Summary of Contents for ENERGY SISTEM Mobile 390 TV Deep Black

  • Page 1 User Manual...

  • Page 3: Battery Disposal

    1. INTRODUCTION To ensure your safety and the safety of others, please ensure that you read all the safety information before operating this product. Keep this information in a safe place for future reference. This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.

  • Page 4: Controls And Connections

    2. CONTROLS AND CONNECTIONS 2.1. PANEL ILLUSTRATION Screen. Stereo speakers. Power ON/OFF indicator. Infrared Sensor to receive the remote control signals. Battery-charge indicator.
  • Page 5 Disc cover opening button. Next track/file. Previous track/file. Play/Pause. Starts of pauses the playback. Stop. Stops the playback. OK: To confirm the selection. SOURCE: Media selection. SETUP: Mobile 390 TV’s setup menu. MENU: Access to the main menu. EXIT: In DVB-T mode, press to exit the current menu. Move up in the menus.
  • Page 6 20.On/Off switch. DC IN Power connection (12 V). 3.5 mm (1/8”) stereo earphones output. 3.5 mm (1/8”) TRRS A/V output. Volume control. USB host port (Type A). ANT in (75 Ohm). 2.2. CONNECTING TO A TV...

  • Page 7: Remote Control

    3. REMOTE CONTROL 3.1. BUTTON DESCRIPTION TFT ON/OFF: Turns on/off the screen. DVB/USB: Switches between DVB and USB mode. NUMERIC KEYBOARD. GOTO: Go to a specific time index. STOP: Press to stop playback. PLAY/PAUSE: Press to start/pause/ resume the playback. TV/RADIO: Switches between TV channels and radio channels.
  • Page 8 3.2. BATTERY Pull the battery loader out and insert a CR2025 battery. Make sure to place the battery in the correct direction. When not using the remote control for a long time remove the battery. When operating range reduces replace the battery. 4.

  • Page 9: System Setup

    5. PICTURES The operation of the image viewer is similar to the music/video viewer. Image rotation: Use the direction keys to rotate the picture. Press ANGLE button to change the picture scan mode. 6. SYSTEM SETUP Press the SETUP button on the remote control, the SETUP MENU(main)will be displayed. After accessing the setup menu, press the direction buttons for up and down movement to select an item desired, then press the ENTER button to confirm.

  • Page 10: Misc Setup

    6.3. RATING ≥ Parental Control Selecting a Rating allows the user to set the parental control feature of the player Select Parental Control, and press ENTER to change the different mode. Note: Unlock the password before setting Parental Control. ≥ Set Password Use the 0-9 keys to input four digits(password), then press ENTER to confirm.

  • Page 11: Auto Search

    7.2. DVB-T MAIN MENU To access the DVB-T Main Menu, press the SETUP or MENU buttons from the remote control. The DVB-T main setup menu appears in the screen. Use direction buttons to navigate through the DVB-T Menu options. The selected choice will be highlighted. 7.2.1.

  • Page 12: Troubleshooting

    8. TROUBLESHOOTING If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section. Problem Possible cause Solution There is no picture or no Improper connection with AC Check the connection sound...
  • Page 13 Problem Possible cause Solution The LED does not light up Mains cable is not connected Check that the mains cable is / not lit when the device is plugged into the power socket connected to the mains Can’t play the music file The file is damaged or the Change the file correctly OR can’t play the...

  • Page 14: Specifications

    9. SPECIFICATIONS General TV System PAL / NTSC Supported disc formats DVD, VCD, CD, CD-R, CD-RW, DVD+-R/W Supported file formats MP3, JPEG, MPEG4 Video S/N Ratio >= 65 dB Resolution >= 500 lines Audio Frequency 20 Hz - 20 kHz +/- 1 dBI S/N ratio >= 90 dB Dynamic Range...

  • Page 15: Warranty Procedure

    10. WARRANTY Energy Sistem Soyntec S.A. warrants its products to be free from defects in materials and workman- ship at the time of purchase. The warranty period is 36 months from the date of purchase. 11. WARRANTY PROCEDURE ≥ Visit the Support section at http://support.energysistem.com and select your product to view the FAQ (Frequently Asked Questions).
