- Page 1 HDMI-SPL-2201C HDMI-SPL-2202C HDMI 1.3 over Single CAT5 1x2 Splitter User Manual HDMI-SPL-2201C HDMI-SPL-2202C Made in Taiwan...
-
Page 2: Safety And Notice
Safety and Notice The HDMI-SPL-2201C& HDMI-SPL-2202C 1x2 HDMI 1.3 over Single CAT5 Splitter has been tested for conformity to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the HDMI-SPL-2201C & HDMI-SPL-2202C should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 The devices are cascadable, allowing you to extend HDMI or DVI compliant displays almost anywhere. HDMI source Diagram HDMI cable HDMI-SPL-2201C HDTV Speaker Audio cable CAT5/6 cable...
- Page 4 Features State-of-the-art Silicon Image (founder of HDMI) chipset embedded for upmost compatibility and reliability HDMI 1.3 compliant HDCP compliant Regenerates the HDMI signal Supports audio output Supports default HDMI EDID and has the ability to learn the EDID of displays Extends up to 15m of input HDMI cable Extends up to 15m of output HDMI cable Extends up to...
- Page 5 Power supply 5V 4A DC Power consumption 3 Watts [max] Operation temperature 0~40°C [32~104°F] Storage temperature -20~60°C [-4~140°F] Relative humidity 20~90% RH [no condensation] 1x HDMI-SPL-2201C or HDMI-SPL-2202C Package Contents 1x 5V power adapter 1x User Manual ~ 4 ~...
-
Page 6: Panel Descriptions
Panel Descriptions HDMI-SPL-2201C 1x2 HDMI 1.3 over Single CAT5 Splitter 1. Input signal format indicator [bright: HDMI signal, dim: DVI signal] 2. DIP switch [see table below] 3. HDMI IN: Connect a HDMI source with a HDMI M-M cable here 4. - Page 7 (longest-to-shortest transmission length). It is recommended to adjust from 7-to-0 or from F-to-8 to find the optimal visual experience. 3. HDMI Signal IN: Link to HDMI-EXT-0101C-TX, HDMI-SPL-2201C, HDMI-SPL-2202C or HDMI-SPL-2208C with a Cat-5/5e/6 cable 4. Audio OUT: Plug in a local speaker here 5.
-
Page 8: Hardware Installation
Extends HDMI signals to next cascading device with one local display 1. Switch off all devices, including monitors. 2. Connect a local HDMI display to the HDMI out of the HDMI-SPL-2201C and then connect a speaker to the 3.5mm audio socket. - Page 9 4. Connect to next HDMI-SPL-2202C (for cascading), to HDMI-EXT-0101C-RX (to HDTV at long range), or HDMI-EXT-1111C-RX (to HDTV at mid range) via RJ-45 out by a CAT5 cable. 5. Plug in 5V 4A DC power supply. 6. Power on the HDTV. HDMI-SPL-2201C CAT5 cable HDMI-SPL-2202C HDMI cable...
- Page 10 HDMI & RJ-45 Pin Definition Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0– Pin 16 Pin 3 TMDS Data2– Pin 10 TMDS Clock+ Pin 17 DDC/CEC Ground Pin 4 TMDS Data1+ Pin 11 TMDS Clock Shield...
- Page 11 Notice 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI or HDMI display EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C.
- Page 12 ~ 11 ~...
