VITOSOLIC 200

Control unit for solar heating systems

Technical Data Manual

Part Nos. and Pricing: see Price List

Vitosolic 200

VITOSOLIC 200

Electronic temperature differential control unit

for up to four energy consumers

for systems with dual mode DHW heating or dual mode DHW

and swimming pool water heating or space heating backup

using solar panels and oil-/gas-fired boilers

With digital temperature display, energy meter,

reloading suppression for the boiler, heating-up of the pre-heat

stage and diagnostic system

For wall mounting

With optional connection of solar cell

5345 075 v1.0 10/2005

Page 1 VITOSOLIC 200 Control unit for solar heating systems Technical Data Manual Part Nos. and Pricing: see Price List Vitosolic 200 VITOSOLIC 200 Electronic temperature differential control unit for up to four energy consumers for systems with dual mode DHW heating or dual mode DHW...
Page 2: Product Information
(safety circuit is feasible. This requires the use of shutdown at 90ºC / 194ºF) in Vitosolic 200 Vitosolic 200 comprises: the optional solar cell. or by the high limit safety cut-out (if Electronics, digital display and setting keys.
Page 3: Technical Data
–4 to 158 ºF at 120 VAC H Total: max. 10A For systems with DHW tanks from Viessmann, the tank temperature sensor is installed directly into the sensor well of the elbow threaded into the heating water return. When a temperature sensor (swimming...
Page 4 For aquastats, tank temperature sensor or 120/240 V cables. temperature sensor (swimming pool) Solar cell CS 10 with connecting cable, For Viessmann DHW cylinders, part of the 2.3 m long. Permissible ambient temperature standard delivery. The solar cell records the intensity of solar H during operation: 0 to 90 ºC /...
