SERVICE MANUAL
MICR COMPONENT MD SYSTEM
It will guide to be change in the following in service manual UX-A70MD
No.20901 issued before.
The mistake is partially found in MD and the CD adjustment, and all
1.
sentences are replaced.
(Refer to page 1-28
2. Guide of extension cable for repair.
Parts No.
QUQ110-2130BM
EXTUXA70MD-14P
Contents
Adjustment method (CD/MD section)-----------------------1-2
1)CD section -------------------------------------------1-2
2)MD section-------------------------------------------1-3
UX-A70MD
Supplement
1-31 of service manual UX-A70MD No.20901)
Extension for MD unit
Extension for CD unit (2 piece use)
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
UB
UF
US
UT
UJ
UP
Usage
UX-A70MD
Area Suffix
Hong Kong
China
Singapore
Taiwan
US military
Corea
No.20901B
Mar. 2001
