Summary of Contents for ENERGY SISTEM Book 4050
- Page 1 User Manual...
- Page 2 Contains Reader® Mobile technology by Adobe Systems Incorporated. Due to continuous updates on the product, all figures in this manual are only for reference, the actual item is the standard.
-
Page 3: Device Buttons
1. QUICK GUIDE 1.1. DEVICE BUTTONS Power button Press this button to turn on/off the device. The red indicator will light when the device is charging, and the blue indicator will light when the device is operating. Page up button Click this button turn page up. Page down button Click this button to turn page down. - Page 4 ≥ Play/record button Open or close the “Recorder and Player” interface. ≥ Zoom button (Z) Press this button to zoom in/out the text or pictures. ≥ MENU button Press this button, function menu will display, press direction button or number button to select and operate the corresponding function.
- Page 5 ≥ Do not place the reader near devices that emit strong magnetic fields. It may cause data damage or loss. ≥ Do not place the reader near devices that emit strong magnetic fields. ≥ It may cause data damage or loss. ≥...
-
Page 6: Reading Interface
2.2. READING INTERFACE The screen is separated into 3 parts: ≥ Status Area: Displays the menu icon, title, battery status, microSD presence, time and “ESC” (equivalent to pressing key). ≥ Reading area: function list, file list, text or pictures will display at this area. ≥... -
Page 7: Page Turning
3. BOOKCASE 3.1. BOOK READING Select “Bookcase” and press “OK” step by step to select one book finally, and then press OK to confirm or press the corresponding number button to open the book directly. 3.2. PAGE TURNING Press the direction buttons to turn pages, you can also press the page up/down button. 3.3. PAGE JUMPING Under the reading status, press any number button, and then press “OK”... - Page 8 3.4. ZOOM Press zoom button (Z) to adjust the font size in 3 levels: small, middle and large. 3.5. REMARK / EXTRACT ≥ Remark: To turn it on press “MENU” and select “Remark” to clear select delete comments and you can select between delete made annotations on the page where is and delete all comments made in the book.
-
Page 9: Picture View
Note: The bookmarks will be sorted by date; only the recent 5 bookmarks can be shown. In the image files, only shift bookmark can be added. 4. PICTURE VIEW 4.1. PICTURE VIEW Select “Picture View” in the main menu and press “OK” Browse and select folders and files, then click “OK”... -
Page 10: Voice Notes
≥ Play/Pause: Press the number button “1” to play/pause music or record, and a speaker icon will appear at the status area. ≥ Record: Press the number button “2” to record, and a microphone icon will appear at the status area. - Page 11 6. NOTEPAD Select “Notepad” in the main menu to enter the notetaking function. Click and switch the input method to “Keypad” inputting. Click again and switch the input method to “handwriting”. All remarks on the screen will be cleaned. Click the input area will disappear. Click anywhere on the screen again, the input area will display.
-
Page 12: Secondary Function
6.3. SECONDARY FUNCTION Candidate words: If the word recognized wrong, please choose the right English word in the candida- te words area. Associated words: In the input area, the associated words will appear. You could select the right word directly. Click the arrow buttons located at the side of the input area will get more associated words. Handwriting sign: There are some signs for controlling the handwriting. -
Page 13: Handwriting Input
to select the corresponding option. You can also press the number buttons to select the function. 8.1. CONTINUOUS TURNING Activate/deactivate continuous turning for pictures, HTML and TXT file types. For pictures continuous turning means that you can view the next/previous picture without the need to return to the file browser. -
Page 14: System Maintenance
≥ Default: Restore the system to the default settings. Please save all data on the SD card before you restore the system. ≥ Clear temp: Erase the temporary files in the system including bookmarks. ≥ Clear remark: Erase the remarks made within the file types that support this feature. 8.9. SYSTEM MAINTENANCE Download the update package, decompress the package and save it under the root directory in SD card, select “Update”, the system will operate the software updating automatically. -
Page 15: Other Operations
a new SD card. After activated, if you want to use a new account to active, please delete the hidden folder under SD root ”.adobe-digital-editions”. Please refer to below website for more information. http://www.adobe.com/products/digitaleditions 10. OTHER OPERATIONS 10.1. BATTERY CHARGING We recommend that you do a full battery charge before first use, because it may not be enough charge on the device to perform normal operations. -
Page 16: Specifications
10.2.2. File management From your PC browser you can copy, delete, and organize the files or folders. When you connect your E-book reader will be blocked. Factory adjustment came from multiple folders on the memory card: e_audio, e_book, e_image, save the files in the folder corresponding and respectively. The microSDcard is the storage media for the device, so everything (books, documents, music) should be stored in the memory card. -
Page 17: About Sd Card
Storage temperature: -4 to 113 degrees F (-20 to 55 degrees C) Power Consuming Less than 200mA@3.3v at EPD refresh time Less than 2.0mA@3.3v at sleep time. It can show more than 8000 pages continuously with full charged battery. 11.1. ABOUT SD CARD If SD card can’t be recognized for a long time, you can plug in the SD card again or restart the device. -
Page 18: Warranty Procedure
Energy Sistem Soyntec S.A. warrants its products to be free from defects in materials and workman- ship at the time of purchase. The warranty period is 36 months from the date of purchase. 11.4. WARRANTY PROCEDURE ≥ Visit the Support section at http://support.energysistem.com and select your product to view the FAQ (Frequently Asked Questions).
