SERVICE MANUAL
MICRO COMPONENT MD SYSTEM
1
MARK
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
WXYZ
0
10
+10
Contents
Safety precautions
Preventing static electricity
Important for laser products
Disassembly method
Main adjustment
Flow of functional operation
until TOC read (CD)
Flow of functional operation
until TOC read (MD)
UX-A70MD
1-2
1-3
1-5
1-6
1-28
1-32
1-33
This service manual is printed on 100% recycled paper.
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
COMPACT
DIGITAL AUDIO
UB
US
UT
UF
UJ
Maintenance of laser pickup
Replacement of laser pickup
Maintenance of MD pickup
Procedures of changing
the MD pickup
Description of major ICs
UX-A70MD
UX-A70MD
Area Suffix
Hong Kong
Singapore
Taiwan
China
U.S.Military
1-34
1-34
1-35
1-35
1-36~56
No.20901
1-1
Jan. 2001
