Hardware Installation

Enclosure Sleeve
F
o r
t n
B
a
k c
Back Panel
Front Panel
Note: The diagrams below are using the FireWire/USB2.0 Enclosure as an
example
1. Unscrew to loosen the Back Panel and remove the Back Panel from
the Enclosure.
2. Use your thumb to push the Base Plate out.
8
