Remote control

Loading Batteries

1. Open the battery cover.
• Slide back and remove the battery
cover in the direction of the arrow.
2. Load batteries.
• Load two Size AA batteries included observing the correct
polarities.
3. Close the battery cover.
• Replace the battery cover in the direction of the arrow and snap
it back into place.
• Do not use new and old batteries together. The batteries could
explode or leak, resulting in fires, physical injury, or stains.
• When loading batteries, observe their correct polarities as
marked on the product. If loaded in the wrong direction, the
batteries could explode or leak, resulting in fires, physical injury,
or stains.
Downloaded from www.Manualslib.com
POWER OFF button
POWER ON button
MUTE button
RGB/VIDEO buttons
PinP button
AUTO button
MENU button
OK button
ID button
CAUTION
manuals search engine
POWER ON/OFF button
VOLUME UP/DOWN buttons
VOL
RGB 1 RGB 2 MUTE VOL
SIZE button
AV1 AV2 AV3 AV4
RECALL button
AUTO PinP SIZE RECALL
MENU
RETURN button
OK
SELECT/ADJUST buttons
ID ID SET
ID SET button

Handling the Remote Control

Use the remote control within about 5 m from front of the unit's
remote-control sensor and within 30 degrees on both sides.
With in 30
degrees
About 3m
ATTENTION
• Do not drop or impact the remote control.
• Do not splash the remote control with water or put it on a wet
object to avoid possible failures.
• Before leaving the remote control out of use for an extended
period of time, remove the batteries from it.
• If the remote control begins to lack responsiveness, replace the
batteries.
• Strong light such as direct sunlight impinging on the
photoreceptor of the remote control can cause operational
failure. Position this unit to avoid direct contact with such light.
With in 30
degrees
About 3m
About 5m
VOL
RGB 1 RGB 2 MUTE VOL
AV1 AV2 AV3 AV4
AUTO PinP SIZE RECALL
MENU
OK
ID ID SET
