Summary of Contents for Ice-O-Matic HISU056
- Page 1 Installation and User’s Manual Cube Ice Machine with storage models HISU056, HISU076 and HISU096...
-
Page 2: Table Of Contents
User Manual for Models HISU056, HISU076 AND HISU096 Introduction The design of this product is the result of years of experience in developing commercial ice cube machines. It has been designed for simple operation in a wide range of locations. Please follow the instructions for installation and maintenance to get the most use from this ice machine. -
Page 3: Important Details
User Manual for Models HISU056, HISU076 AND HISU096 Important Details Warranty: The machine is designed for use indoors in a controlled environment. It must be kept dry, not The warranty statement for this product is provided overheated or subjected to excessive cold. The water separately from this manual. -
Page 4: Pre-Installation
User Manual for Models HISU056, HISU076 AND HISU096 Pre-Installation Spacing: No additional spacing is required at the top or sides. This appliance is intended to be used in commercial However, suggested minimum side clearance for applications including: installation is 1/8 inch or 3 mm and suggested • Restaurant kitchens... -
Page 5: Cabinet Layout, Hisu056 And Hisu076
User Manual for Models HISU056, HISU076 AND HISU096 Cabinet Layout, HISU056 AND HISU076 60.3cm 23.7in 38.1cm 15.0in 81.1cm 31.9in 95.4cm 37.6in 68.9cm 27.1in 10.2cm 4.0in MINIMUM UTILITY CLEARENCE 15.2cm OUTLET INLET 6.0in 29.8cm 48.3cm 11.8in 19.0in July 2013 Page 4... -
Page 6: Cabinet Layout, Hisu096
User Manual for Models HISU056, HISU076 AND HISU096 Cabinet Layout, HISU096 60.1cm 23.67in 50.8cm 20.00in 81.1cm 31.94in 95.4cm 37.56in 10.2cm 4.00in 68.9cm MINIMUM 27.13in UTILITY CLEARENCE 15.2cm 6.00in OUTLET INLET 42.5cm 48.3cm 16.75in 19.00in July 2013 Page 5... -
Page 7: Component Location
User Manual for Models HISU056, HISU076 AND HISU096 Component Location Cube Deflector Curtain Thermostat Sensing Point Thermostat Condenser Fins Drain Plug Bin Thermostat Adjustment Controller Control Area Condenser Fan July 2013 Page 6... -
Page 8: Connect The Water Supply
User Manual for Models HISU056, HISU076 AND HISU096 Connect the water supply Connection Information: WARNING: connect to potable water supply only. Plumbing information: Important: Open the hand water valve to flush There is a single 3/4 gas BNF inlet water connection water through the tubing before connecting to the and a connecting hose is supplied. -
Page 9: Connect The Power
User Manual for Models HISU056, HISU076 AND HISU096 Connect the power This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the back of the machine for the voltage and maximum fuse size and per the dataplate use fuses or HACR circuit breakers. -
Page 10: Control Panel And Adjustments
User Manual for Models HISU056, HISU076 AND HISU096 Control Panel and Adjustments Ice Bridge Thickness Adjustment Area Ice Bridge Thickness Adjustment ON / OFF / WASH Ajuste da espessura da ponte de gelo Ligar / desligar / lavar Master Switch. Move to ON (left side depressed) to make ice, OFF (centered) to shut off and WASH (right side depressed) for use in cleaning. -
Page 11: Initial Start Up
User Manual for Models HISU056, HISU076 AND HISU096 Initial Start Up 9. Within a minute or so the ice formed in the mold will fall down and slide into the ice storage bin. 1. Remove the front panel by removing the two... -
Page 12: Use And Operational Notes
User Manual for Models HISU056, HISU076 AND HISU096 Use and Operational Notes To use, simply lift the door by its bottom edge and No Step slide it up and into the top of the machine. Use the Do not stand on the machine. -
Page 13: Maintenance
User Manual for Models HISU056, HISU076 AND HISU096 Maintenance 6. Mix a solution of 5 oz or 150 cc of ice machine Scale Remover and 2.5 quarts or 2.4 liters of Regularly vacuum the right side of the air cooled... - Page 14 User Manual for Models HISU056, HISU076 AND HISU096 7. Drain the reservoir into the storage bin by removing the drain plug. Return the drain plug to its normal position. 8. Wash all interior surfaces of the ice machine storage bin, reservoir surface and inside of the door with the remaining sanitizer solution.
-
Page 15: Before Calling For Service
User Manual for Models HISU056, HISU076 AND HISU096 Before calling for service No ice – check water supply No ice – check power supply. Remove front panel, if there are no lights on the control panel there is no power to the controller. -
Page 16: 208-230/60/1 Wiring Diagram
User Manual for Models HISU056, HISU076 AND HISU096 208-230/60/1 Wiring Diagram July 2013 Page 15... - Page 17 PRÁTICA PRODUTOS S.A RODOVIA BR459, KM 101 POUSO ALEGRE - MG BRAZIL 37 550 000 TOLL FREE #: 0800 035 5033 17-3438-32...
