Model W1791/W1792 Mini HVLP Spray Gun SAFETY For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages.
Page 4
Model W1791/W1792 Mini HVLP Spray Gun Safety Instructions for Pneumatic Tools 10. USE PROPER AIR HOSE for the 17. DISCONNECT TOOLS before tool. Make sure your air hose is in servicing, changing accessories, or good condition and is long enough moving to another location.
Model W1791/W1792 Mini HVLP Spray Gun Additional Safety Instructions for Spray Guns READ THIS MANUAL. This manual PROTECTIVE CLOTHING. Protect contains proper operating exposed skin from overspray by instructions for this spray gun. wearing a protective suit or other approved garment.
Model W1791/W1792 Mini HVLP Spray Gun INTRODUCTION Woodstock Technical W1791 Specifications Support Type ....... HVLP Gravity Feed Fluid Tip ....... 0.8 mm This tool has been specially designed to Air Consumption ....3.5–6 CFM provide many years of trouble-free ser- Inlet Air Pressure ..3-4 Bar /43.5-58 PSI vice.
Page 7
Inventory The following is a description of the main components shipped with the Model W1791/ W1792. Lay the components out to inventory them. Note: If you can't find an item on this list, check the mounting location on the tool or examine the packaging materials carefully.
Page 8
Model W1791/W1792 Mini HVLP Spray Gun Assembly Controls Insert the filter into the gun body Atomizing Cap (see Figure 3). Fluid Control Trigger Pattern Control Air Flow Control Regulator/Gauge Figure 4. Controls (W1791 shown). Fluid Control: Controls the volume of material that travels through the Figure 3.
Page 9
Model W1791/W1792 Mini HVLP Spray Gun OPERATIONS Spraying The Model W1791/W1792 HVLP spray gun is designed to spray low to medium viscosity materials, such as lacquers, stains, primers, multi-component paints, acrylics, epoxies etc. It is ideal for auto body touch-ups, woodworking projects, or projects with hard to reach areas.
Page 10
Model W1791/W1792 Mini HVLP Spray Gun 7. Adjust the fluid control knob to 10. Begin spraying 2-3 inches before the start with a low volume of material work and continue to the end of the and keep the atomization as low work.
Model W1791/W1792 Mini HVLP Spray Gun Atomizing Cap and Fan Rotating the pattern adjustment control in Figure 8 will give you a range between Adjustments the two patterns in Figure 9. The atomizing cap needs to be adjusted for horizontal or vertical spraying Stroke patterns.
Model W1791/W1792 Mini HVLP Spray Gun CLEANING & LUBRICATION Cleaning 5. Unscrew the atomizing cap with your fingers and the fluid tip with Proper cleaning is the best way to ensure the service wrench. The fully trouble free performance from your spray disassembled gun should look like Figure 10.
Page 13
Model W1791/W1792 Mini HVLP Spray Gun Lubrication Lubricate the following areas with spray gun lube after cleaning: A. Atomizing Cap Threads B. Air Valve Packing C. Trigger Pin D. Air Flow Control Valve E. Pattern Control F. Fluid Control Knob After each cleaning, apply a thin film Figure 11.
Model W1791/W1792 Mini HVLP Spray Gun Troubleshooting Symptom Possible Cause Possible Solution Fluttering or 1. Dry or worn fluid tip seat 1. Tighten fluid tip or replace Spitting spray. permits air to seep into fluid seat with new one. passage.
Page 15
Model W1791/W1792 Mini HVLP Spray Gun Symptom Possible Cause Possible Solution Excessive over- 1. Fluid pressure too high. 1. Reduce fluid pressure. spray. 2. Gun is too far from surface. 2. Keep gun at recommended distance. 3. Spraying too fast.
Woodstock International, Inc. will repair or replace, at its expense and at its option, the Shop Fox machine or machine part which in normal use has proven to be defective, provided that the original owner returns the product prepaid to a Shop Fox factory service center with proof of their purchase of the product within two years, and provides Woodstock International, Inc.
2. How long have you been a woodworker/metalworker? _____ 0-2 Years _____ 2-8 Years ____ 8-20 Years _____ 20+ Years 3. How many of your machines or tools are Shop Fox? _____ 0-2 _____ 3-5 ____ 6-9 _____ 10+ 4. Do you think your tool represents a good value?
Page 20
FOLD ALONG DOTTED LINE Place Stamp Here WOODSTOCK INTERNATIONAL INC. P.O. BOX 2309 BELLINGHAM, WA 98227-2309 FOLD ALONG DOTTED LINE TAPE ALONG EDGES--PLEASE DO NOT STAPLE...
