  • Page 1 HDTV INDOOR ULTRATHIN ANTENNA AMPLIFIED OMNIDIRECTIONAL 1500080 User’s Guide Please read this user’s guide before using your new antenna. Patent Pending...
  • Page 2: Package Contents

    Package Contents Antenna Power Injector 6-ft Coaxial Cable AC Adapter Detachable Stand Features • Up to 20-mile range, ideal for urban use • Sleek, unobtrusive design • Integrated low-noise amplifi cation • Omnidirectional • Sits upright, lies fl at, or mounts to a wall •...
  • Page 3: Connect Antenna

    Connect Antenna 1. Connect one end of the included 6-ft coaxial cable to the antenna’s output cable. 2. Connect the other end of the cable to the power injector’s ANT terminal. 3. Connect the power injector’s pre-attached coaxial cable to the Antenna In jack on your TV, receiver, or set top box.
  • Page 4 Å È To Power Injector’s DC 9V Jack Ç Æ Receiver To Antenna In Set Top Box...
  • Page 5 On a Wall: 1. Drill two holes into the wall at the distance that fi ts the antenna mounting holes, about 4¾ inches (120 mm) apart. 2. Thread screws (not supplied) into each hole with the heads extend about ¼ inch (6 mm) from the wall. 3.
  • Page 6: Specifications

    Note: • For HD reception, you need a TV with an ATSC HDTV tuner, an HDTV receiver, or digital set top box. • Use only an adapter that supplies 9VDC and delivers at least 300mA. Its center tip must be set to positive and its plug must fi...
  • Page 7 No Channels? In most cases, simply connecting your antenna to your TV will not instantly provide your local channels. Most televisions require some minor confi guration before you see programming. Refer to your television’s user’s guide for information No Channels about performing the following steps: 1.
  • Page 8: Limited Warranty

    FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 9 You may contact Ignition L.P. at: Ignition L.P., 3102 Maple Ave., Suite 450, Dallas, TX 75201 02/09 For product support, call 1-866-315-0426 © 2014 Ignition L.P. All rights reserved. Antennacraft is a registered trademark Printed 01C14 used by Ignition L.P. in China 1500080...
