About the dishwasher control panel.
You can locate your model number on the tub wall just inside the door. Throughout this manual, features and
appearance may vary from your model.

Control Settings

Status Indicator Lights
1
The Status display tells you what's happening while the dishwasher is in operation and may flash, indicating a
malfunction (see page 6). The lights will come ON indicating the sequence of operation the dishwasher is in.
SENSING
Displayed while the ExtraClean™ Sensor is measuring the amount of soil and temperature of
water. The dishwasher will adjust the selected cycle to achieve optimal performance.
WASHING
Displayed during prewash and main wash periods.
RINSING
Displayed during rinse periods.
DRYING
Displayed during HEATED DRY.
SANITIZED
Displayed when cycle has met sanitization conditions. Light remains ON until door is opened.
CLEAN
Displayed when a wash cycle is complete. The light will remain ON until door is opened.
Time Remaining Display
2
During operation, the display shows the minutes remaining until the cycle is complete. The display may
adjust the remaining time while the Sensing light is on. The time displayed at the start of each cycle may
change from the factory setting as the unit customizes itself to home use. During a delay start, the display
will show hours of time remaining until the cycle starts.
Selections
3
The light above the selected pad will be ON to indicate which WASH CYCLE has been selected.
ANTI-BACTERIA
POTS
COOK Heavy 10.4 gal., 102 min.
or
& PANS
WARE Medium 9.1 gal., 76 min.
NORMAL WASH
4
1
3
(on some models)
Heavy 9.1 gal., 91 min.
Medium 7.8 gal., 89 min.
Light 6.5 gal., 87 min.
This cycle raises the water temperature in the final rinse to sanitize your dishware. The
cycle length will vary depending on the temperature of your inlet water.
NOTE: The Anti-Bacteria cycle is monitored for sanitization requirements. If the cycle is
interrupted during or after the main wash portion or if the incoming water temperature is so
low that adequate water heating cannot be achieved, the sanitizing conditions may not be
met. In these cases, the sanitized light will not illuminate at the end of the cycle.
NOTE: NSF-certified residential dishwashers are not intended for licensed food
establishments.
Light 7.8 gal., 72 min.
This cycle is meant for heavily soiled dishes or cookware with dried-on or baked-on soils. This
cycle may not remove burned-on foods. Everyday dishes are safe to be used in this cycle.
Heavy 9.1 gal., 77 min.
Medium 6.5 gal., 62 min.
Light 5.2 gal., 49 min.
This cycle is for medium/heavily soiled dishes and glassware.
6
5
4
2
