Summary of Contents for Blizzard Lighting PROKONTROL MH
- Page 1 PROKONTROL Blizzard Lighting, LLC www.blizzardlighting.com Waukesha, WI USA Copyright (c) 2013...
-
Page 2: Table Of Contents
Fade In/Out Time of Color Channels 3.9.6 Firmware Updates 4. APPENDIX A Quick Lesson On DMX Keeping Your ProKontrol™ MH As Good As New Returns (Gasp!) Shipping Issues Tech SPECS! Page 2 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 3: Getting Started
Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. -
Page 4: Instructions On Our Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may re- quire service, please contact Blizzard Lighting at support@blizzardlighting.com. 1.5 Instructions on Our Instructions We try to make these manuals easy to read and as fun as reading an instruc- tion manual can be. -
Page 5: Introduction
“Movement” and built-in “Color Effect” buttons, plus an LCD display indicator for easy navigation of all controls and menu functions. 2.3 The ProKontrol™ Pin-up Pictures Page 5 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 6: Button And Fader Functions
In CHASE mode, PAN/TILT wheels are to adjust the chase speed and time respectively. • In SCENE mode, nothing defined in PAN/TILT wheels. • In MOVEMENT mode, PAN/TILT wheels are to adjust the MOVEMENT parameters. • In FIXTURE mode, PAN/TILT wheels are to adjust the output values of PAN/ TILT. Page 6 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 7: Common Terms
Playbacks can be either scenes or chases that are directly called to execution by the user. A playback can also be considered program memory that can be recalled during a show. Page 7 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 8: Operating Instructions
07. Data Load - To load data from a USB memory stick. 08. Send Fixture Update File - To send the fixture update code. The PAN wheel is used to browse between the menu options. Page 8 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 9: Fixture Adressing / Patching Fixtures And Faders
PAN/TILT wheels on the ProKontrol MH. If you are patching an LED fixture, then, you must patch the Red, Green, Blue, White and Dimmer channels to the corresponding faders respectively. The ProKontrol MH will then be able to correctly run all of its built-in movements and fade in/out effects with the patch setting. Page 9 ProKontrol MH Manual Rev. -
Page 10: Fixture Patching Instructions (Step By Step)
When patching, a “!” mark will be shown in the LCD display when there is a overlap in the patching of DMX channels. This will need to be corrected, otherwise the DMX output may run in error. Page 10 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 11: System Functions
Press and hold <MENUS> for 2 seconds to enter Menu Mode. Insert a USB memory stick to the USB port. Rotate the PAN wheel to locate “08. Send fixture Update file”. Press <ENTER> to confirm. Rotate the PAN wheel to locate the file to send. Press <ENTER> to start sending. Repeat Step 4 and 5 to send another file. Press the <ESC> button to exit. Page 11 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 12: Rdm Dmx Address Setup
PAGE button (PAGE A: 1-16, PAGE B: 17-32). Press the <MOVEMENT> button to activate the MOVEMENT mode. Select a desired MOVEMENT/MACRO with the number buttons (1-16). Movement 1-9 is for the pan/tilt movement of moving heads. By using the <SWAP> button, toggle through the options. Page 12 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 13: Scenes And Chases
Channels, scenes and movements can be edited in a chase. Press and hold the <REC> button for 2 seconds to enter Editing Mode. Press the <CHASE> button (indicator on). Select a number button for the chase. Page 13 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 14: Run Scenes
Press and hold the <FIXTURE> button, then rotate the PAN wheel to adjust the fade in/out time of the color channels. Each fixture can be set with individually fade in/out settings. Fade in/out time can also be set to enabled/disabled. Page 14 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 15: Firmware Updates
3.9.6 Firmware Updates If firmware updates become available anytime in the future, they will be avail- able at our website at: www.blizzardlighting.com. Create a folder named “PROKONTROL MH” in the root directory of your USB memory stick. Download and copy the update file to the folder. Insert the USB memory stick to the USB port. Power off the controller. Press and hold REC + BLACK OUT + RUN MODE. -
Page 16: Keeping Your Prokontrol™ Mh As Good As New
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 16 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... -
Page 17: Tech Specs
Max. Operating Temp. 104 degrees F (40 degrees C) ambient Control Protocol USITT DMX-512 DMX Channels Output 3-pin XLR Female Remote Control Telekinesis (Supernatural Skills Required) Warranty 2-year limited warranty. Page 17 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC... - Page 18 This page intentionally left blank. Page 18 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC...
- Page 19 This page intentionally left blank. Page 19 ProKontrol MH Manual Rev. A © 2013 Blizzard Lighting, LLC...
- Page 20 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
