Coleman EVEN HEAT 85-3026-0 Assembly Manual

Coleman EVEN HEAT 85-3026-0 Assembly Manual

With 3 burners
Hide thumbs Also See for EVEN HEAT 85-3026-0:

Advertisement

Quick Links

Download this manual
DURABILITY • POWER • PERFORMANCE
EV E N HEAT ™
b A r bE cu E
3
wiTH
burNErs
AssEMbLY MANuAL
85-3026-0 (G52201) Propane
85-3027-8 (G52202) Natural Gas
LIMITED 5-YEAR WARRANTY
Read and save manual for future reference.
Assemble your grill immediately. Missing or damaged parts
should be claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-800-275-4617.
www.colemanbbqs.com
Manual Revision #: 22122009 PD

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVEN HEAT 85-3026-0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Coleman EVEN HEAT 85-3026-0

Summary of Contents for Coleman EVEN HEAT 85-3026-0

  • Page 1 DURABILITY • POWER • PERFORMANCE EV E N HEAT ™ b A r bE cu E wiTH burNErs AssEMbLY MANuAL 85-3026-0 (G52201) Propane 85-3027-8 (G52202) Natural Gas LIMITED 5-YEAR WARRANTY Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase.

  • Page 2: Hardware Pack

    HArDwArE PAcK TOOLS NEEDED FOR ASSEMBLY No. Description Part Number Qty. ¼"-20UNCX38 Screw 20120-13038-250 • #2 Phillips screwdriver (long and short) ¼"-20UNCX16 Screw 20120-13016-250 • ¼” Slotted screwdriver (long and short) ø7 Lock Washer 41400-07000-250 • Adjustable wrench ø7 Washer 40300-07000-250 •...
  • Page 3 G522-0400-01 plate - middle Left door assembly G522-8000-01 Even Heat™ heat distribution G522-0064-01 Right door assembly G522-9000-01 plate - right Door handle G522-0036-01 Coleman® signature cooking G522-0023-01 grate Bottom shelf-LP G522-4000-01 Warming rack G515-0058-01 Locking castor G401-0061-01 Match holder G608-0019-01...
  • Page 4 G522-0400-01 plate - middle Left door assembly G522-8000-01 Even Heat™ heat distribution G522-0064-01 Right door assembly G522-9000-01 plate - right Door handle G522-0036-01 Coleman signature cooking G522-0023-01 Bottom shelf-NG G522-4600-01 grate Locking castor G401-0061-01 Warming rack G515-0058-01 Castor G606-0027-01 Match holder...

  • Page 5: You Will Need

    AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs Separate the 2 different types of castors: Attach the front brace (CI) to the left 2 locking castors (EG) and 2 regular and right cart side panels (EA and EB). castors (EH). The top of the front brace (CI) can be identified by two clips located on the top Attach the locking castors (EG) to the left, and right side of this part.
  • Page 6 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs PROPANE MODEL ONLY Attach the upper back panel (CL) to both the left and right side panels (EA & b. Locate the Quick Check hydraulic EB). tube support bracket (A) on the DO NOT tighten screws until all left side panel (EA).
  • Page 7 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs d. Final image reflects the proper TIP: Do not tighten until all hardware is assembly of the Quick Check fuel in place. gauge assembly (EK). a. Mount the right side shelf (DG) onto the two hooks, located on the right, upper side panel of the burner box (BA).
  • Page 8 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs TIP: Do not tighten until all hardware is a. Remove the hardware that is in place. pre-assembled to the side burner valve (CC). Feed the side burner valve (CC) a. Mount the left side burner side shelf through the bottom of the left side (DA) onto the two hooks, located burner side shelf (DA), and re-attach...
  • Page 9 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs TIP: The Electrode Set, main burner e. Using the wing nut (#14), assemble the side burner (DC) to the side burner (CF) and the Electrode wire, side burner (DD), can be found attached drip pan (DB), as shown. to the control panel (CH) heat YOU WILL NEED: shield, as shown in figure C.
  • Page 10 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs a. Assemble the heat shield (CM) to Assemble the door support rail (CP) to the bottom of the front brace (CI) as the left and right upper side panels (EA shown in figure A. and EB), as shown. WARNING: This part may have sharp WILL NEED: edges.
  • Page 11 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs PROPANE MODEL SHOWN Position the Even Heat heat distribution plates (BD,BE and BF) into a. Assemble the right door assembly the burner box (BA) as shown. (ED), to the bottom shelf (EF) by inserting the fixed pin (bottom of door) into the hole provided (figure B).
  • Page 12 AssEMbLY iNsTrucTiONs AssEMbLY iNsTrucTiONs a. Position the QUICK CLEAN grease FOR PROPANE MODEL ONLY. tray (CJ) onto the right and left tracks For natural gas model, follow step 21. (CN and CO), as shown. a. Feed the regulator (CB) through the opening on the left side panel (EA).

  • Page 13: Additional Warnings

    ADDiTiONAL wArNiNGs You have now completed the Assembly of your COLEMAN® EVEN HEAT™ BARBECUE. NEXT STEPS: Position your BARBECUE Read SAFETY & CARE MANUAL Perform Grill Safety Check-list WARNING HOT SURFACES: WARNING: FOR YOUR FAMILIES SAFETY, DO NOT ATTEMPT TO LIGHT...

This manual is also suitable for:

Even heat 85-3027-8Even heat g52201Even heat g52202
