WLAN
2 WLAN antennas are supplied in models with integrated WiFi and should be screwed into the standard
SMA connectors.
USB
There are 2 USB 3.0 ports (5 Gbps) and 2 USB 2.0 ports on the back panel.
All USB ports support current up to 1A.
Ports on the back are upside down – note when connecting USB plugs.
Depending on the FACE Module used - some models incorporate additional 4 USB 2.0 ports in the front.

Serial port

The RS232 mini-serial port is located on the back panel.
Mini-serial to DB9 cable to connect to standard serial devices is sold separately.
eSATA
MintBox 2 features two eSATA ports. Ports are located on the back panel.
