SERIAL 1 SERIAL 2 SERIAL 3
(BUS A)
SCSI
OUT OUT
IN IN
NET AUDIO 1 AUDIO 2
Video
VID1 to VID16
MON A
MON B
MON A
Audio
AUDIO 1 IN
AUDIO 1 OUT
AUDIO 2 IN
AUDIO 2 OUT
Data
SCSI
NET
SERIAL 1 & 2
SERIAL 3 & 4 (BUS A & BUS B) 9-way (Male) D-type RS-232, RS-422 and RS-485 serial port.
TERM
485 BUS

Alarms and relays

R1
R2
DIRECT
AUX ALARMS
AUX RELAYS
Dedicated Micros ©2007
1 2 3 4 5
TERM
SERIAL 4
485 BUS
(BUS B)
A
B
MON A MON VID 1 VID 2 VID 3 VID 4 VID 5
75Ω BNC composite camera connections, 1V pk-pk with loop
through, unit is available as a 10 or 16 channel unit
Not currently used, available for future expansion
75 Ohms BNC composite monitor output, 1V pk-pk
Not currently used available for future expansion
RCA (phono) socket, 22KHZ sampling, 47 KΩ input impedance.
RCA (phono) socket.
RCA (phono) socket.
RCA (phono) socket.
50-pin HD SCSI-2 connection.
RJ-45 100-baseT Ethernet connection.
9-way (Male) D-type RS-232 serial port
Termination DIP switches for RS-485.
2x MMJ ports for DM 485-BUS accessories.
Screw terminal, alarm relay dry contact, NO/NC, configurable for
alarm.
Screw terminal, activity relay dry contact, NO/NC, configurable for
VMD.
Screw terminal, direct auxiliary input, NO/NC.
25-way (Female) D-type programmable alarms, NO/NC.
9-way (Female) D-type, configurable for global camera fail and
trigger on alarm.
AUX ALARMS AUX RELAYS
VID 6 VID 7 VID 8 VID 9 VID 10 VID 11 VID 12 VID 13 VID 14 VID 15 VID 16
