This manual contains important information.
PN: 872035 (3-11)
Series 340 BN/MB Btu Transmitter
Hydronic Energy Transmitter with RS-485 BACnet™ & Modbus® and
Scaled Pulse Output
+
AC L /DC
AC C /DC
-
Btu ENERGY METER
Power Out
Signal +
Signal
-
Shield
Input LED
IMPORTANT:
READ AND KEEP FOR REFERENCE.
Installation & Operation Manual
Pulse Out -
Pulse Out +
Output LED
Data
Industrial
Model: 340 BN/MB
005100
S/N 340-
D.I.C.
Comm
Port
Comm LED
Advertisement
Table of Contents
Related Manuals for Badger Meter 340 BN Btu Series
Summary of Contents for Badger Meter 340 BN Btu Series
- Page 1 Series 340 BN/MB Btu Transmitter Hydronic Energy Transmitter with RS-485 BACnet™ & Modbus® and Scaled Pulse Output Pulse Out - Pulse Out + AC L /DC Output LED Data AC C /DC Industrial Btu ENERGY METER Power Out Model: 340 BN/MB Signal + 005100 S/N 340-...
- Page 2 Series 340 BN/MB Transmitter Page ii 3-11...
-
Page 3: Table Of Contents
Installation & Operation Manual CONTENTS Introduction .............................. Installation ..............................Mechanical installation ............................... 5 Location ..................................5 Surface Mount Installation ............................6 Wall Mounting ................................6 Din Rail Mounting ................................ 7 Temperature Sensor Installation ........................... Direct Insert.................................. 7 Thermowell................................... 7 Hot Tap ..................................8 Electrical Installation.......................... - Page 4 Series 340 BN/MB Transmitter Filter Coefficients..............................Pulse Output ................................RS-485 Network Configurations ..........................RS-485 Network Configuration – PULSE ONLY ..................... RS-485 Network Configuration – Modbus ......................... 20 Modbus Register Map ..............................21 RS-485 Network Configuration – BACnet ......................BACnet Object Map ..............................22 BACnet Protocol Implementation Conformance Statement ..................
-
Page 5: Introduction
The temperature sensors can be two-wire 10 kΩ Type II Thermistors or 100 or 1000 Ohm RTDs that follow the IEC 751 curve. The flow input may be provided by many of the Badger Meter line of flow sensors and other manufacturers' devices that generate pulses or sine waves. -
Page 6: Surface Mount Installation
Series 340 BN/MB Transmitter Surface Mount Installation The Series 340 BN/MB may be mounted to the surface of any panel using double sided adhesive tape or by attaching fasteners through the holes in the mounting flanges of the unit. 1.60” (40.6mm) 3.65”... -
Page 7: Din Rail Mounting
Figure 3: Din Rail Mounting Temperature Sensor Installation Badger offers several styles of 10k Thermistors and 100 Ohm Platinum RTDs in both direct immersion and Thermowells. The style selected depends on system requirements and pipe size. Direct Insert Generally for smaller pipe sizes direct insert sensors are used. -
Page 8: Hot Tap
For pipes that cannot be drained even for initial installation, we offer a Hot Tap version. Model THT – available as 10k Thermistor version only. Figure 6: Hot Tap Electrical Installation All connections to the Badger® Series 340 BN/MB are made to screw terminals on removable headers. Wire 3/32" Flathead Screwdriver... -
Page 9: Power Supply Wiring
Observe the polarity shown on the label. If a Badger Meter plug-in type power supply (Model A-1026 or A-503) is used, connect the black/white striped wire to the terminal marked positive (+) and the black wire to the terminal marked negative (-). -
Page 10: Sensor Wiring
The 340BN/MB is very versatile, and can accept both Pulse and Zero Crossing Sine Wave flow sensors. Excitation voltage is also provided for Three Wire Powered Sensors (Example: Hall Effect, of Badger 4000 Series). See the Programming Section for configuration instructions. -
Page 11: Thermistors
Pulse Output Wiring The Badger Meter Series 340 BN/MB has solid state switch output rated for a maximum sinking current of 100 mA @ 36V DC. In most cases the pulse out (+) terminal of the Series 340 BN/MB will connect to the input pulse (+) and the pulse out (-) terminal to the input pulse (-) of the receiving device. -
Page 12: Connecting The Rs-485 Buss
Series 340 BN/MB Transmitter Pulse Input Device NOTE: (-) (+) maximum sinking current is 100 mA @ 36 VDC Pulse Out - Pulse Out + AC L /DC Output LED AC C /DC Figure 12: Sample Pulse Output Wiring Diagram Connecting the RS-485 Buss As shown in the Sample Wiring Diagram, the position of jumpers on each 340MB/BN transmitter and wiring between each 340MB transmitter and the RS-485 network are different depending on where the transmitter is installed, i.e. -
Page 13: Communications Cable Wiring
USB to COM Port adapters can be used if the DB9 COM port is not available. NOTE: The Badger Meter A301 Cable will work with all Series 300 products. However the older version of the cable (A300) does not have sufficient bandwidth to work with the Series 340 BN/MB Transmitters. -
Page 14: Programming
“D.I.C. COM port”, taking care to properly align the tab on the plug and socket to maintain polarity. Connect the DB9 connector of the Badger Meter Model A301 communications cable to a PC COM port that has the 340 software installed. - Page 15 Installation & Operation Manual Once the 340BN/MB has been selected the appropriate COM port can be selected from the Configuration Tab. Figure 17: Select Set COM Port Figure 18: Select the COM Port If the COM and Device type have been properly selected, the “---” will be replaced with values. If this does not occur, communication has not been established, and you cannot continue to the next step.
- Page 16 Series 340 BN/MB Transmitter If communication still does not occur, and you are using a DB9 to COM 1 or COM2, try using a USB to COM adapter. This will usually create a new COM port that was not previously listed. Windows Device Manager can be helpful in determining the actual COM ports that are available.
- Page 17 Installation & Operation Manual When communication has been confirmed, Click on the Parameters button. Figure 21: Parameters Screen From this screen we will set up the following: 1. Flow Sensor Type, Scaling, and units. 2. Temperature Sensor Type, Units, Mode, and Zeroing. 3.
-
Page 18: Flow Sensor Section
Flow Sensor Section Figure 23: Pulse or Sine For most Badger Meter sensors the sensor type is “Pulse”, and the “K” and “Offset” values can be found in the respective Flow Sensor Manual. “Sine” is used for zero-crossing flow sensors (some turbine meters, etc.) Several flow rate and flow total units of measure can be selected from the pull-down menu. -
Page 19: Energy Calculation
Installation & Operation Manual The “Zero Temp Diff” is a very powerful feature in this product which allows any inaccuracies of drift in the temperature sensors, or 340 temperature measurements to be cancelled out. This correction can be either manually typed in or if the temperature sensors are known to be at exactly the same temperature, the “Zero Temp Diff”... -
Page 20: Rs-485 Network Configurations
Series 340 BN/MB Transmitter RS-485 Network Configurations The RS-485 Section can be configured in three ways: - PULSE OUT only – RS-485- OFF - Modbus - BACnet The following sections explain each in detail. RS-485 Network Configuration – PULSE ONLY Figure 27: Pulse Only Option If the Modbus or BACnet communications are not going to be used, the “Pulse Out Only”... -
Page 21: Modbus Register Map
Installation & Operation Manual Modbus Register Map MODEL 340BN/MB Register Map Register Name Address Data Type Read/Write Temperature 1 40001 + 40002 IEEE 754 Float Read Only Temperature 2 40003 + 40004 IEEE 754 Float Read Only Flow Input (Hz) 40005 + 40006 IEEE 754 Float Read Only... -
Page 22: Bacnet Object Map
Series 340 BN/MB Transmitter BACnet Object Map Out of Description Name Units Service Analog Input TempIn FALSE ºC, ºF Analog Input TempOut FALSE ºC, ºF Analog Input FreqIn FALSE gpm, gph, lpm, lph, Analog Input VolFlow FALSE ft3/s, ft3/m, ft3/h, m3/s, m3/min, m3/h kBTU/min, kBTU/h, Analog Input... -
Page 23: Bacnet Protocol Implementation Conformance Statement
Installation & Operation Manual BACnet Protocol Implementation Conformance Statement Page 23 3-11... -
Page 24: Rs-485 Network Test
Although it uses Modbus settings, it is RS-485 communication it is testing. The test requires connection to a COM port using the Badger Meter A302-20 RS 485 to RS-232 convertor cable. This cable can also be helpful with other diagnostics programs and devices that use an RS-232 port to communicate. -
Page 25: Factory Default Settings
Installation & Operation Manual Factory Default Settings The table below is a list of factory default setting for all 340BN/MB variables. These settings can be changed by accessing the parameters to best fit your application, and if desired, recorded in the table for future reference. Description Default Value Customer Value... -
Page 26: Specifications
Requires PC or laptop running Windows® XP, Vista or 1000Ω RTD, Platinum, Two or Three wire Windows 7 RTDs follow IEC 751 DIN Curve @0°C Badger Meter Model A-340 programming kit containing software and Model A301-20 programming cable Pulse Output Pulse width: Programmable 10mS to 5 sec. - Page 27 Installation & Operation Manual Blank Page Page 27 3-11...
- Page 28 Copyright 2011, Badger Meter, Inc. All rights reserved. Due to continuous research, product improvements and enhancements, Please see our website at www.badgermeter.com Badger Meter reserves the right to change product or system specifications without notice, except to the extent an outstanding contractual obligation exists. for specific contacts.
