wire grid with vertical 3/8 in.
spacing, is designed to help protect the
coil from inclement weather, vandalism
and incidental damage. It provides
protection while not restricting airflow
and maintaining ease of coil cleaning.
Form 38TXA-10PD
