ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.
CONTENTS SAFETY DEVICE OVERVIEW EFINITIONS NSERT YOUR CARD & O OWER REATE OR OG IN TO A OOGLE CCOUNT SING THE OUCH CREEN ONTROLS CREEN HONE TATUS AND OTIFICATION CONS PHONE CALLS AKING ALLS ECEIVING ALLS CONTACTS MESSAGES MMS M ESSAGES SING MAIL...
Page 3
SING THE ROWSER LUETOOTH ONNECT TO A OMPUTER OMPATIBILITY EATURE UMMARY USING MULTIMEDIA FUNCTIONS AMERA IDEO ECORDER FM R ADIO USIC IDEOS ALLERY OUND ECORDER GOOGLE APPLICATIONS N OR REATE OOGLE CCOUNT SING MAIL SING OOGLE ALENDAR SING OOGLE SETTINGS TECHNICAL SPECIFICATIONS: TROUBLESHOOTING AND WARRANTY INFORMATION...
SAFETY General Statement on RF Energy The phone is a low-power radio transmitter and receiver. When switched on it intermittently transmits radio frequency (RF) energy (radio waves). The transmit power level is optimized for best performance and automatically reduces when there is good quality reception.
Product Safety Information Please read all instructions This device may produce before use bright or flashing lights Do not use while driving Do not dispose of in fire Avoid contact with Do not use while re-fuelling magnetic media Small parts may be a Avoid Extreme choking hazard Temperatures...
Page 6
Obey warning signs in Do not attempt to hospitals and medical disassemble facilities Do not rely on this device Switch off when flying for emergency communications Switch off in explosive environments This device has been certified by the Wi-Fi Alliance. - microSD™...
Key Definitions Function Hold down to power on your phone. Power Key Press to switch to sleep mode. Press to wake up. Hold down for phone options: Silent mode, Flight mode or Power off. Home Key Press to return to the Home Screen from any screen. Hold down to see the recently used applications.
Page 9
Function Press to End a call. Press to Exit. End Key Hold for Profile options the same as the Power Key. Volume Use to control the volume Up and Down Keys...
Insert your SIM card Power off your phone before inserting the SIM, or memory card. 1. Remove the battery cover: 2. Insert your SIM card carefully into the SIM slot as shown above.
3. The handset supports microSD memory cards up to 32GB. If you wish to expand the device memory then insert as shown above (optional). 4. Insert the battery with the gold contacts located against the gold springs. 5. Replace the battery cover and press it gently until it clicks into place.
The phone can also be charged by connecting it to a computer using the USB lead supplied. A sound is played when the charger or USB cable is plugged in. The phone can be charged in the ON or OFF state: When switched OFF the charging icon is displayed.
Page 13
Normal charge time is 3-4 hours. Do not leave on charge for more than 24hrs. After 2-3 charge / discharge cycles the battery life will improve. From then on use top up charging to recharge frequently and always charge promptly when flat. ...
Page 14
Power On & Off 1. Make sure that your SIM card and battery are inserted. 2. Press the Power Key on the top to power on your handset. To power off your handset, press and hold the Power Key select Power off > OK. Wake up from sleep mode 1.
Page 15
Create or Log in to a Google Account We recommend you log in or create a Google account to enable on line services such as Email, Market and to protect your handset and data in case of loss or theft. Follow the on screen wizard to create your Google account or scroll down to skip.
Page 16
Using the Touch Screen Controls The touch screen controls change dynamically depending on the tasks you are performing: 1. Tap buttons or icons to select the function or open applications. 2. Hold an item for options related to that function. 3.
The Home Screen Slide the Home Screen left or right to view additional pages. Tap and hold to add Shortcuts, Widgets, Folders etc.
Page 18
Press the Menu Key to view the Home Screen Options: Add – widgets and shortcuts Search – open Google search Manage apps – view all installed Notifications – view apps notifications panel Wallpaper – set background Settings – device image Settings...
Page 19
Add or remove icons 1. Long press any icon in Apps to save it to the desktop. Tap and hold the icon to move. 2. Drag the item to release to delete it from the Home Screen. Example, Add the Power Control Widget 1.
Page 20
3. Tap Widgets, scroll down and tap Power Control to add 4. The power control widget is added to chosen page. Tap each button to control the related functions:...
Phone Status and Notification Icons Status Icons Data connected Signal strength Data in use Flight mode Battery is very low No signal Battery is low Roaming Battery is full Speaker is muted Battery is charging Microphone is muted Speaker mode is on Vibrate mode enabled...
Page 22
Bluetooth is on USB connected GPS is on Connected to a Wi-Fi network Alarm is set Headset connected No SIM card installed...
Notification Icons New Email Problem with SMS or MMS delivery New SMS New instant message New MMS Upcoming event New voicemail Song is playing Missed call Downloading data Call in progress Uploading data More notifications Call on hold Call forwarding on...
Page 24
The Notifications Panel The Notifications Panel at the top of the Home Screen shows useful device and status information. Pull down the bar at the top of the display to view the notifications panel: You can also open the Notifications Panel from the Home Screen by tapping Menu >...
Page 25
Multi-Tasking Run multiple applications simultaneously. Press the Home key from any application to launch, open or view something else. The original application will be suspended until you return to it. Applications and Settings to access Applications. Scroll down to see more...
Installing Applications Tap Market from the Home Screen to download and install applications from the Android Market. Select the item and tap Install. install non-Market applications Settings > Applications > Unknown sources. Uninstall third-party applications 1. Tap Home > Menu >...
Page 27
Word, Excel and Adobe PDF. First time use requires registration. Settings Tap Menu > Settings from the Home Screen to view Settings:...
Settings Menu: Wireless & Manage Wi-Fi, Bluetooth, Mobile networks, networks Virtual Private Networks & Flight mode. Call settings Set up fixed dial numbers, voicemail, call forwarding, call waiting, and caller ID etc. Sound Sound levels, ringtones, notifications, vibrate. Display Brightness, screen timeout, orientation etc. Location &...
Page 29
Storage Check memory status. Mount or unmount the SD card. Language & Set the language and keyboard options. keyboard Voice input & Manage voice input and text to speech options. output Accessibility Download a screen reader application Date & time Set the date, time, time zone, and date/time format.
Page 30
Open recently used applications Hold the Home Key from any screen to view the recently used applications:...
PHONE CALLS Making Calls Make a Call from the Dialer 1. Enter numbers directly using the number keys or press the Call Key from the home screen to open the dialer. 2. Enter the phone number. Tap to delete numbers, hold this key to clear all digits.
Make a Call from Contacts 1. Tap from the Home Screen. Contacts are displayed in alphabetical order. 2. Slide your finger to scroll through your Contacts list. 3. Tap to select the Contact then tap to call. Tips: to search for a Contact. Press on the right hand side of the Contacts list to use the scroller to scan through your Contacts.
Page 33
Make a Call from Call Log 1. Press the Call Key from the home screen to open the Dial pad. 2. Tap to open the Call Log. 3. Scroll and tap the required number. Tap to start the call You can also open your Call Log by tapping >...
2. Tap the number required then tap 3. Press the End Key to end the call. Making a Conference Call You can make a conference call between yourself and two or more other parties. 1. Call the first number. 2. While you are connected, tap Menu >...
Turn the Speaker On/Off (Handsfree) Tap Menu > Speaker during a call. The speakerphone icon is displayed. Making an Emergency Call 1. Press the Call Key from any screen to open the Dial pad. 2. Enter the Emergency Number for your location and tap Call. It is possible to dial emergency numbers when the SIM card is not inserted.
Making an International Call 1. Press the Call Key to open the Dial pad. 2. Press the “+” key to add the International Dialling Prefix 3. Enter the full phone number. 4. Tap to make the call. 5. Press the End Key to end the call.
Receiving Calls Answer an Incoming Call When there is an incoming call, the phone will display the information on the screen: Drag down to answer the call: Reject an Incoming Call Drag up to reject the call.
Page 38
Place a Call on Hold During a call tap Menu > Hold to place the call on hold. icon is displayed. If you are already on a call and accept a new call, the first call will be put on hold automatically. Tap Swap to switch between the two calls.
Call Settings From the Home Screen press Menu > Settings > Call settings: Fixed Restrict outgoing calls to a fixed set of numbers. Dialing This requires support from your network provider Numbers and the SIM PIN2 code. Voicemail Select a voicemail service provider. service Voicemail Specify a voicemail number.
Page 40
Caller Send or block your number in outgoing calls. Additional settings Call Hear pips to indicate an incoming call waiting while on Call waiting a call. Accounts Add SIP accounts using internet dialling Use Internet Set Internet calling options calling...
CONTACTS Contacts can be stored on the SIM card or phone. Synchronise your contacts on to your Google account or save a copy on your microSD™ card. Contacts stored on the phone provide more fields to enter information such as a photo, home address, email, etc.
Page 42
Importing / Exporting Contacts You can import or export contacts to and from your SIM card or microSD™ card. Tap Home > to enter the Contacts Screen. Import / export contacts to the SIM card 1. Tap Menu > Import / Export from the Contacts Screen. 2.
Create a New Contact 1. Tap Menu > New contact from the Contacts Screen. 2. Select the location to save your contact – If the Contact is stored on the phone (local) then you can add a photo and extra fields such as email, home address etc.
Search Contacts 1. Tap Contacts > Search 2. Input the name to search for. The matching contacts will be listed. Edit a Contact 1. Select the contact from the Contacts Screen. 2. Tap Edit the contact. 3. Edit the contact and tap Done. Delete a Contact 1.
Page 45
Save a Contact from a Message 1. Tap Home > and tap the thread that contains the phone number you wish to save. 2. Tap Menu > more > Add to Contacts 3. Complete the Contact details and tap Done to save Set a dedicated Ringtone 1.
MESSAGES SMS and MMS Messages Tap Home > to access SMS and MMS messages. Unread message(s) will display for SMS or for MMS in the status bar. Open new messages from the Notifications Panel or the Messaging Screen. Tap the message to read it. Composing an SMS 1.
3. Tap Type to compose and enter the content of your SMS. 4. Tap Send to send your SMS. Composing an MMS 1. Tap Home > > New message 2. Tap the To field to enter the recipient‟s number. You can also enter the first letters of their name to display matching Contacts and select a recipient from the list or tap to see...
Tips: Adding the Subject or Attachments will convert the message from SMS to MMS. Tap Menu > Add subject to enter the subject if required. Tap Type to compose to enter text content if required. Forwarding a Message Tap and hold the individual message to get further options such as Forward, Delete, View message details etc.
Reply to a message 1. Tap the message you want to reply to from the Messaging Screen. 2. Tap Type to compose and enter the contents of your message. 3. Tap Send. Access Draft Messages Tap Messages > Menu > Draft to view your draft messages, if you have any.
You can also delete a message by opening it from the Messaging Screen and tapping Menu > Delete messages. Message Settings Tap Messages > Menu > Settings to configure message settings: Storage settings Notifications settings SMS Settings Signature settings MMS Settings Multiple SMS Message Charging: A standard SMS message can contain up to 160 characters.
Using MyEmail MyEmail is a subscription based Email service provided by Telstra. Tap Home , flick to your far left hand desktop > MyEmail. Alternate Email providers can be accessed via the internet or you can use the built in Gmail application. Composing and sending an Email After creating an Email account, compose and send Emails: 1.
3. Enter the subject and the content of your Email. 4. Tap Send. Reply to or Forward an Email 1. Open the Email to reply to or forward from the Email Screen. 2. Tap Reply, Reply all or Menu > Forward. 3.
Page 53
Notification settings Email notifications: Enable status bar notification for new Email Select ringtone: Select the ringtone for incoming Email notification. Vibrate: Enable vibrate with ringtones when Email arrives. Server settings Incoming settings: Set the incoming server settings. ...
GETTING CONNECTED Connecting to the Internet You can access the Internet through the mobile network or via Wi-Fi. Your mobile network settings are pre-configured by your service provider and there is no need to change any settings. If you wish to disable your internet access talk to your service provider.
Page 55
Connect to a Wi-Fi network 1. Tap Home > Menu > Settings > Wireless & networks > Wi-Fi settings. The available Wi-Fi networks are displayed. 2. Tap a network to connect. An open network will automatically connect If you select a secured network you need to enter a password. Check the Wi-Fi network status 1.
Using the Browser You can use your Browser to visit most websites. Some web pages may not be displayed properly as some web technologies such as Flash are not supported. Tap the Google Quick Search box from the Home Screen and enter your search request using the keypad.
Browser Menu: > Menu to open the browser menu: Tap New window to open a new browser window. Tap Exit to close the browser, or multiple tabs and windows Tap Bookmarks to access your favourite sites Tap Windows to view or open multiple windows ...
Add a new bookmark 1. Open a web page. 2. Tap Menu > Bookmarks > Add 3. Enter a name of the bookmark and tap OK. Bookmarks are sorted by time with the latest at the top. Edit a bookmark 1.
Delete a bookmark 1. Open a Browser window. 2. Tap Menu > Bookmarks. 3. Select an item to delete and hold it until the menu pops up. 4. Select Delete bookmark and tap OK to confirm the deletion. Open links in web pages 1.
Share link: Send the link by Bluetooth, Email, Messaging etc. Copy link URL: Copy the link to the clipboard. Download applications from web pages 1. Open a web page that contains an application link. 2. Tap the link or hold on the link and select Save link to download the application to your phone.
Page 61
Block pop-up windows Enable JavaScript Load images Enable plug-ins Auto-fit pages Open in background Landscape-only display Set home page Privacy settings • Clear cache • Remember form data • Clear history: • Clear form data •...
Page 62
Advanced settings • Set search engine • Reset to default • Website settings...
Bluetooth Bluetooth enabled devices can exchange information within a distance of about 10 meters without any physical connection. The Bluetooth devices must be paired to share information. Turning Bluetooth on or off 1. Tap Home > Menu > Settings > Wireless & networks. 2.
Make your device visible to other devices 1. Tap Home > Menu > Settings > Wireless & networks > Bluetooth settings. 2. Select the Bluetooth check box to turn on. 3. Select the Discoverable check box to make your device visible. Change your device name 1.
Pair with another Bluetooth device Both devices must have Bluetooth turned on. 1. Tap Home > Menu > Settings > Wireless & networks > Bluetooth settings. 2. Tap Scan for devices to display available devices in your vicinity. 3. Tap the device to pair with and enter your PIN if required. The same PIN should be used on both devices.
Connect to a Computer Copy files between the phone and any computer using the USB lead supplied. Select Turn on USB storage when prompted to connect your microSD™ memory card to the computer. Browse your computer to see the connected drive as an external storage device.
Page 67
Use the Join Me Connection Suite to Synchronise your Phone The Join Me installation file (JoinMe_PCclient.exe) can be found on the SD memory card (in the root folder) on your phone. 1.Connect phone to the PC using the supplied USB data lead. 2.“USB debugging”...
Page 68
5.The SD memory from your phone will appear as a removable drive in your file manager (My Computer) in Windows. 6.Double click “JoinMe_PCclient.exe” to start Join Me installation, and follow the prompts. Keep your phone connected during installation. 7.Press the Connect button to start using Join Me. Press “OK” and allow a few seconds to connect.
Page 69
The software should be installed and run with the Administrator login. Please install the software before connecting your phone and follow the installation steps carefully. Join Me Feature Summary SMS: Create, send, receive and save SMS messages from Messages your computer using Join Me.
Page 70
View Android applications installed on your phone as well Manager as manage (backup and install) Android applications between your phone and computer. Calendar Manage your calendar appointments and reminders using Join Me as well as synchronise with your PC (Outlook, CSV, Vcard, XML file).
Page 71
Bookmarks Manage URL favourites on your phone via Join Me as well as add, import, export, delete bookmarked web links between your phone and computer. Call View your entire call history and call details (name, Record duration, time of call etc), from your phone using your computer.
Taking Pictures Line up your shot and tap to take the picture. Tap the icon in the right corner of your screen to view the picture. Tap Menu > Gallery to view all of your pictures. Camera Settings Tap the icons on the left of the screen to adjust camera settings: ...
Video Recorder Tap Home > > Camcorder to open the camcorder. Switch from the camcorder to camera mode using the selector switch on the screen Shooting Videos 1. Tap to start shooting. 2. Tap to stop shooting. Notes: Tap the icon in the right corner to view the last video clip. ...
Video Settings Tap the icons on the left of the screen to adjust video settings. Scroll up or down to see the full menu list: Colour Effect / Video quality / Video Encoder / Video duration / Restore defaults. ...
Page 76
FM Radio Your phone includes an FM radio. The wired headset works as an antenna, so always connect the headset when using the radio. If you receive an incoming call while listening to the radio, the radio will be suspended. Open the FM Radio Insert the headset and Tap Home >...
Page 77
4. Press Volume Keys to adjust the volume. 5. Tap Menu > Sleep to set the FM radio sleep timer. 6. Tap to turn off the FM radio.
Music You need to have audio files stored on your memory card. Use downloads, Bluetooth or PC Connectivity to save files onto your memory card. 1. Tap Home > > Music to open Music application. 2. Select a file to open from the Artist, Album or Song folders. Creating Playlists 1.
Managing Playlists 1. Tap Playlist from the Music Screen to view all playlists. 2. Hold on the playlist you want to play or edit until a shortcut menu pops up. Tap Play to play the playlist. Tap Delete to delete the playlist. ...
Page 81
Videos Tap Home > > Videos to open the video player. 1. Tap the video file you want to play from the Videos Screen. 2. Tap on the screen to show the control bar.
Page 82
Gallery Use Gallery to view pictures and play back videos. You can also set pictures as wallpaper, contact icons and share them with your friends.
Sound Recorder Sound Recorder enables you to record your voice memos that you can also set as a ringtone. Tap Home > > Sound Recorder. Record Your Memo 1. Hold the phone so the microphone is near your mouth. 2. Tap to start, to stop and to play back.
GOOGLE APPLICATIONS Sign In or Create Your Google Account Sign in to your Google Account to synchronize Gmail, Calendar, and Contacts between your phone and the web. 1. Tap a Google application, such as Talk or Market. 2. Follow the instructions in the wizard and tap Next. 3.
Create and send an Email 1. In the Inbox, press Menu and then tap Compose. 2. Enter email address in the To field. If you are sending to several recipients, separate the addresses with a comma. You can add as many recipients as you want. 3.
Using Google Talk Google Talk is Google‟s instant messaging program, which enables you to communicate with other people that also use Google Talk. Open Google Talk Tap Home > > Talk. Add a new friend You can only add people who have a Google Account. 1.
View and accept an invitation 1. In the Friends list, press Menu > More > Invites. All chat invitations you have sent or received are listed on the pending invitations screen. 2. Tap a pending invitation, and then tap Accept or Cancel. Change your online status 1.
Page 88
SETTINGS Select Flight Mode, turn on Wi-Fi, manage Wi-Fi Wireless & settings, Bluetooth, Tethering and portable networks hotspot, VPN settings, mobile networks to configure data access Manage Fixed Dialling Numbers, Voicemail, Speed Call dial, Call Barring, call forwarding, Additional Settings settings for caller ID, Call Waiting.
Page 89
select device administrators, Use secure credentials, Install from SD card, Set password, clear credentials. Unknown sources, Quick Launch, Manage Applications applications, Running services, Storage use, Battery use, Development Accounts & Background data, Auto-sync. sync Back up my data, Automatic restore, Factory data Privacy reset Storage...
Page 90
Automatic, Set date, Set time zone, Set time, Date & time 12/24hr, Select date format. About System updates, Status, Battery use, Legal phone information, model, build & version details. Screen Unlock Pattern, PIN, or Password Protect your phone from unauthorized use by creating a personal screen unlock pattern, PIN or Password.
5. Draw the pattern again and tap Confirm. Note If you forget your unlock pattern, PIN or Password then after five incorrect entries press Forgot Pattern to enter your Google account password. If you do not have a Google account then contact your service provider.
Page 92
If you forget the unlock pattern then after five attempts you can enter your Google account details to unlock your device. If you have not registered a Google account then contact your service provider. SIM Card Lock Set a PIN code on your SIM card to prevent others from using your account.
Change SIM PIN Before changing SIM PIN, you need to enable it. 1. Tap Home > Menu > Settings > Location & security > Set up SIM card lock. 2. Tap Change SIM PIN. 3. Enter the PIN and tap OK. 4.
TROUBLESHOOTING AND WARRANTY INFORMATION Please check the manual thoroughly before contacting your service provider. Symptom Solution Hold the power key to check the phone is No incoming ring not in silent mode. or alarm tone Check the ring tone and ring volume settings.
Page 96
Symptom Resolution A phone number Check for network coverage cannot be Check you have Voice enabled on your plan. dialled Check you have an active account or credit. I cannot connect Check for network coverage. Check you to the internet have a valid data SIM with available credit.
Page 97
Symptom Resolution Check the network signal strength. With only 1 or 2 bars, the battery has to work harder to maintain network contact. The battery Switch off Wi-Fi, Bluetooth & GPS if you discharges are not using them. quickly Tip: You can add the power management widget to your home screen to easily switch off functions.
Error Messages Message Solution Check a valid SIM card is inserted. No SIM Card Introduction See the section You have set a SIM PIN. Please enter your Enter PIN code SIM PIN code. Contact your Service Provider to get the Enter PUK code PUK code Contact your Service Provider to obtain...
Warranty Information The warranty does not apply to defects or errors caused by: (a) Normal wear and tear (b) Misuse including mishandling, physical damage, improper installation – including battery, and unauthorised disassembly of the product. (c) Water, exposure to solvents or any other liquid damage. (d) Any unauthorised repair or modification.
