22" 4.0A ELECTRIC HEDGE TRIMMER
22112
Owner's Manual
TOLL-FREE HELPLINE: 1-888-90WORKS
(888.909.6757)
Read all safety rules and instructions carefully before operating this tool.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 22112 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GreenWorks 22112

  • Page 1 22" 4.0A ELECTRIC HEDGE TRIMMER 22112 Owner’s Manual TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757) Read all safety rules and instructions carefully before operating this tool.
  • Page 2: Table Of Contents

    CONTENTS Contents ..........................2 Specifications ........................2 Important Safety Instructions ....................3 - 4 Specific Safety Rules ......................5 Symbols ..........................6 -7 Electrical ...........................8 - 9 Know your hedge trimmer ....................1 0 Assembly ..........................11 Operation ........................12-14 Maintenance ......................... 15 -16 Troubleshooting .........................
  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. READ THESE INSTRUCTIONS BEFORE USING THE HEDGE TRIMMER • Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • Do not force tool. Use the correct tool for your application. The correct tool will do the job better and safer at the rate for which it is designed. • Keep firm footing and balance. Do not overreach. Overreaching can result in loss of balance.
  • Page 5: Specific Safety Rules

    SPECIFIC SAFETY RULES • Replace any blade that has been damaged. Always make sure blade is installed correctly and securely fastened before each use. Failure to do so can cause serious injury. • Never cut any material over 3/4 in. •...
  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper inter-pretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 7: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.
  • Page 8: Electrical

    ELECTRICAL W A R N I N G TO AVOID ELECTRICAL HAZARDS, FIRE HAZARDS, OR DAMAGE TO THE TOOL, USE PROPER CIRCUIT PROTECTION. YOUR HEDGE TRIMMER IS WIRED AT THE FACTORY FOR 120V OPERATION. CONNECT TO A 120V, 15A CIRCUIT AND USE A 15A TIME- DELAYED FUSE OR CIRCUIT BREAKER.
  • Page 9 ELECTRICAL GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has a POLARIZED plug.The power cord MUST be plugged into a matching outlet that is properly installed and grounded in accordance with ALL local codes and ordinances.
  • Page 10: Know Your Hedge Trimmer

    KNOW YOUR HEDGE TRIMMER The safe use of this product requires an understanding of the information on the product and in this operator’s manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules. (See Figure 2.) CORD RETAINER A convenient cord retainer helps keep the extension cord connection secure during trimmer operation.
  • Page 11: Assembly

    ASSEMBLY UNPACKING • This product requires assembly. • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •...
  • Page 12: Operation

    OPERATION W A R N I N G Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. W A R N I N G Always wear safety goggles or safety glasses with side shields when operating power tools.
  • Page 13: Cutting Tips

    OPERATION STARTING THE HEDGE TRIMMER (See Figure 3.) 1. Attach an extension cord to your hedger. 2. Place one hand on the trigger handle (1). Place the other hand on the auxiliary handle (2). 3. Slide the lock switch (4) backwards you then squeeze the trigger switch (3) to turn ON the hedge trimmer.
  • Page 14: Operation

    OPERATION OPERATING THE HEDGE TRIMMER W A R N I N G Read the safety information for safe operation using the blade. Extreme care must be taken when using blades to ensure safe operation. Refer to Important Safety Instructions and Specific Safety Rules (See pages 3 - 5) The unit is used for cutting in either direction in a slow, sweeping action from side to side.
  • Page 15: Maintenance

    MAINTENANCE W A R N I N G WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS. USE OF ANY OTHER PARTS MAY CREATE A HAZARD OR CAUSE PRODUCT DAMAGE. W A R N I N G ALWAYS WEAR SAFETY GOGGLES OR SAFETY GLASSES WITH SIDE SHIELDS DURING PRODUCT OPERATION.
  • Page 16: Maintenance

    MAINTENANCE CLEANING THE HEDGE TRIMMER • Stop the motor and disconnect from power supply. • Clean dirt and debris from the body of the hedge trimmer, using a damp cloth with a mild detergent. NOTE: Do not use any strong detergents on the plastic housing or the handle. They can be damaged by certain aromatic oils such as pine and lemon, and by solvents such as kerosene.
  • Page 17: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Unit will not start. 1. Cord not plugged in. 1. Plug in cord. 2. Cord or switch is dam- 2. Have cord or switch aged. replaced. Motor runs, but cutting Hedge trimmer damaged. Call for technical service. blades do not move.
  • Page 18: Warranty

    (4) years against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. This warranty is valid only for...
  • Page 19: Exploded View

    EXPLODED VIEW...
  • Page 20: Parts List

    PARTS LIST ITEM NO. PART NO. DESCRIPTION 3630129 Switch 3340187 Spring 3410787-3 Lock off button 3340287 Spring 3411386-3 Switch trigger 3640186 Inner plug 3130186-5 Housing 3410386-2 Left vent 3220187 Screw ST3X12-C 3220905 Screw ST4X12-F 3410711-3 Guard 3220511 Screw M4X12 3130286-3 Auxiliary handle 3110486 Blade assembly...
  • Page 21 TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757) Rev: 01 (01-09-10) Printed in China on 100% Recycled Paper...
