Page 1 Challenger 2 0 1 0 O W N E R ’ S M A N U A L...
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 4 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 6 INTRODUCTION 5...
Page 7: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.
Page 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Vehicle Security Alarm ....18 ▫...
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ To Open The Trunk ....24 Trunk Lock And Release ....34 ▫...
Page 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Supplemental Restraint System (SRS) - ▫ Transporting Passengers ....71 Airbags ......47 ▫...
Page 13: Things To Know Before Starting Your Vehicle
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN) Your vehicle uses a keyless ignition system. This system The Wireless Ignition Node (WIN) operates similar to an consists of a Key Fob with Remote Keyless Entry (RKE) ignition switch.
Page 14: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
Page 15: Understanding Your Instrument Panel
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Removing Key Fob From Ignition at the top of the Key Fob sideways with your thumb and Place the shift lever in PARK. Turn the Key Fob to the then pull the key out with your other hand.
Page 16: Starting And Operating
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 WARNING! Key-In-Ignition Reminder Opening the driver’s door when the Key Fob is in the • Never leave children alone in a vehicle. Leaving ignition and the ignition switch position is OFF or ACC, unattended children in a vehicle is dangerous for a sounds a signal to remind you to remove the Key Fob.
Page 17: Sentry Key
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SENTRY KEY bulb check, it indicates that there is a problem with the The Sentry Key Immobilizer System prevents unauthor- electronics. This condition will result in the engine being ized vehicle operation by disabling the engine. The shut off after two seconds.
Page 18: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Replacement Keys Duplication of Key Fobs may be performed at an autho- rized dealer, this procedure consists of programming a NOTE: Only Key Fobs that are programmed to the blank Key Fob to the vehicle electronics. A blank Key Fob vehicle electronics can be used to start and operate the is one that has never been programmed.
Page 19: Vehicle Security Alarm
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device must accept any interference that may be off after three minutes, turn all of the visual signals off received, including interference that may cause unde- after 15 minutes, and then the Vehicle Security Alarm will sired operation.
Page 20: To Disarm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 • The Vehicle Security Alarm remains armed during Vehicles Equipped with Keyless Enter-N-Go Press the Keyless Enter-N-Go Start/Stop button until the trunk entry. Pressing the TRUNK button will not Electronic Vehicle Information Center (EVIC) indicates disarm the Vehicle Security Alarm.
Page 21: Illuminated Entry
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE exterior lights will flash, and the horn will sound. If this The lights will fade to off after approximately 30 seconds occurs, disarm the Vehicle Security Alarm. or they will immediately fade to off once the ignition switch is placed in ON/RUN from the OFF position.
Page 22: To Unlock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 at speeds 5 mph (8 km/h) and above disables the system within five seconds, to unlock both doors. The turn signal from responding to all RKE transmitter buttons for all lights will flash to acknowledge the unlock signal. The RKE transmitters.
Page 23 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When not using the EVIC, perform the following 3. Test the feature while outside of the vehicle by press- ing the LOCK/UNLOCK buttons on the RKE transmitter steps: with the ignition switch in the OFF position and the Key 1.
Page 24: To Lock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Alarm. Opening a door with the Security Alarm activated Information Center (EVIC)/Personal Settings (Customer- will cause the alarm to sound. Press the UNLOCK button Programmable Features)” in “Understanding Your In- to deactivate the Security Alarm. strument Panel”...
Page 25: Remote Open Window Feature
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Pressing the LOCK button on the RKE transmit- least one second and release. When the Panic Alarm is on, ter while you are in the vehicle will activate the Security the headlights and park lights will flash, the horn will Alarm.
Page 26: Programming Additional Transmitters
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 Programming Additional Transmitters Avoid touching the new battery with your fingers. Skin Programming Key Fobs or RKE transmitters may be oils may cause battery deterioration. If you touch a performed at an authorized dealer. battery, clean it with rubbing alcohol.
Page 27: Remote Starting System
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Changes or modifications not expressly ap- How To Use Remote Start proved by the party responsible for compliance could All of the following conditions must be met before the void the user’s authority to operate the equipment. engine will remote start: •...
Page 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 NOTE: WARNING! • If an engine fault is present the vehicle will start and • Do not start or run an engine in a closed garage or then shut down 10 seconds later. confined area.
Page 29 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Exit Remote Start Mode without Driving the NOTE: • For vehicles not equipped with Keyless Enter-N-Go Vehicle feature, the ignition switch must be in the ON/RUN • Press and release the REMOTE START button one time position in order to drive the vehicle.
Page 30: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 DOOR LOCKS If the door lock knob is down when you shut the door, the door will lock. Therefore, make sure the key is not Manual Door Locks inside the vehicle before closing the door. To lock each door, push the door lock knob on each door trim panel downward.
Page 31: Power Door Locks
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks locks will not operate. This prevents you from acciden- The power door lock switch is located on each door trim tally locking the Key Fob in the vehicle. Removing the panel.
Page 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 6. The doors were not previously locked using the power 6. The vehicle speed is 0 mph (0 km/h) door lock switch or Remote Keyless Entry (RKE) Automatic Unlock Doors on Exit Programming transmitter The Automatic Unlock Doors On Exit feature can be Automatic Door Locks —...
Page 33: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Within 30 seconds, press the power door UNLOCK switch to unlock the doors. 5. A single chime will indicate the completion of the programming. NOTE: If you do not hear the chime, it means that the system did not enter the programming mode and you will need to repeat the procedure.
Page 34: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 NOTE: To open the window part way, press the window switch • The door window will lower slightly if it is closed to the first detent and release it when you want the completely when opening the door.
Page 35: Trunk Lock And Release
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE open or partially open positions. This is a normal occur- The trunk lid can be released from rence and can be minimized. If the buffeting occurs with outside the vehicle by pressing the one window open, then open the other window to Trunk Release button on the Re- minimize the buffeting.
Page 36: Trunk Safety Warning
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 TRUNK SAFETY WARNING Trunk Emergency Release WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended.
Page 37: Occupant Restraints
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS If you will be carrying children too small for adult-sized Some of the most important safety features in your seat belts, the seat belts or the Lower Anchors and Tether vehicle are the restraint systems: for CHildren (LATCH) feature also can be used to hold infant and child restraint systems.
Page 38: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 of ejection and the risk of injury caused by striking the WARNING! inside of the vehicle. Everyone in a motor vehicle should be belted at all times. In an accident, you and your passengers can suffer much greater injuries if you are not properly buckled Lap/Shoulder Belts up.
Page 39 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Wearing your belt in the wrong place could make • It is dangerous to ride in a cargo area, inside or your injuries in an accident much worse. You outside of a vehicle.
Page 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 2. The seat belt latch plate is contacting the seat when the 3. When the belt is long enough to fit, insert the latch belt is routed through the seat web guide. When the belt plate into the buckle until you hear a “click.”...
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt that is buckled into the wrong buckle will Your body could strike the inside surfaces of the not protect you properly.
Page 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 4. Position the lap belt across your thighs, below your 5. Position the shoulder belt on your chest so that it is abdomen. To remove slack in the lap belt portion, pull up comfortable and not resting on your neck.
Page 43: Lap/Shoulder Belt Untwisting Procedure
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. 1. Position the latch plate as close as possible to the The belt will automatically retract to its stowed position. anchor point.
Page 44: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 When To Use The Automatic Locking Mode Energy Management Feature Use the Automatic Locking Mode anytime a child safety This vehicle has a safety belt system with an Energy seat is installed in a seating position that has a belt with Management feature in the front seating positions to help this feature.
Page 45: Seat Belt Pretensioners - If Equipped
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners — If Equipped Enhanced Seat Belt Use Reminder System The seat belts for both front seating positions may be (BeltAlert ) equipped with pretensioning devices that are designed to If the driver’s or front passenger’s (if equipped with belt remove slack from the seat belt in the event of an alert) seat belt has not been buckled within 60 seconds of...
Page 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 front passenger seat is unoccupied. The BeltAlert warn- 2. Turn the ignition switch to the ON/RUN position, but ing system may be triggered when an animal or heavy do not start the engine. Wait for the Seat Belt Reminder object is on the front passenger seat or when the seat is Light to turn off and then proceed to the next step.
Page 47: Seat Belts And Pregnant Women
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The BeltAlert can be reactivated by repeating this pro- Seat Belt Extender cedure. If a seat belt is too short even when fully extended your authorized dealer can provide you with a seat belt NOTE: When the BeltAlert is deactivated, the Seat Belt extender.
Page 48: Supplemental Restraint System (Srs) - Airbags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Supplemental Restraint System (SRS) - Airbags This vehicle has Advanced Front Airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s Advanced Front Air- bag is mounted in the center of the steering wheel.
Page 49 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Airbags have a multistage inflator NOTE: • Airbag covers may not be obvious in the interior trim; design. This allows the airbag to have different rates of inflation based on the severity and type of collision. but they will open during airbag deployment.
Page 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • Supplemental Side Airbag Inflatable Curtains (SABIC) WARNING! • Front and Side Impact Sensors • No objects should be placed over or near the • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, airbag on the instrument panel, because any such and Seat Track Position Sensors objects could cause harm if the vehicle is in a...
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not mount any accessories to the knee bolster such as alarm lights, stereos, citizen band radios, etc. Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped SABIC airbags may offer side-impact and vehicle rollover protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 • Being too close to the SABIC airbags during deploy- Knee Impact Bolsters ment could cause you to be severely injured or killed. The Knee Impact Bolsters help protect the knees of the The system includes side impact sensors adjacent to both driver and the front passenger, and position front occu- front and rear seat occupants that are calibrated to deploy...
Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a child from 1 to 12 years old (not in a rear facing child WARNING! seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint. Infants in rear-facing child restraints should never (Refer to “Child Restraints”) ride in the front seat of a vehicle with a passenger...
Page 54: Airbag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 If the airbag system in this vehicle needs to be modified WARNING! (Continued) to accommodate a disabled person, contact the Customer • Being too close to the steering wheel or instrument Center. Phone numbers are provided under If You Need panel during Advanced Front Airbag deployment Assistance .
Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ORC deploys the Advanced Front Airbags, SABIC air- The side airbags will not deploy in all side collisions. Side bags — if equipped, and front seat belt pretensioners — airbag deployment will depend on the severity and type if equipped, as required, depending on the severity and of collision.
Page 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The ORC contains a backup power supply system that WARNING! may deploy the airbags even if the battery loses power or it becomes disconnected prior to deployment. Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to Also, the ORC turns on the Airbag Warning protect you in a collision.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE wheel hub trim cover and the upper right side of the A quantity of non-toxic gas is generated to inflate the side instrument panel separate and fold out of the way as the curtain airbag.
Page 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 • Turn on the interior lights, which remain on as long as Front and Side Impact Sensors In front and side impacts, impact sensors can aid the the battery has power or until the ignition key is ORC in determining appropriate response to impact removed.
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE floor. They are not caused by contact with chemicals. Do not drive your vehicle after the airbags have de- They are not permanent and normally heal quickly. ployed. If you are involved in another collision, the However, if you haven’t healed significantly within a airbags will not be in place to protect you.
Page 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Maintaining Your Airbag System WARNING! (Continued) • Do not attempt to modify any part of your ad- WARNING! vanced airbag system. The airbag may inflate • Modifications to any part of the airbag system accidentally or may not function properly if modi- could cause it to fail when you need it.
Page 61: Event Data Recorder (Edr)
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light check the fuse block for blown fuses. Refer to the label You will want to have the airbags ready to located on the inside of the fuse block cover for the inflate for your protection in a collision.
Page 62: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 • How far (if at all) the driver was depressing the such as law enforcement, that have the special equip- accelerator and/or brake pedal; and, ment, can read the information if they have access to the vehicle or the EDR.
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants and Child Restraints WARNING! • Safety experts recommend that children ride In an collision, an unrestrained child, even a tiny rearward-facing in the vehicle until they are at least baby, can become a projectile inside the vehicle. The one year old and weigh at least 20 lbs (9 kg).
Page 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 The belt-positioning booster seat is for children weighing WARNING! more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit Rearward-facing child seats must never be used in with knees bent over the vehicle’s seat cushion while the the front seat of a vehicle with the front passenger...
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Check belt fit periodically. A child’s squirming or WARNING! slouching can move the belt out of position. • Improper installation can lead to failure of an • If the shoulder belt contacts the face or neck, move the infant or child restraint.
Page 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Here are some tips on getting the most out of your child Do not leave it loose in the vehicle. In a sudden stop or restraint: accident, it could strike the occupants or seatbacks and cause serious personal injury.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE available for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle.
Page 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Again, carefully follow the installation instructions that means of adjusting the tension in the strap. Forward- are provided with the child restraint system. facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a The rear seat lower anchorages are round bars hook for attachment to the tether strap anchorage and a located at the rear of the seat cushion where it...
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in Improper installation of a child restraint to the the strap. LATCH anchorages can lead to failure of an infant or child restraint.
Page 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 then allow the belt to retract into the retractor. For additional information on ALR, refer to “Automatic Locking Mode”. To install a child restraint, first, pull enough of the seat belt webbing from the retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.
Page 71: Maintaining Your Vehicle
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Ensure that the tether strap does not slip into the ENGINE BREAK-IN RECOMMENDATIONS opening between the seatbacks as you remove slack in A long break-in period is not required for the drivetrain the strap.
Page 72: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 CAUTION! WARNING! • Do not leave children or animals inside parked Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. vehicles in hot weather. Interior heat build-up may cause serious injury or death.
Page 73: Exhaust Gas
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas If you are required to drive with the trunk/liftgate open, make sure that all windows are closed and the climate WARNING! control BLOWER switch is set at high speed. DO NOT use the recirculation mode.
Page 74: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Safety Checks You Should Make Inside the Defroster Vehicle Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to Seat Belts feel the air directed against the windshield. See your Inspect the belt system periodically, checking for cuts, authorized dealer for service if your defroster is frays, and loose parts.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Al- Pedals that cannot move freely can cause loss of ways properly reinstall and secure floor mats that vehicle control and increase the risk of serious per- have been removed for cleaning.
Page 76: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Periodic Safety Checks You Should Make Outside Door Latches the Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 78: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ “Slide-On-Rod” And Extender Features Of Mirrors ......81 Sun Visor .
Page 79 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 113 Lights ......127 ▫...
Page 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 ▫ Flash-To-Pass ..... . . 131 ▫ To Deactivate ..... . . 138 ▫...
Page 81 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Security ......147 ▫ Sunroof Maintenance ....152 ▫...
Page 82: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 MIRRORS Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 83: Outside Mirrors
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirrors Outside Mirrors Folding Feature To receive maximum benefit, adjust the outside mirror(s) The mirrors are equipped with a rotational hinge. The to center on the adjacent lane of traffic and a slight mirrors have one detent (clockwise) towards the rear of overlap of the view obtained from the inside mirror.
Page 84: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Power Mirrors After selecting a mirror, move the knob in the same The power mirror switch is located on the driver’s door direction you want the mirror to move. Use the center off trim panel, next to the power door lock switch.
Page 85: Illuminated Vanity Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors “Slide-On-Rod” and Extender Features of Sun An illuminated vanity mirror is on the sun visor. To use Visor the mirror, rotate the sun visor downward and swing the To use the “Slide-On-Rod” feature of the sun visor, rotate mirror cover upward.
Page 86: Uconnect™ Phone - If Equipped
0.96 or higher. See the Uconnect™ website for supported phones. For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect Slide-On-Rod Extender Uconnect™ Phone — IF EQUIPPED • www.jeep.com/uconnect Uconnect™ Phone is a voice-activated, hands-free, in- • or call 1–877–855–8400 vehicle communications system.
Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone allows you to transfer calls between WARNING! the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s Any voice commanded system should be used only microphone for private conversation.
Page 88: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 The Uconnect™ Phone can be used with any Hands-Free menu structure. Voice commands are required after most Profile certified Bluetooth cellular phone. See the Uconnect™ Phone prompts. You will be prompted for a Uconnect™...
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phonebook and New Entry. Please remember, the Cancel Command Uconnect™ Phone works best when you talk in a At any prompt, after the beep, you can say Cancel and normal conversational tone, as if speaking to someone you will be returned to the main menu.
Page 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 • When prompted, after the beep, say Pair a Phone and phone to use if multiple cellular phones are in the follow the audible prompts. vehicle at the same time. For example, if priority three and priority five phones are present in the vehicle, the •...
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will confirm the phone number • The Uconnect™ system will confirm the name and and then dial. The number will appear in the display then dial the corresponding phone number, which of certain radios.
Page 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 • When prompted, enter the number designation (e.g., Phonebook Download – Automatic Phonebook Home, Work, Mobile, or Pager ). This will allow Transfer From Cellular Phone you to store multiple numbers for each phonebook If equipped and specifically supported by your phone, entry, if desired.
Page 93 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- Phonebook Download — Single Entry loaded, there may be a short delay before the latest If equipped and supported by your phone, Uconnect™ downloaded names can be used. Until then, if avail- Phone allows the user to download entries from their able, the previous downloaded phonebook is available phone via Bluetooth .
Page 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 • You will then be asked for the name of the phonebook first disconnect or drop the Bluetooth connection to the Uconnect™ Phone, and then send the address entry that you wish to edit. book entry via Bluetooth .
Page 95 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the name, the Uconnect™ Phone will Delete Uconnect™ Phonebook Entry ask you which designation you wish to delete: home, NOTE: Editing phonebook entries is recommended work, cellular, pager, or all. Say the designation you when the vehicle is not in motion.
Page 96: Phone Call Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 • Note that only the phonebook in the current language • The Uconnect™ Phone will then prompt you as to the is deleted. number designation you wish to call. • Automatic downloaded phonebook entries cannot be •...
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE call, press and hold the button until you hear a by the phone number or phonebook entry you wish to call. The first call will be on hold while the second call is single beep, indicating that the incoming call was in progress.
Page 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 Conference Call there is a call on hold, it will become the new active call. When two calls are in progress (one active and one on If the active call is terminated by the phone far end, a call hold), press and hold the button until you hear a on hold may not become active automatically.
Page 99: Uconnect™ Phone Features
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Uconnect™ Phone Features Call continuation is the progression of a phone call on the Language Selection Uconnect™ Phone after the vehicle ignition key has been To change the language that the Uconnect™ Phone is switched to OFF.
Page 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Emergency Assistance Canada and 060 for Mexico). The number dialed may If you are in an emergency and the cellular phone is not be applicable with the available cellular service reachable: and area. •...
Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance Paging If you need towing assistance: To learn how to page, refer to Working with Automated Systems. Paging works properly except for pagers of • Press the button to begin. certain companies, which time out a little too soon to •...
Page 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 When calling a number with your Uconnect™ Phone that The Uconnect™ Phone will then send the corresponding normally requires you to enter in a touch-tone sequence phone number associated with the phonebook entry, as on your cellular phone keypad, you can press the tones over the phone.
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF Dialing Using the Cellular Phone Keypad Turning confirmation prompts off will stop the system You can dial a phone number with your cellular phone from confirming your choices (e.g., the Uconnect™ keypad and still use the Uconnect™...
Page 104: Advanced Phone Connectivity
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Mute/Un-Mute (Mute OFF) from your Uconnect™ Phone paired cellular phone to the When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone or vice versa, press the button able to hear the conversation coming from the other and say Transfer Call.
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say List Phones. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect™ Phone will play the phone names of Uconnect™...
Page 106: Things You Should Know About Your Uconnect™ Phone
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Things You Should Know About Your Uconnect™ Repeat the words and phrases when prompted by the Phone Uconnect™ Phone. For best results, the Voice Training session should be completed when the vehicle is parked Uconnect™...
Page 107 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Speak normally, without pausing, just as you would • When navigating through an automated system such speak to a person sitting a few feet/meters away from as voice mail, or when sending a page, at the end of you.
Page 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 • In a convertible vehicle, system performance may be • Echo at the phone far end can sometimes be reduced compromised with the convertible top down. by lowering the in-vehicle audio volume. • In a convertible vehicle, system performance may be Phone Far End Audio Performance compromised with the convertible top down.
Page 109 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 114: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 115 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If you do not say a command within a few For example, if you are in the disc menu and you are seconds, the system will present you with a list of listening to FM radio, you can speak commands from the options.
Page 116: Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Commands In this mode, you can say the following commands: The Voice Command system understands two types of • “Radio” (to switch to the radio mode) commands. Universal commands are available at all •...
Page 117 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Previous Channel” (to select the previous channel) Radio FM To switch to the FM band, say “FM” or “Radio FM”. In • “List Channel” (to hear a list of available channels) this mode, you may say the following commands: •...
Page 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Memo − “Previous” (to play the previous memo) To switch to the voice recorder mode, say “Memo”. In − “Delete” (to delete a memo) this mode, you may say the following commands: • “Delete All” (to delete all memos) •...
Page 119: Voice Training
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Keep in mind that you have to press the Voice SEATS Command button first and wait for the beep Seats are a primary part of the Occupant Restraint System of the vehicle. They need to be used properly for safe before speaking the “Barge In”...
Page 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 switch is used to adjust the angle of the seatback. Push WARNING! forward or rearward on the switch to change the position of the seatback. Adjusting a seat while the vehicle is moving is dangerous.
Page 121: Manual Front Seatback Recline
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seatback Recline 2. Lift the handle to return the seatback to an upright To recline: position. 1. Lean forward in the seat and lift the handle, then lean WARNING! back to the desired position and release the handle. Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 122: Lumbar Support
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Lumbar Support Head Restraints This feature allows you to increase or decrease the Head restraints can reduce the risk of injury in the event of a rear impact. The head restraints should be adjusted amount of lumbar support.
Page 123: Heated Seats
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Driving a vehicle with the head restraints removed or improperly adjusted could cause serious injury or death in the event of a collision. The head restraints should always be checked prior to operating the vehicle and never adjusted while the vehicle is in motion.
Page 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Press the switch once to select High-level heat- WARNING! ing. Press the switch a second time to select • Persons who are unable to feel pain to the skin Low-level heating. Press the switch a third time to shut the heating elements Off.
Page 125: Easy Entry Seats
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Repeated overheating of the seat could damage the heating element and/or degrade the material of the seat. Easy Entry Seats Pulling upward on the lever, located on the seatback, allows the seatback to dump forward and the seat to slide forward.
Page 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 WARNING! • Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury.
Page 127: To Open And Close The Hood
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD 2. Move to the outside of the vehicle and push the safety Two latches must be released to open the hood. catch to the left. The safety catch is located under the center front edge of the hood.
Page 128: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 LIGHTS CAUTION! Headlights and Parking Lights To prevent possible damage, do not slam the hood to The headlight switch is located on the left side of the close it. Lower the hood until it is open approxi- instrument panel.
Page 129: Automatic Headlights - If Equipped
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the headlight switch clockwise to the first detent Headlights On with Wipers (Available with for parking light and instrument panel light operation. Automatic Headlights Only) Turn it to the second detent for headlight, parking light When this feature is active, the headlights will turn on and instrument panel light operation.
Page 130: Daytime Running Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 To activate the delay feature, place the ignition in the OFF Daytime Running Lights — If Equipped position while the headlights are still on. Then, turn off The high beam headlights will come on as Daytime the headlights within 45 seconds.
Page 131: Multifunction Lever
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE An indicator light in the instrument cluster illuminates when the fog lights are turned on. NOTE: The fog lights will operate with the low beam headlights or parking lights on. However, selecting the high beam headlights will turn off the fog lights.
Page 132: Lane Change Assist
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 NOTE: High/Low Beam Switch • If either light remains on and does not flash, or there is Push the multifunction lever away from you to switch a very fast flash rate, check for a defective outside light the headlights to high beam.
Page 133: Overhead Console Map/Reading Lights
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console. Each light is turned on by pressing the lens. Press the lens a second time to turn off the light. These lights also turn on when a door is opened, or when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is...
Page 134: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Interior Lights will increase the brightness of the instrument panel lights The interior lights come on when a door is opened. and, if equipped, the lighting in the door map pockets, door handles and cupholders. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition is placed in Dome Light Position...
Page 135: Windshield Wipers And Washers
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Rotate the end of the multifunction lever to the first The multifunction lever operates the windshield detent past the intermittent settings for low-speed wiper wipers and washer when the ignition is placed in operation, or to the second detent past the intermittent the RUN position.
Page 136: Mist Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Mist Feature WARNING! Push the multifunction lever inward (toward the steering column) to the first detent to activate a single wipe cycle Sudden loss of visibility through the windshield to clear off road mist or spray from a passing vehicle. The could lead to a collision.
Page 137: Tilt/Telescoping Steering Column
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Headlights On with Wipers feature can be enabled or disabled. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Fea- tures)” in “Understanding Your Instrument Panel” for further information. TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward.
Page 138: Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 outward or push it inward as desired. To lock the steering The Electronic Speed Control lever, located on the right- column in position, push the control handle inward until side of the steering wheel, operates the system. fully engaged.
Page 139: To Activate
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE System can be reactivated by pushing the Electronic To Set A Desired Speed Speed Control ON/OFF button and resetting the desired Turn the Electronic Speed Control ON. When the vehicle vehicle set speed. reaches the speed desired, push the lever downward to SET DECEL and release.
Page 140: To Resume Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 • Press the brake pedal, or press the clutch pedal to the RESUME ACCEL position, the set speed will continue to floor (manual transmission). increase until the lever is released, then the new set speed will be established.
Page 141: To Accelerate For Passing
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing On steep hills, a greater speed loss or gain may occur, so Press the accelerator as you would normally. When the it may be preferable to drive without Electronic Speed pedal is released, the vehicle will return to the set speed.
Page 142: Overhead Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 OVERHEAD CONSOLE Courtesy/Reading Lights The overhead console contains courtesy/reading lights At the forward end of the overhead console are two and sunglass storage. Universal Garage Door Opener courtesy/reading lights. (HomeLink ) button and a power sunroof switch may also be included, if equipped.
Page 143: Garage Door Opener - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink unit operates off your vehicle’s battery.
Page 144: Programming Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 toll-free 1–800–355–3515 Internet WARNING! www.HomeLink.com for safety information or assis- • Your motorized door or gate will open and close tance. while you are training the Universal Transceiver. Programming HomeLink Do not train the transceiver if people, pets, or Before You Begin other objects are in the path of the door or gate.
Page 145 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Your vehicle should be parked outside of the garage If the EVIC display states “DID NOT TRAIN” repeat while training. Step 3. If the signal is too weak, replace the battery in the handheld transmitter.
Page 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 garage door opener may have rolling code. If so, proceed to the heading “Programming A Rolling Code System.” Programming A Rolling Code System At the garage door opener motor (in the garage), locate the “Learn”...
Page 147: Gate Operator/Canadian Programming
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Return to the vehicle and press the programmed Similar to this Canadian law, some U.S. gate operators are HomeLink button twice (holding the button for two designed to “time-out” in the same manner. seconds each time).
Page 148: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Then proceed with Step 4 under “Programming 3. Without releasing the button, proceed with Program- HomeLink ” earlier in this section. ming HomeLink Step 2 and follow all remaining steps. Using HomeLink Security To operate, press and release the programmed It is advised to erase all channels before you sell or turn HomeLink button.
Page 149: General Information
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Press the LEARN button on the garage door opener to 2. This device must accept any interference that may be complete the training for rolling code. received including interference that may cause undesired operation.
Page 150: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof switch is located between the sun • Never leave children in a vehicle with the key in visors on the overhead console. the ignition switch (or with the ignition in the Accessory or Run position, for vehicles equipped with Keyless Go™).
Page 151: Opening Sunroof - Partially
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Express Open”. During Express Open operation, any WARNING! (Continued) movement of the sunroof switch will stop the sunroof. • Do not allow small children to operate the sun- Closing Sunroof — Partially roof. Never allow your fingers, other body parts, or Press and hold the switch in the forward position.
Page 152: Pinch Protect Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Pinch Protect Feature of sunroof position. During Express Vent operation, any This feature will detect an obstruction in the opening of movement of the sunroof switch will stop the sunroof. the sunroof during Express Close operation. If an ob- Sunshade Operation struction in the path of the sunroof is detected, the The sunshade can be opened manually.
Page 153: Sunroof Maintenance
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof Maintenance ELECTRICAL POWER OUTLETS Use only a nonabrasive cleaner and a soft cloth to clean There are two 12 Volt (13 Amp) electrical power outlets the glass panel. on this vehicle. Both of the outlets are protected by a fuse. Ignition Off Operation The front 12 Volt power outlet has power available only The power sunroof switch will remain active for up to...
Page 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 155 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! CAUTION! (Continued) • After the use of high power draw accessories or • Many accessories that can be plugged in draw long periods of the vehicle not being started (with power from the vehicle’s battery even when not in accessories still plugged in), the vehicle must be use (i.e., cellular phones, etc.).
Page 156: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 CUPHOLDERS Illuminated Front Cupholders — If Equipped The front cupholders are illuminated with LEDs. They Front Cupholders are turned on with the headlights or parking lights. Refer The front cupholders are located in the center console. to “Lights”...
Page 157: Rear Cupholders
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cupholders CONSOLE FEATURES The rear seat cupholders are located in the center armrest Sliding Center Console Armrest between the rear seats. The cupholders are positioned for- The center console armrest slides forward with three ward in the armrest and side-by-side to provide convenient detents to provide flexibility for comfort, cupholder use access to beverage cans or bottles while maintaining a...
Page 158: Console Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Console Storage The center console has a storage compartment located underneath the armrest, and also contains a 12 Volt power outlet, a molded-in coin holder (designed to hold various size coins). The center console may also be equipped with a Universal Consumer Interface (UCI).
Page 159: Rear Window Features
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES CAUTION! Rear Window Defroster Failure to follow these cautions can cause damage to The rear window defroster button is located on the the heating elements: climate control (Mode) knob. Press this button to •...
Page 160: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Keyless Enter-N-Go Display — Instrument Panel Features ....162 If Equipped ......185 Instrument Cluster –...
Page 161 160 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 730N/430 (RER/RBZ) — Media Center 130 (RES/RSC) — AM/FM AM/FM Stereo Radio And CD/DVD/HDD/ Stereo Radio With CD Player (MP3 AUX Jack) NAV — If Equipped ....192 And Sirius Radio .
Page 162 UNDERSTANDING YOUR INSTRUMENT PANEL 161 ▫ Play Mode ......220 ▫ Operating Instructions - Uconnect™ Phone (If Equipped) .
Page 163: Instrument Panel Features
162 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlets 5 — Heated Seat Switch 9 — Ignition Switch 2 — Instrument Cluster 6 — ESP OFF Switch 10 — Trunk Release Button 3 — Glove Compartment 7 — Hazard Warning Switch 11 —...
Page 164: Instrument Cluster - Base
UNDERSTANDING YOUR INSTRUMENT PANEL 163 INSTRUMENT CLUSTER – BASE...
Page 165: Instrument Cluster - Premium
164 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – PREMIUM...
Page 166: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 165 INSTRUMENT CLUSTER DESCRIPTIONS trip odometer is displayed to reset it to 0 miles (km). A second press of the button will display the outside 1. Fuel Gauge temperature in the odometer. The pointer shows the level of fuel in the fuel tank when the ignition switch is placed in the ON/RUN position.
Page 167 166 UNDERSTANDING YOUR INSTRUMENT PANEL ignition switch is placed in the ON/RUN position and place the shift lever in PARK, and cycle the ignition key. remain on briefly as a bulb check. If the light stays on or The light should turn off. If the light remains lit with the turns on while driving, turn off some of the vehicle’s engine running, your vehicle will usually be drivable.
Page 168 UNDERSTANDING YOUR INSTRUMENT PANEL 167 or when towing a trailer. It should not be allowed to WARNING! exceed the upper limits of the normal operating range. A hot engine cooling system is dangerous. You or CAUTION! others could be badly burned by steam or boiling coolant.
Page 169 168 UNDERSTANDING YOUR INSTRUMENT PANEL 10. Airbag Warning Light 12. Electronic Stability Program (ESP) This light will turn on for four to eight seconds If this indicator light flashes during accelera- as a bulb check when the ignition switch is first tion, ease up on the accelerator and apply as turned to the ON/RUN position.
Page 170 UNDERSTANDING YOUR INSTRUMENT PANEL 169 miles (kilometers) at speeds greater than 30 mph Do not operate the vehicle until the cause is corrected. (48 km/h), see an authorized dealer as soon as possible. This light does not indicate how much oil is in the engine. The engine oil level must be checked under the hood.
Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Shift Lever Indicator — Automatic Transmission the repair technician should leave the odometer reading Only the same as it was before the repair or service. If s/he The Shift Lever Indicator is self-contained within the cannot do so, then the odometer must be set at zero, and instrument cluster.
Page 172 UNDERSTANDING YOUR INSTRUMENT PANEL 171 On vehicles equipped with a Premium Instrument Clus- TRIP ODOMETER button to turn off the message. If the ter, this display shows the Electronic Vehicle Information problem continues, the message will appear the next time Center (EVIC) messages when the appropriate conditions the vehicle is started.
Page 173 172 UNDERSTANDING YOUR INSTRUMENT PANEL CHAngE OIL (Base Cluster) 2. Fully depress the accelerator pedal, slowly, three times Your vehicle is equipped with an engine oil change within 10 seconds. indicator system. The “CHAngE OIL” message will flash 3. Turn the ignition switch to the OFF position. in the instrument cluster odometer for approximately 12 seconds after a single chime has sounded to indicate NOTE: If the indicator message illuminates when you...
Page 174 UNDERSTANDING YOUR INSTRUMENT PANEL 173 hydraulic system malfunction. In this case, the light will WARNING! remain on until the condition has been corrected. Driving a vehicle with the brake light on is danger- The dual brake system provides a reserve braking capac- ous.
Page 175 174 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is vehicle placard or tire inflation pressure label, you should applied with the ignition switch in the ON/RUN posi- determine the proper tire inflation pressure for those tion.
Page 176 UNDERSTANDING YOUR INSTRUMENT PANEL 175 maintain correct tire pressure, even if under-inflation has tires or wheels on your vehicle, to ensure that the not reached the level to trigger illumination of the TPMS replacement or alternate tires and wheels allow the TPMS low tire pressure telltale.
Page 177 176 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Anti-Lock Brake (ABS) Light 25. Malfunction Indicator Light (MIL) This light monitors the Anti-Lock Brake System The Malfunction Indicator Light (MIL) is part of (ABS). The light will turn on when the ignition an onboard diagnostic system called OBD. The switch is placed in the ON/RUN position and may stay OBD system monitors engine and automatic on for as long as four seconds.
Page 178 UNDERSTANDING YOUR INSTRUMENT PANEL 177 26. Door Ajar Indicator CAUTION! This light will turn on to indicate that one or more door may be ajar. Prolonged driving with the MIL on could cause damage to the engine control system. It also could 27.
Page 179: Electronic Vehicle Information Center (Evic)
178 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER This system conveniently allows the driver to select a (EVIC) variety of useful information by pressing the switches The Electronic Vehicle Information Center (EVIC) fea- mounted on the steering wheel. The EVIC consists of the tures a driver-interactive display which is located in the following: instrument cluster.
Page 180 UNDERSTANDING YOUR INSTRUMENT PANEL 179 • Surround Sound modes (if equipped with Driver- SCROLL Button Selectable Surround [DSS]) Press the SCROLL button to scroll through Trip Functions, Performance Pages, Uconnect™ gps The system allows the driver to select information by (If Equipped), System Status Messages, and pressing the following buttons mounted on the steering Personal Settings (Customer-Programmable...
Page 181: Electronic Vehicle Information Center (Evic) Displays
180 UNDERSTANDING YOUR INSTRUMENT PANEL • Door(s) Ajar (with a single chime if vehicle is in Electronic Vehicle Information Center (EVIC) Displays motion) When the appropriate conditions exist, the EVIC displays • Trunk Ajar (with a single chime) the following messages. •...
Page 182: Engine Oil Change Indicator System
UNDERSTANDING YOUR INSTRUMENT PANEL 181 • Right Front Low Pressure (with a single chime) Engine Oil Change Indicator System • Right Rear Low Pressure (with a single chime) Oil Change Required Your vehicle is equipped with an engine oil change •...
Page 183: Trip Functions
182 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Fully depress the accelerator pedal, slowly, three times Press the SCROLL button to cycle through all the Trip within 10 seconds. Computer functions. 3. Turn the ignition switch to the OFF/LOCK position. The Trip Functions mode displays the following. •...
Page 184 UNDERSTANDING YOUR INSTRUMENT PANEL 183 Fuel Saver Mode — On Fuel Saver Mode — Off • Distance To Empty (DTE) This feature allows you to monitor when you are driving in a fuel efficient manner, and it can be used to modify Shows the estimated distance that can be traveled with driving habits in order to increase fuel economy.
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL • Trip B and average fuel economy, according to the current fuel tank level. DTE cannot be reset through the FUNCTION Shows the total distance traveled for Trip B since the last SELECT button. reset. •...
Page 186: Keyless Enter-N-Go Display - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 185 To Reset The Display Reset will only occur while a resettable function is being displayed. Press and release the FUNCTION SELECT button once to clear the resettable function being dis- played. To reset all resettable functions, press and release the FUNCTION SELECT button a second time within three seconds of resetting the currently-displayed func- tion.
Page 187: Driver-Selectable Surround Sound (Dss) - If Equipped
186 UNDERSTANDING YOUR INSTRUMENT PANEL Refer to “Keyless Enter-N-Go” in “Starting And Operat- Video Surround Mode will only be available for video ing” for more information. media sources (DVDs, Video CDs, or other video media supported by the radio). NOTE: Under certain conditions, the display may be superseded by another display of higher priority.
Page 188 UNDERSTANDING YOUR INSTRUMENT PANEL 187 Automatic Compass Calibration 3. Press the SCROLL button until “Calibrate Compass” This compass is self-calibrating, which eliminates the displays in the EVIC. need to set the compass manually. When the vehicle is 4. Press and release the FUNCTION SELECT button to new, the compass may appear erratic and the EVIC will start the calibration.
Page 189: System Warnings (Customer Information Features)
188 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Keep magnetic materials away from the top of 2. Press and hold the HOME button for approximately the instrument panel, such as iPod’s, Mobile Phones, two seconds. Laptops and Radar Detectors. This is where the compass 3.
Page 190: Personal Settings (Customer-Programmable Features)
UNDERSTANDING YOUR INSTRUMENT PANEL 189 • Oil Pressure FUNCTION SELECT button while in this display to Shows the actual oil pressure. select English, Espanol, or Francais. Then, as you con- tinue, the information will display in the selected lan- • Tire Pressure guage.
Page 191 190 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Key Unlock Flash Lights with Remote Key Lock When Driver Door 1st Press is selected, only the driver’s When ON is selected, the front and rear turn signals will door will unlock on the first press of the Remote Keyless flash when the doors are locked or unlocked with the Entry (RKE) transmitter UNLOCK button.
Page 192 UNDERSTANDING YOUR INSTRUMENT PANEL 191 NOTE: Turning the headlights on during the daytime Turn Headlights On with Remote Key Unlock causes the instrument panel lights to dim. To increase the When this feature is selected, the headlights will activate brightness, refer to “Lights” in “Understanding The and remain on for up to 90 seconds when the doors are Features Of Your Vehicle”.
Page 193: Media Center 730N/430 (Rer/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/Nav - If Equipped
192 UNDERSTANDING YOUR INSTRUMENT PANEL Turn-by-Turn Navigation — If Equipped MEDIA CENTER 730N/430 (RER/RBZ) — AM/FM When ON is selected, the Turn-by-Turn directions will STEREO RADIO AND CD/DVD/HDD/NAV — IF appear in the display as the vehicle approaches a desig- EQUIPPED nated turn within a programmed route.
Page 194: Operating Instructions - Uconnect™ Phone - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 193 Operating Instructions — Uconnect™ Phone — If displayed. To move the minute backward, touch the Equipped screen where the word “Min” with the arrow pointing Refer to “Uconnect™ Phone” in the Uconnect™ User downward is displayed. Manual located on the DVD for further details.
Page 195: Clock Setting Procedure - Rer Radio
194 UNDERSTANDING YOUR INSTRUMENT PANEL Show Time if Radio is Off 3. Touch the screen where the words “Set Time Zone” are When selected, this feature will display the time of day displayed. The time zone selection menu will appear on on the touch screen when the radio is turned off.
Page 196 UNDERSTANDING YOUR INSTRUMENT PANEL 195 To Manually Set the Clock — RER 6. To save the new time setting, touch the screen where the word “Save” is displayed. 1. Turn on the radio. Changing Daylight Savings Time 2. Touch the screen where the time is displayed. When selected, this feature will display the time of day in 3.
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL Show Time if Radio is Off 3. Touch the screen where “User Clock” is displayed, the When selected, this feature will display the time of day clock setting menu will appear on the screen. on the touch screen when the radio is turned off. Proceed 4.
Page 198: Media Center 130 (Sales Code Res)
UNDERSTANDING YOUR INSTRUMENT PANEL 197 MEDIA CENTER 130 (SALES CODE RES) Operating Instructions — Radio Mode NOTE: The radio sales code is located on the lower right NOTE: The ignition switch must be in the ON or ACC side of the radio faceplate. position to operate the radio.
Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons 4. Adjust the minutes using the right side TUNE/ Press and release the SEEK buttons to search for the next SCROLL control knob. Press the TUNE/SCROLL control listenable station in AM/FM mode. Press the right switch knob to save time change.
Page 200 UNDERSTANDING YOUR INSTRUMENT PANEL 199 Push the rotary TUNE/SCROLL control knob a second Push the rotary TUNE/SCROLL control knob again to time and MID will display. Turn the TUNE/SCROLL exit setting tone, balance, and fade. control knob to the right or left to increase or decrease the AM/FM Button mid-range tones.
Page 201: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
200 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by Operation Instructions — CD MODE For CD And repeating the above procedure with this exception: Press MP3 Audio Play the SET/RND button twice and SET 2 will show in the NOTE: display window.
Page 202 UNDERSTANDING YOUR INSTRUMENT PANEL 201 If you insert a disc with the ignition ON and the radio EJECT Button - Ejecting a CD ON, the unit will switch from radio to CD mode and Press the EJECT button to eject the CD. begin to play when you insert the disc.
Page 203: Notes On Playing Mp3 Files
202 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK SET/RND Button (Random Play Button) button will allow faster scrolling through the tracks in Press this button while the CD is playing to activate CD and MP3 modes. Random Play.
Page 204 UNDERSTANDING YOUR INSTRUMENT PANEL 203 Supported Medium Formats (File Systems) exceeding 20 folders will result in this display. With The medium formats supported by the radio are ISO 9660 200 files, exceeding 50 folders will result in this Level 1 and Level 2 and includes the Joliet extension. display.) When reading discs recorded using formats other than •...
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Sampling Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- Specification Frequency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.
Page 206: Operation Instructions - Auxiliary Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 205 Loading times for playback of MP3 files may be affected MP3 player, or cassette player, and utilize the vehicle’s by the following: audio system to amplify the source and play through the vehicle speakers. • Media - CD-RW media may take longer to load than CD-R media Pressing the DISC/AUX button will change the mode to auxiliary device if the AUX jack is connected.
Page 207: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
206 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (RES/RSC) — AM/FM Operating Instructions — Radio Mode STEREO RADIO WITH CD PLAYER (MP3 AUX NOTE: The ignition switch must be in the ON/RUN or JACK) AND SIRIUS RADIO ACC position to operate the radio. NOTE: The radio sales code is located on the lower right Power Switch/Volume Control (Rotary) side of the radio faceplate.
Page 208 UNDERSTANDING YOUR INSTRUMENT PANEL 207 SEEK Buttons If your vehicle is not equipped with or this feature is not Press and release the SEEK buttons to search for the next available on your vehicle, a “Not Equipped With listenable station in AM/FM mode. Press the right switch Uconnect”...
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure starting at Step 2. For vehicles not equipped with satellite radio, press the SETUP button and then follow the above 1. Press and hold the TIME button until the hours blink. procedure, starting at Step 2. 2.
Page 210 UNDERSTANDING YOUR INSTRUMENT PANEL 209 Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob a fifth time Push the rotary TUNE/SCROLL control knob and BASS and FADE will display. Turn the TUNE/SCROLL control will display. Turn the TUNE/SCROLL control knob to knob to the left or right to adjust the sound level between the right or left to increase or decrease the bass tones.
Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following 16-Digit Program Type format types: Character Display 16-Digit Personality Persnlty Program Type Character Display Public Public No program type Rhythm and Blues R & B None or undefined Religious Music Rel Musc...
Page 212 UNDERSTANDING YOUR INSTRUMENT PANEL 211 By pressing the SEEK button when the Music Type icon the minutes using the right side TUNE/SCROLL is displayed, the radio will be tuned to the next frequency control knob. Press the TUNE/SCROLL control knob station with the same selected Music Type name.
Page 213: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
212 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by Operation Instructions — CD MODE for CD and repeating the above procedure with this exception: Press MP3 Audio Play the SET/RND button twice and SET 2 will show in the NOTE: display window.
Page 214 UNDERSTANDING YOUR INSTRUMENT PANEL 213 If you insert a disc with the ignition ON/RUN and the EJECT Button - Ejecting a CD radio ON, the unit will switch from radio to CD mode Press the EJECT button to eject the CD. and begin to play when you insert the disc.
Page 215: Notes On Playing Mp3 Files
214 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Button AM/FM Button Press the right SEEK button for the next selection on the Press the button to select either AM or FM mode. CD. Press the left SEEK button to return to the beginning SET/RND Button (Random Play Button) of the current selection, or return to the beginning of the Press this button while the CD is playing to activate...
Page 216 UNDERSTANDING YOUR INSTRUMENT PANEL 215 Supported Media (Disc Types) a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. 200 files, exceeding 50 folders will result in this display.) Supported Medium Formats (File Systems)
Page 217 216 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats MPEG Sampling Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- Specification Frequency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 160, 128, 144, extension may cause playback problems.
Page 218: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 217 Loading times for playback of MP3 files may be affected begin playing the files contained in that folder (or the by the following: next folder in sequence if the selection does not contain playable files). •...
Page 219: Universal Consumer Interface (Uci) 0.5 - If Equipped
218 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode Operating Instructions - Uconnect™ Phone (If The auxiliary (AUX) jack is an audio input jack which Equipped) allows the user to plug in a portable device such as an Refer to “Uconnect™ Phone” in the Uconnect™ User MP3 player or cassette player and utilize the vehicle’s Manual located on the DVD for further details.
Page 220: Connecting The Ipod
UNDERSTANDING YOUR INSTRUMENT PANEL 219 This feature allows an iPod to be plugged into the Connecting The iPod vehicle’s sound system through a 16–pin connector, using Use the provided connection cable to connect an iPod to the provided interface cable. the vehicle’s 16–pin connector port located on the center console.
Page 221: Using This Feature
220 UNDERSTANDING YOUR INSTRUMENT PANEL Using This Feature Play Mode By using the provided connection cable to connect an When switched to UCI mode, the iPod automatically iPod to the vehicle’s UCI 16–pin connector port: starts Play mode. In Play mode, use the following buttons on the radio faceplate to control the iPod and display •...
Page 222 UNDERSTANDING YOUR INSTRUMENT PANEL 221 • Jump backward in the current track by pressing and • While a track is playing, press the INFO button to see holding the << RW button. Holding the << RW the associated metadata (artist, track title, album, etc.) button long enough will jump to the beginning of for that track.
Page 223: List Or Browse Mode
222 UNDERSTANDING YOUR INSTRUMENT PANEL Shuffle OFF modes for the iPod . If the RND icon is fast will scroll through the list faster. During fast showing on the radio display, then the shuffle mode is scroll, a slight delay in updating the information on the radio display may be noticed.
Page 224 UNDERSTANDING YOUR INSTRUMENT PANEL 223 • Pressing a PRESET button will display the current CAUTION! list on the top line and the first item in that list on • Leaving the iPod (or any supported device) any- the second line. where in the vehicle in extreme heat or cold can •...
Page 225: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Req/Rer/Res Radios Only)
224 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect™ Multimedia (SATELLITE RADIO) — IF information, call the toll-free number 888-539-7474, or EQUIPPED (REN/REQ/RER/RES RADIOS ONLY) visit the Sirius web site at www.sirius.com, or at www- Satellite radio uses direct satellite-to-receiver broadcast- .siriuscanada.ca for Canadian residents. ing technology to provide clear digital sound, coast to Electronic Serial Number/Sirius Identification coast.
Page 226: Selecting Uconnect™ Multimedia (Satellite) Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 225 Sirius ID number will display. The Sirius ID number bikes should be placed as far rearward as possible, within display will time out in two minutes. Press any button on the loading design of the rack. Do not place items directly the radio to exit this screen.
Page 227: Operating Instructions - Uconnect
226 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect™ Multimedia INFO Button (Satellite) Mode Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- NOTE: The ignition switch must be in the ON or ACC able).
Page 228 UNDERSTANDING YOUR INSTRUMENT PANEL 227 • Display Sirius ID number — Press the AUDIO/ MUSIC TYPE Button Pressing this button once will turn on the Music Type SELECT button to display the Sirius ID number. This mode for five seconds. Pressing the MUSIC TYPE button number is used to activate, deactivate, or change the or turning the TUNE/SCROLL control knob within five Sirius subscription.
Page 229: Operating Instructions - Uconnect™ Phone (If Equipped)
228 UNDERSTANDING YOUR INSTRUMENT PANEL pushbutton memory. The channels stored in SET 2 KICKER HIGH PERFORMANCE SOUND SYSTEM memory can be selected by pressing the pushbutton WITH DRIVER-SELECTABLE SURROUND (DSS) – twice. IF EQUIPPED Every time a preset button is used, a corresponding button number will display.
Page 230 UNDERSTANDING YOUR INSTRUMENT PANEL 229 any stereo audio source. A new feature of the KICKER NOTE: Dependent on the audio source, the output may audio system offers the ability to choose surround sound sound better in stereo or DDS surround mode. for any audio source.
Page 231: Remote Sound System Controls
230 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF Vehicles equipped with steering wheel-mounted buttons EQUIPPED are also equipped with the Electronic Vehicle Information Center (EVIC). The EVIC features a driver-interactive display which is located in the instrument cluster. VOLUME Button The VOLUME button controls the sound level of the sound system.
Page 232: Cd/Dvd Disc Maintenance
UNDERSTANDING YOUR INSTRUMENT PANEL 231 mode will change (i.e., from AM to FM, to Media mode, CD/DVD DISC MAINTENANCE etc., depending on which radio is in the vehicle). To keep a CD/DVD in good condition, take the following precautions: FUNCTION SELECT Button When the EVIC is in the Compass/Temp/ 1.
Page 233: Radio Operation And Mobile Phones
232 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- CLIMATE CONTROLS lar disc, it may be damaged (i.e., scratched, reflective Manual Air Conditioning and Heating System coating removed, a hair, moisture or dew on the disc) The controls for the manual system in this vehicle contain oversized, or have protection encoding.
Page 234 UNDERSTANDING YOUR INSTRUMENT PANEL 233 Front Blower Control Temperature Control There are four blower speeds. Use this Use this control to regulate the tem- control to regulate the amount of air perature of the air inside the passenger forced through the system in any compartment.
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL Mode Control (Air Direction) Bi-Level Mode Mode control allows you to choose Air is directed through the panel and floor outlets. from several selections of air distribu- tion. You can select either a primary NOTE: There is a difference in temperature (in any mode, as identified by the symbols, or conditions other than full cold or full hot), between the a blend of two of these modes.
Page 236 UNDERSTANDING YOUR INSTRUMENT PANEL 235 Defrost Mode NOTE: • If the RECIRCULATION button is pressed when the Air is directed through the windshield and side window demist outlets. Use DEFROST mode with system is in MIX, DEFROST, or FLOOR mode the maximum blower and temperature settings for best RECIRCULATION LED indicator will flash 3 times windshield and side window defrosting.
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL • The A/C can be deselected manually without disturb- Max A/C ing the mode control selection. For maximum cooling use the A/C and RECIRCULA- TION mode buttons at the same time. Economy Mode If ECONOMY mode is desired, press the A/C button to Remote Start —...
Page 238: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 237 If Outside Ambient Mode Overrides To Temperature Overrides To Rear Window Defroster Temperature Is Active Less than 40°F Full Heat Between 40°F and 80°F No Override No Override More than 80°F Bi-Level Full Cool NOTE: Summer Operation •...
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL Vacation Storage Side Window Demisters Anytime you store your vehicle, or keep it out of service A side window demister outlet is located at each end of (i.e., vacation) for two weeks or more, run the air the instrument panel.
Page 240 UNDERSTANDING YOUR INSTRUMENT PANEL 239 Control Setting Suggestions for Various Weather Conditions...
Page 242: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....245 Engine Block Heater — If Equipped ..252 ▫...
Page 243 242 STARTING AND OPERATING ▫ Five-Speed Automatic Transmission ..262 ▫ Manual Transmission – If Equipped ..274 ▫ Gear Ranges ......262 ▫...
Page 244 STARTING AND OPERATING 243 ▫ Synchronizing ESP ....285 ▫ Tread Wear Indicators ....301 ▫...
Page 245 244 STARTING AND OPERATING ▫ Reformulated Gasoline ....315 ▫ Gross Axle Weight Rating (GAWR) ..322 ▫ Gasoline/Oxygenate Blends ... . . 315 ▫...
Page 246: Starting Procedures
STARTING AND OPERATING 245 STARTING PROCEDURES Manual Transmission – If Equipped Before starting your vehicle, adjust your seat, adjust the Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, fasten your seat belt, and if TRAL and press the clutch pedal before starting vehicle.
Page 247: Automatic Transmission - If Equipped
246 STARTING AND OPERATING WARNING! CAUTION! Do not attempt to push or tow your vehicle to get it Damage to the transmission may occur if the follow- started. Unburned fuel could enter the catalytic con- ing precautions are not observed: •...
Page 248: Keyless Go™ - If Equipped
STARTING AND OPERATING 247 Do not press the accelerator. Use the Fob with Integrated Installing and Removing the ENGINE Key to briefly turn the ignition switch to the START START/STOP Button position and release it as soon as the starter engages. The Installing the Button starter motor will continue to run, and it will disengage automatically when the engine is running.
Page 249: Normal Starting
248 STARTING AND OPERATING NOTE: The ENGINE START/STOP button should only Using the ENGINE START/STOP Button – Manual be removed or inserted with the ignition in the OFF Transmission Only position. NOTE: Normal starting of either a cold or a warm Normal Starting engine is obtained without pumping or pressing the accelerator pedal.
Page 250 STARTING AND OPERATING 249 2. The ignition switch will return to the OFF position. To Turn Off the Engine Using ENGINE START/STOP Button – Manual Transmission Only 3. If the shift lever is not in PARK, the ENGINE START/ STOP button must be held for two seconds and vehicle 1.
Page 251: Extreme Cold Weather (Below 20°F Or 29°C)
250 STARTING AND OPERATING • If the vehicle speed is above 5 mph (8 km/h), the • Starting with the ignition switch in the OFF position: ENGINE START/STOP button must be held for two • Press the ENGINE START/STOP button once to seconds before the engine will shut off.
Page 252: If Engine Fails To Start
STARTING AND OPERATING 251 If Engine Fails To Start Clearing a Flooded Engine (Using ENGINE START/STOP Button) – Automatic Transmission WARNING! Only If the engine fails to start after you have followed the • Never pour fuel or other flammable liquids into the “Normal Starting”...
Page 253: After Starting
252 STARTING AND OPERATING the way to the floor and hold it, then press and hold the CAUTION! ENGINE START/STOP button for no more than 15 sec- onds. Release the accelerator pedal and the clutch pedal, To prevent damage to the starter, wait 10 to 15 sec- wait 10 to 15 seconds, then repeat the “Normal Starting”...
Page 254: Manual Transmission - If Equipped
STARTING AND OPERATING 253 The engine block heater must be plugged in at least one CAUTION! hour to have an adequate warming effect on the engine. • Never drive with your foot resting on the clutch WARNING! pedal, or try to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause Remember to disconnect the engine block heater abnormal wear on the clutch.
Page 255 254 STARTING AND OPERATING NOTE: During cold weather, you may experience in- Shifting creased effort in shifting until the transmission fluid Fully press the clutch pedal before shifting gears. As you warms up. This is normal. release the clutch pedal, lightly press the accelerator pedal.
Page 256 STARTING AND OPERATING 255 MANUAL TRANSMISSION CAUTION! RECOMMENDED SHIFT SPEEDS Always make sure the vehicle comes to a complete Axle Ratio stop before shifting into REVERSE. Failure to do so may result in transmission damage. 3.73 (km/h) (32) (40) (67) You must always use first gear (or Reverse) when starting 3.91 from a standing position.
Page 257 256 STARTING AND OPERATING with the ignition switch in the ON position (RUN possible fuel economy from your vehicle. This occurs position for Keyless Go™), as compared to the ignition when the engine coolant (antifreeze) is higher than 106°F LOCK position (OFF position for Keyless Go™). This (41°C), vehicle speed is greater than 19 mph (30 km/h) is normal operation of the transmission reverse inhibi- but less than 21 mph (34 km/h), and the transmission is...
Page 258: Automatic Transmission - If Equipped
STARTING AND OPERATING 257 AUTOMATIC TRANSMISSION — IF EQUIPPED WARNING! CAUTION! Skipping more than one gear while downshifting, could cause you to lose control of your vehicle. You Damage to the automatic transmission may occur if could have an accident. the following precautions are not observed: •...
Page 259: General Information
258 STARTING AND OPERATING • Shift lever position WARNING! • Accelerator position It is dangerous to move the shift lever out of PARK or • Vehicle speed NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, The gear shifting process is continuously adapted, de- the vehicle could accelerate quickly forward or in pendent on the driving style, the driving situation, and...
Page 260 STARTING AND OPERATING 259 • The electronically-controlled transmission provides a WARNING! precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new Unintended movement of a vehicle could injure vehicle may be somewhat abrupt or soft until after the those in and near the vehicle.
Page 261: Key Ignition Park Interlock
260 STARTING AND OPERATING This may result in a slightly different feeling or response other ignition position (ACC, ON/RUN) position, and during normal operation in DRIVE position. After the the brake pedal must be pressed whether or not the transmission cools down, it will return to normal engine is running.
Page 262 STARTING AND OPERATING 261 4. Using the screwdriver, press and hold the override tab 5. Move the shift lever into the NEUTRAL position. through the access port on the center console. 6. The vehicle may then be started in NEUTRAL. 7.
Page 263: Starting And Operating Five-Speed Automatic Transmission
262 STARTING AND OPERATING Five-Speed Automatic Transmission Gear Ranges Shifting from DRIVE to PARK or REVERSE should be PARK done only after the accelerator pedal is released and the This range supplements the parking brake by locking the vehicle is stopped. Be sure to keep your foot on the brake transmission.
Page 264 STARTING AND OPERATING 263 WARNING! CAUTION! Never use the PARK position as a substitute for the Damage to the shifter could result if the shift lever is parking brake. Always apply the parking brake fully moved out of PARK before the ignition is turned when parked to guard against vehicle movement and from the LOCK (OFF position with Keyless Go™) to possible injury or damage.
Page 265 264 STARTING AND OPERATING The transmission automatically upshifts through fifth CAUTION! gear. The DRIVE position provides optimum driving characteristics under all normal operating conditions. Coasting the vehicle or driving for any other reason with the shift lever in NEUTRAL can result in When frequent transmission shifting occurs when using transmission damage.
Page 266 STARTING AND OPERATING 265 Temporary Transmission Limp Home Mode 3. Turn the engine off. The transmission is monitored for abnormal conditions. 4. Wait approximately 10 seconds. If a condition is detected that could result in transmission damage, the transmission will engage Limp Home Mode. 5.
Page 267: Autostick - If Equipped
266 STARTING AND OPERATING AUTOSTICK — IF EQUIPPED WARNING! AutoStick — 3.5L Engine Do not downshift for additional engine braking on a AutoStick allows you to move the shift lever to the left slippery surface. The drive wheels could lose their (-) or right (+) when the shift lever is in the DRIVE grip and the vehicle could skid, causing an accident position, this allows the selection of the desired top gear.
Page 268 STARTING AND OPERATING 267 can also provide you with more control during passing, disengage AutoStick mode, hold the shift lever to the city driving, cold slippery conditions, mountain driving, right (D+) for a few seconds. You can shift in or out of the trailer towing, and many other situations.
Page 269: Driving On Slippery Surfaces
268 STARTING AND OPERATING • Avoid using speed control when AutoStick is en- WARNING! gaged. Rapid acceleration on slippery surfaces is dangerous. • The transmission will automatically shift up when Unequal traction can cause sudden pulling of the rear maximum engine speed is reached while AutoStick is wheels.
Page 270: Driving Through Water
STARTING AND OPERATING 269 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace tires when tread wear indicators first become WARNING! visible. Do not drive on, or cross, a road or a path where 4.
Page 271 270 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • Driving through standing water may cause dam- • Always check the depth of the standing water age to your vehicle’s drivetrain components. Al- before driving through it. Never drive through ways inspect your vehicle’s fluids (i.e., engine oil, standing water that is deeper than the bottom of transmission, axle, etc.) for signs of contamination the tire rims mounted on the vehicle.
Page 272: Power Steering
STARTING AND OPERATING 271 POWER STEERING WARNING! The standard power steering system will give you good • Driving through standing water limits your vehi- vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical cle’s traction capabilities. Do not exceed 5 mph steering capability if power assist is lost.
Page 273: Power Steering Fluid Check
272 STARTING AND OPERATING system. This noise should be considered normal, and it checked if a leak is suspected, abnormal noises are does not in any way damage the steering system. apparent, and/or the system is not functioning as antici- pated.
Page 274: Parking Brake
STARTING AND OPERATING 273 If necessary, add fluid to restore to the proper indicated flash. If vehicle speed is detected, a chime will sound level. With a clean cloth, wipe any spilled fluid from all to alert the driver. Fully release the parking brake surfaces.
Page 275: Manual Transmission - If Equipped
274 STARTING AND OPERATING Manual Transmission – If Equipped Automatic Transmission – If Equipped The foot operated parking brake is positioned below the The foot operated parking brake is located below the lower lower left corner of the instrument panel. To release the left corner of the instrument panel.
Page 276 STARTING AND OPERATING 275 WARNING! WARNING! (Continued) • Always fully apply the parking brake when leav- • Never use the PARK position as a substitute for ing your vehicle, or it may roll and cause damage the parking brake. Always apply the parking or injury.
Page 277: Brake System
276 STARTING AND OPERATING BRAKE SYSTEM braking conditions. The system automatically “pumps” Your vehicle is equipped with dual hydraulic the brakes during severe braking conditions to prevent brake systems. If either of the two hydraulic wheel lock-up. systems loses normal capability, the remaining The Electronic Brake Force Distribution (EBD) prevents system will still function.
Page 278 STARTING AND OPERATING 277 You also may experience the following when the brake WARNING! system goes into anti-lock: • The Anti-Lock Brake System (ABS) contains so- • The ABS motor running (it may continue to run for a phisticated electronic equipment that may be sus- short time after the stop), ceptible to interference caused by improperly in- •...
Page 279 278 STARTING AND OPERATING Anti-Lock Brake Warning Light WARNING! (Continued) The “Anti-Lock Brake System (ABS) Warning • The Anti-Lock Brake System (ABS) cannot prevent Light” monitors the Anti-Lock Brake System. The the natural laws of physics from acting on the light will come on when the ignition switch is turned to vehicle, nor can it increase braking or steering the ON position and may stay on for as long as four...
Page 280: Electronic Brake Control System
STARTING AND OPERATING 279 If both the “Brake Warning Light” and the “ABS Warning Anti-Lock Brake System (ABS) – If Equipped Light” remain on, the ABS and EBD systems are not This system aids the driver in maintaining vehicle control functioning.
Page 281: Traction Control System (Tcs) - If Equipped
280 STARTING AND OPERATING Traction Control System (TCS) – If Equipped Brake Assist System (BAS) – If Equipped This system monitors the amount of wheel spin of each This system complements the ABS by optimizing the driven wheel. If wheel spin is detected, brake pressure is vehicle braking capability during emergency braking applied to the slipping wheel(s) and engine power is maneuvers.
Page 282: Hill Start Assist (Hsa) - Manual Transmission Only
STARTING AND OPERATING 281 brake pedal. If the driver does not apply the throttle WARNING! during this short period of time, the system will release brake pressure and the vehicle will roll down the hill. The The BAS cannot prevent the natural laws of physics system will release brake pressure in proportion to from acting on the vehicle, nor can it increase the amount of throttle applied as the vehicle starts to move in...
Page 283 282 STARTING AND OPERATING NOTE: You must complete Steps 1 through 8 within WARNING! 90 seconds. There may be situations on minor hills (i.e., less than 1. Center the steering wheel (front wheels pointing 8%), with a loaded vehicle, or while pulling a trailer, straight forward).
Page 284: Electronic Stability Program (Esp) - If Equipped
STARTING AND OPERATING 283 9. Turn the ignition switch to the OFF position and then does not match the intended path, the ESP applies the back to the ON position. If the sequence was completed brake of the appropriate wheel to assist in counteracting properly, the “ESP/TCS Indicator Light”...
Page 285 284 STARTING AND OPERATING Partial Off WARNING! The “Partial Off” mode is intended for times when a more spirited driving experience is desired. It is also The ESP cannot prevent the natural laws of physics intended for driving in deep snow, sand, or gravel. This from acting on the vehicle, nor can it increase the mode disables the TCS portion of the ESP and raises the traction afforded by prevailing road conditions.
Page 286: Synchronizing Esp
STARTING AND OPERATING 285 mode is overcome, turn the ESP ON again by momen- tarily pressing the “ESP OFF” switch. This may be done while the vehicle is in motion. Synchronizing ESP The Malfunction Indicator Light for the ESP is combined with BAS indicator.
Page 287: Esp/Bas Malfunction Indicator Light And Esp/Tcs Indicator Light
286 STARTING AND OPERATING ESP/BAS Malfunction Indicator Light and NOTE: • The “ESP/TCS Indicator Light” and the “ESP/BAS ESP/TCS Indicator Light The Malfunction Indicator Light for the ESP is Malfunction Indicator Light” will turn on momen- combined with the BAS indicator. The “ESP/ tarily each time the ignition switch is turned ON.
Page 288: Tire Safety Information
STARTING AND OPERATING 287 TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 289 288 STARTING AND OPERATING CAUTION! Do not use two different size tires on the rear wheels, as this can result in rear axle damage. Tire Sizing Chart TIRE SIZING TERMS Size Designation: P = Passenger Car tire size based on U.S. design standards ..blank..
Page 290 STARTING AND OPERATING 289 TIRE SIZING TERMS — D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol —...
Page 291 290 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 292: Tire Terminology And Definitions
STARTING AND OPERATING 291 Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof. Cold Tire Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 293: Tire Loading And Tire Pressure
292 STARTING AND OPERATING Tire Loading and Tire Pressure This placard tells you important information about the: Tire Placard Location 1) number of people that can be carried in the vehicle NOTE: The proper cold tire inflation pressure is listed 2) total weight your vehicle can carry on the driver’s side B-Pillar.
Page 294 STARTING AND OPERATING 293 axles must not be exceeded. For further information on 3. Subtract the combined weight of the driver and pas- GAWRs, vehicle loading, and trailer towing, refer to sengers from XXX kg or XXX lbs. “Vehicle Loading” in this section. 4.
Page 295 294 STARTING AND OPERATING NOTE: • The following table shows examples on how to calcu- late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load carry capacity of your vehicle.
Page 296 STARTING AND OPERATING 295...
Page 297: Tires - General Information
296 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 298: Tire Inflation Pressures
STARTING AND OPERATING 297 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to Some vehicles may have supplemental tire pressure the right or left.
Page 299 298 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 300: Radial Ply Tires
STARTING AND OPERATING 299 Tire Pressures for High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 301: Tire Spinning
300 STARTING AND OPERATING WARNING! CAUTION! Temporary use spare tires are for emergency use only. Because of the reduced ground clearance, do not take With these tires, do not drive more than 50 mph your vehicle through an automatic car wash with the (80 km/h).
Page 302: Tread Wear Indicators
STARTING AND OPERATING 301 WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) for more than 30 seconds continu- ously when you are stuck, and do not let anyone near a spinning wheel, no matter what the speed.
Page 303: Life Of Tire
302 STARTING AND OPERATING Life Of Tire Replacement Tires The service life of a tire is dependent upon varying The tires on your new vehicle provide a balance of many factors including, but not limited to: characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure.
Page 304 STARTING AND OPERATING 303 WARNING! WARNING! (Continued) • Never use a tire with a smaller load index or • Do not use a tire, wheel size or rating other than capacity, other than what was originally equipped that specified for your vehicle. Some combinations on your vehicle.
Page 305: Snow Tires
304 STARTING AND OPERATING SNOW TIRES TIRE ROTATION RECOMMENDATIONS Some areas of the country require the use of snow tires Tires on the front and rear axles of vehicles operate at during the winter. Standard tires are of the all season type different loads and perform different steering, driving, and satisfy this requirement as indicated by the M+S and braking functions.
Page 306: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 305 The suggested rotation method for vehicles equipped TIRE PRESSURE MONITOR SYSTEM (TPMS) with all season tires is the “forward-cross” as shown in The Tire Pressure Monitor System (TPMS) will warn the the following diagram. driver of a low tire pressure based on the vehicle recom- mended cold placard pressure.
Page 307 306 STARTING AND OPERATING The TPMS will warn the driver of a low tire pressure if For example, your vehicle may have a recommended the tire pressure falls below the low-pressure warning cold (parked for more than three hours) placard pressure limit for any reason, including low temperature effects of 30 psi (207 kPa).
Page 308 STARTING AND OPERATING 307 NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance or to provide warning of a tire failure or condition. equipment tires and wheels. TPMS pressures and warning have been established for the tire size •...
Page 309: Base System
308 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, Tire Pressure Monitoring Low Pressure Warnings and the TPMS will monitor the actual tire pressure in The “TPM Telltale Light” will illuminate in the the tire. instrument cluster and a chime will sound when tire pressure is low in one or more of the four Base System active road tires.
Page 310 STARTING AND OPERATING 309 turn off when the fault condition no longer exists. A 2. If you install the compact spare tire in place of a road system fault can occur due to any of the following: tire that has a pressure below the low-pressure warning limit, upon the next ignition switch cycle, a chime will 1.
Page 311: Premium System - If Equipped
310 STARTING AND OPERATING Premium System – If Equipped Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitor System (TPMS) uses wireless The “TPM Telltale Light” will illuminate in the technology with wheel rim mounted electronic sensors to instrument cluster and a chime will sound when monitor tire pressure levels.
Page 312 STARTING AND OPERATING 311 Should this occur, you should stop as soon as possible and inflate all of the tires with a low pressure condition (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure inflation value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the “TPM Telltale Light”...
Page 313 312 STARTING AND OPERATING Check TPMS Warning If the ignition switch is cycled, this sequence will repeat, If a system fault is detected, the “TPM Telltale Light” will providing the system fault still exists. If the system fault flash on and off for 75 seconds and then remain on solid. The no longer exists, the “TPM Telltale Light”...
Page 314 STARTING AND OPERATING 313 Vehicles with Compact Spare 4. For each subsequent ignition switch cycle, a chime will sound, the “TPM Telltale Light” will flash on and off for 1. The compact spare tire does not have a TPM sensor. 75 seconds and then remain on solid, and the EVIC will Therefore, the TPMS will not monitor the pressure in the display a CHECK TPM SYSTEM message for three...
Page 315: General Information
314 STARTING AND OPERATING General Information FUEL REQUIREMENTS This device complies with Part 15 of the FCC rules and 3.5L and 5.7L Engine (with Automatic RSS 210 of Industry Canada. Operation is subject to the Transmission) following conditions: The 3.5L and 5.7L engine (with automatic •...
Page 316: L Engine (With Manual Transmission)
STARTING AND OPERATING 315 as hard starting, stalling, and hesitations. If you experi- Reformulated Gasoline ence these symptoms, try another brand of gasoline Many areas of the country require the use of cleaner before considering service for the vehicle. burning gasoline referred to as “reformulated gasoline.” Reformulated gasolines contain oxygenates and are spe- Over 40 auto manufacturers worldwide have issued and cifically blended to reduce vehicle emissions and im-...
Page 317: E-85 Usage In Non-Flex Fuel Vehicles
316 STARTING AND OPERATING • operate in a lean mode CAUTION! • OBD II “Malfunction Indicator Light” on Do not use gasolines containing Methanol or E85 • poor engine performance Ethanol. Use of these blends may result in starting and driveability problems and may damage critical •...
Page 318: Mmt In Gasoline
STARTING AND OPERATING 317 MMT In Gasoline Materials Added to Fuel MMT is a manganese-containing metallic additive that is All gasoline sold in the United States is required to blended into some gasoline to increase octane. Gasoline contain effective detergent additives. Use of additional blended with MMT provides no performance advantage detergents or other additives is not needed under normal beyond gasoline of the same octane number without...
Page 319: Carbon Monoxide Warnings
318 STARTING AND OPERATING Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon some light smoke, your engine may be out of tune monoxide poisoning:...
Page 320: Adding Fuel
STARTING AND OPERATING 319 WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. •...
Page 321 320 STARTING AND OPERATING CAUTION! • Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap (gas cap). • A poorly fitting gas cap could let impurities into the fuel system. •...
Page 322: Loose Fuel Filler Cap Message
STARTING AND OPERATING 321 • When the fuel nozzle “clicks” or shuts off, the fuel WARNING! tank is full. • Never have any smoking materials lit in or near Loose Fuel Filler Cap Message the vehicle when the gas cap is removed or the If the vehicle diagnostic system determines that the fuel tank is being filled.
Page 323: Vehicle Loading
322 STARTING AND OPERATING • Gross Axle Weight Rating (GAWR) rear VEHICLE LOADING The load carrying capacity of your vehicle is shown on • Vehicle Identification Number (VIN) the “Vehicle Certification Label.” This information • Type of Vehicle should be used for passenger and luggage loading as indicated.
Page 324: Overloading
STARTING AND OPERATING 323 Figure out the weight on the front and rear of the vehicle WARNING! separately. It is important that you distribute the load evenly over the front and rear axles. Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front Overloading can cause potential safety hazards and or rear GAWR.
Page 325: Trailer Towing
324 STARTING AND OPERATING NOTE: Refer to the “Vehicle Certification Label” affixed Gross Vehicle Weight Rating (GVWR) to the rear of the driver’s door for your vehicle’s GVWR The GVWR is the total allowable weight of your vehicle. and GAWRs. This includes driver, passengers, cargo, and tongue weight.
Page 326 STARTING AND OPERATING 325 NOTE: The GCWR rating includes a 150 lbs (68 kg) Tongue Weight (TW) allowance for the presence of a driver. The TW is the downward force exerted on the hitch ball by the trailer. In most cases, it should not be less than 10% Gross Axle Weight Rating (GAWR) or more than 15% of the trailer load.
Page 327: Trailer Hitch Classification
326 STARTING AND OPERATING of hitches are the most popular on the market today and WARNING! they are commonly used to tow small- and medium- • An improperly adjusted weight distributing hitch sized trailers. system may reduce handling, stability, braking Weight-Distributing Hitch performance, and could result in an accident.
Page 328 STARTING AND OPERATING 327 All trailer hitches should be professionally installed on Trailer Hitch Classification Definitions your vehicle. Class Max. Trailer Hitch Industry Standards Class I - Light Duty 2,000 lbs (907 kg) Class II - Medium 3,500 lbs (1587 kg) Duty Class III - Heavy Duty 5,000 lbs (2268 kg)
Page 329: Trailer Towing Weights (Maximum Trailer Weight Ratings)
328 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area Max. GTW (Gross Trailer Max. Tongue Wt. Wt.) 3.5L Automatic 12 sq ft (1.11 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg) 5.7L Automatic...
Page 330: Towing Requirements
STARTING AND OPERATING 329 Consider the following items when computing the CAUTION! weight on the rear axle of the vehicle: • Do not tow a trailer at all during the first 500 miles • The tongue weight of the trailer. (805 km) the new vehicle is driven.
Page 331 330 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Make certain that the load is secured in the trailer • Vehicles with trailers should not be parked on a and it will not shift during travel. When trailering grade. When parking, apply the parking brake on cargo that is not fully secured, dynamic load shifts the tow vehicle.
Page 332 STARTING AND OPERATING 331 − Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 4. Tongue weight rating for the trailer hitch utilized. Information” in “Starting and Operating” for the (This requirement may limit the ability to always proper inspection procedure.
Page 333 332 STARTING AND OPERATING − An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.
Page 334 STARTING AND OPERATING 333 Towing Requirements – Trailer Lights and Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven- pin wiring harness.
Page 335: Towing Tips
334 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE range can be selected when towing. How- ever, if frequent shifting occurs while in this range, use the AutoStick mode to select a lower gear range.
Page 336 STARTING AND OPERATING 335 specified for “police, taxi, fleet, or frequent trailer tow- − Extended driving at high RPM should be avoided to ing.” Refer to “Maintenance Schedule” for the proper prevent excess heat generation. A reduction in vehicle maintenance intervals. speed may be required to avoid extended driving at high RPM.
Page 337: Recreational Towing (Behind Motorhome, Etc.)
336 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND The parking brake must be firmly engaged and the MOTORHOME, ETC.) wheels chocked during driveshaft removal and installa- tion. The parking brake must remain engaged unless the Recreational towing is allowed ONLY if the driveshaft vehicle is securely and properly connected to the tow is removed.
Page 338: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS ▫ Preparations For Jacking ....353 Hazard Warning Flasher ....339 ▫...
Page 339 338 WHAT TO DO IN EMERGENCIES ▫ Towing This Vehicle Behind Another Vehicle Towing A Disabled Vehicle ....366 With A Tow Dolly ....368 ▫...
Page 340: Hazard Warning Flasher
WHAT TO DO IN EMERGENCIES 339 HAZARD WARNING FLASHER NOTE: With extended use the Hazard Warning flasher The Hazard Warning flasher switch is located in the may wear down your battery. switch bank near the bottom center of the instrument IF YOUR ENGINE OVERHEATS panel.
Page 341: Tirefit Kit - If Equipped
340 WHAT TO DO IN EMERGENCIES • You can also turn the temperature control to maximum WARNING! heat, the mode control to floor and the blower control to high. This allows the heater core to act as a You or others can be badly burned by hot engine supplement to the radiator and aids in removing heat coolant (antifreeze) or steam from your radiator.
Page 342: Tirefit Storage
WHAT TO DO IN EMERGENCIES 341 TIREFIT Storage TIREFIT Kit Components and Operation The TIREFIT kit is located in the trunk. 1. Sealant Bottle TIREFIT Location 2. Deflation Button — If Equipped 3. Pressure Gauge 4. Power Button...
Page 343 342 WHAT TO DO IN EMERGENCIES 5. Mode Select Knob Selecting Sealant Mode Turn the Mode Select Knob (5) to this 6. Sealant Hose (Clear with Yellow Cap) position to inject the TIREFIT Sealant 7. Air Pump Hose (Black) and to inflate the tire. Use the Sealant Hose (clear hose with the yellow cap) 8.
Page 344: Tirefit Usage Precautions
WHAT TO DO IN EMERGENCIES 343 • You can use the TIREFIT air pump to inflate bicycle TIREFIT Usage Precautions tires. The kit also comes with two needles located in • Replace the TIREFIT Sealant Bottle (1) and Sealant the Accessory Storage Compartment (located on the Hose (6) prior to the expiration date (printed on the bottom of the air pump) for inflating sport balls, rafts, bottle label) to assure optimum operation of the sys-...
Page 345 344 WHAT TO DO IN EMERGENCIES WARNING! (Continued) WARNING! (Continued) • Do not use TIREFIT or drive the vehicle under the • A loose TIREFIT kit thrown forward in a collision following circumstances: or hard stop could endanger the occupants of the vehicle.
Page 346: Sealing A Tire With Tirefit
WHAT TO DO IN EMERGENCIES 345 2. Verify that the valve stem (on the wheel with the WARNING! (Continued) deflated tire) is in a position that is near to the ground. • TIREFIT Sealant solution contains latex. In case of This will allow the TIREFIT Hoses (6) and (7) to reach the allergic reaction or rash, consult a physician im- valve stem and keep the TIREFIT kit flat on the ground.
Page 347 346 WHAT TO DO IN EMERGENCIES 3. Uncoil the Sealant Hose (6) and then remove the NOTE: Manual transmission vehicles must have the yellow cap from the fitting at the end of the hose. parking brake engaged and the shifter in NEUTRAL. •...
Page 348 WHAT TO DO IN EMERGENCIES 347 2. Connect the Power Plug (8) to a different 12 Volt Pressure Gauge (3) will decrease quickly from approxi- power outlet in your vehicle or another vehicle, if avail- mately 70 psi (5 Bar) to the actual tire pressure when the able.
Page 349 348 WHAT TO DO IN EMERGENCIES If the tire inflates to the recommended pressure or is at CAUTION! least 26 psi (1.8 Bar) pressure within 15 minutes: • The metal end fitting from Power Plug (8) may get 1. Press the Power Button (4) to turn off the TIREFIT kit. hot after use, so should be handled carefully.
Page 350 WHAT TO DO IN EMERGENCIES 349 If tire pressure is less than 19 psi (1.3 Bar) , the tire is too WARNING! badly damaged. Do not attempt to drive the vehicle further. Call for assistance. TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using If the tire pressure is 19 psi (1.3 bar) or higher: TIREFIT.
Page 351 350 WHAT TO DO IN EMERGENCIES 4. Have the tire inspected and repaired or replaced at the 3. Use the yellow cap on end of the Sealant Hose (6) to earliest opportunity at an authorized dealer or tire ser- depress the Sealant Bottle release button. The Sealant vice center.
Page 352: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES 351 JACKING AND TIRE CHANGING WARNING! (Continued) • The jack is designed to use as a tool for changing WARNING! tires only. The jack should not be used to lift the • Do not attempt to change a tire on the side of the vehicle for service purposes.
Page 353 352 WHAT TO DO IN EMERGENCIES 1. Open the trunk. 3. Remove the fastener securing the spare tire. 2. Lift the access cover using the pull strap. Spare Tire Fastener Opening The Access Panel...
Page 354: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 353 4. Remove the spare tire. WARNING! 5. Remove the fastener securing the jack. A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle. Always stow the jack parts and the spare tire in the places provided.
Page 355: Jacking And Changing A Tire
354 WHAT TO DO IN EMERGENCIES 2. Turn on the Hazard Warning flashers. Jacking and Changing a Tire 3. Set the parking brake. WARNING! 4. Place the shift lever into PARK (automatic transmis- Carefully follow these tire changing warnings to sion) or REVERSE (manual transmission).
Page 356 WHAT TO DO IN EMERGENCIES 355 1. Remove the spare tire, jack, and lug wrench. WARNING! (Continued) 2. If equipped with steel wheels, do not remove the • Do not let anyone sit in the vehicle when it is on a wheel cover at this time.
Page 357 356 WHAT TO DO IN EMERGENCIES WARNING! To avoid possible personal injury, handle the wheel covers with care to avoid contact with the metal edges and retention teeth. 3. Before raising the vehicle, use the lug wrench to loosen, but not remove, the lug nuts on the wheel with the flat tire.
Page 358 WHAT TO DO IN EMERGENCIES 357 4. Place the jack underneath the lift area that is closest to WARNING! the flat tire. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange. Raising the vehicle higher than necessary can make the vehicle less stable.
Page 359: Compact Spare Tire
358 WHAT TO DO IN EMERGENCIES 8. Install the lug nuts with the cone shaped end of the WARNING! nut toward the wheel. Lightly tighten the lug nuts. To avoid the risk of forcing the vehicle off the jack, do not A loose tire or jack thrown forward in a collision or tighten the lug nuts fully until the vehicle is lowered to hard stop could endanger the occupants of the ve-...
Page 360: Wheel Cover Or Center Cap Installation - If Equipped
WHAT TO DO IN EMERGENCIES 359 1. Mount the road tire on the axle. For vehicles equipped WARNING! with wheel covers, perform Steps 2 and 3. For vehicles equipped with center caps, proceed to Step 4. The limited-use spare tires are for emergency use only.
Page 361 360 WHAT TO DO IN EMERGENCIES snapping the cover over the two lug nuts. Do not use a hammer or excessive force to install the cover. 4. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
Page 362: Jump-Starting Procedures
WHAT TO DO IN EMERGENCIES 361 7. For vehicles equipped with center caps, install the so please follow the procedures in this section carefully. center cap by hand. Do not use a hammer or excessive NOTE: When using a portable battery booster pack force to install the center cap.
Page 363: Preparations For Jump-Start
362 WHAT TO DO IN EMERGENCIES Preparations for Jump-Start The battery is stored under an access cover in the trunk. Remote battery posts are located on the right side of the engine compartment for jump-starting. NOTE: The remote battery posts are viewed by standing on the right side of the vehicle looking over the fender.
Page 364: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 363 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
Page 365 364 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 366: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 365 8. Disconnect the opposite end of the positive (+) jumper FREEING A STUCK VEHICLE cable from the positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion.
Page 367 366 WHAT TO DO IN EMERGENCIES NOTE: Turn off the Electronic Stability Program (ESP) WARNING! before rocking the vehicle. Refer to “Electronic Stability Program,” or “Traction Control” in “Starting and Oper- Fast spinning tires can be dangerous. Forces gener- ating” for further information. ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires.
Page 368 WHAT TO DO IN EMERGENCIES 367 Towing This Vehicle Behind Another Vehicle (Flat If the transmission is not operative or if the vehicle is to Towing With All Four Wheels On The Ground) be towed more than 15 miles (24 km) or faster than Flat towing of vehicles is permitted within the following 30 mph (48 km/h), the vehicle must be transported using limitations:...
Page 369 368 WHAT TO DO IN EMERGENCIES CAUTION! (Continued) • Do not push or tow this vehicle with another vehicle as damage to the bumper fascia and trans- mission may result. If you must use the accessories (wipers, defrosters, etc.) while being towed, the ignition must be in the RUN position, not the ACC position.
Page 370: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Oil ......378 Engine Compartment — 3.5L ... . . 372 ▫...
Page 371 370 MAINTAINING YOUR VEHICLE ▫ Exhaust System ..... 387 Replacement Bulbs ....414 ▫...
Page 372 MAINTAINING YOUR VEHICLE 371 ▫ Engine ......422 Fluid Capacities ..... . 421 ▫...
Page 373: Engine Compartment - 3.5L
372 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.5L 1 — Integrated Power Module 6 — Engine Oil Fill 2 — Air Cleaner Filter 7 — Engine Oil Dipstick 3 — Brake Fluid Reservoir Access Cover 8 — Remote Jump Start (Positive Battery Post) 4 —...
Page 374: Engine Compartment - 5.7L
MAINTAINING YOUR VEHICLE 373 ENGINE COMPARTMENT — 5.7L 1 — Integrated Power Module 6 — Air Cleaner Filter 2 — Coolant Pressure Cap 7 — Engine Oil Fill 3 — Brake Fluid Reservoir Access Cover 8 — Engine Oil Dipstick 4 —...
Page 375: Onboard Diagnostic System - Obd Ii
374 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 376: Emissions Inspection And Maintenance Programs
MAINTAINING YOUR VEHICLE 375 Trip Odometer button to turn off the message. If the serviced, recently had a dead battery, or a battery replace- problem continues, the message will appear the next time ment. If the OBD II system should be determined not the vehicle is started.
Page 377: Replacement Parts
376 MAINTAINING YOUR VEHICLE 5. Approximately 15 seconds later, one of two things will as you normally would in order for the OBD II system to happen: update. A recheck with the above test routine may then indicate that the system is now ready. a.
Page 378: Dealer Service
MAINTAINING YOUR VEHICLE 377 DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 379: Engine Oil
378 MAINTAINING YOUR VEHICLE regular intervals, such as every fuel stop. The best time to CAUTION! (Continued) check the engine oil level is about five minutes after a • Your vehicle has been built with improved fluids fully warmed engine is shut off. that protect the performance and durability of Checking the oil while the vehicle is on level ground will your vehicle and also allow extended maintenance...
Page 380 MAINTAINING YOUR VEHICLE 379 regular intervals, such as every fuel stop. The best time to NOTE: Under no circumstances should oil change check the engine oil level is about five minutes after a intervals exceed 6,000 miles (10 000 km) or six months, fully warmed engine is shut off.
Page 381 380 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) – 5.7L Engine CAUTION! SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature Do not use chemical flushes in your engine oil as the starting and vehicle fuel economy.
Page 382: Engine Oil Filter
MAINTAINING YOUR VEHICLE 381 Synthetic Engine Oils Engine Oil Filter You may use synthetic engine oils provided the recom- The engine oil filter should be replaced with a new filter mended oil quality requirements are met, and the recom- at every engine oil change. mended maintenance intervals for oil and filter changes Engine Oil Filter Selection are followed.
Page 383: Engine Air Cleaner Filter
382 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter used to assure most efficient service. MOPAR engine air Refer to “Maintenance Schedule” for further information. cleaner filters are a high quality filter and are recommended. WARNING! Maintenance-Free Battery Your vehicle is equipped with a maintenance-free battery. The air induction system (air cleaner, hoses, etc.) can You will never have to add water, nor is periodic main- provide a measure of protection in the case of engine...
Page 384 MAINTAINING YOUR VEHICLE 383 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 385: Air Conditioner Maintenance
384 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! (Continued) For best possible performance, your air conditioner • The battery in this vehicle has a vent hose that should be checked and serviced by an authorized dealer should not be disconnected and should only be at the start of each warm season.
Page 386: Body Lubrication
MAINTAINING YOUR VEHICLE 385 Protection Agency and is an ozone-saving product. How- WARNING! ever, the manufacturer recommends that air conditioning • Use only refrigerants and compressor lubricants service be performed by authorized dealers or other service facilities using recovery and recycling equipment. approved by the manufacturer for your air condi- tioning system.
Page 387: Windshield Wiper Blades
386 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. Avoid using the wiper blades to remove frost or ice from When performing other underhood services, the hood the windshield. Keep the blade rubber out of contact with latch, release mechanism and safety catch should be petroleum products such as engine oil, gasoline, etc.
Page 388: Exhaust System
MAINTAINING YOUR VEHICLE 387 When refilling the washer fluid reservoir, apply some WARNING! washer fluid to a cloth or towel and wipe the wiper blades clean. This will help blade performance. Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care To prevent freeze-up of your windshield washer system must be exercised when filling or working around in cold weather, select a solution or mixture that meets or...
Page 389 388 MAINTAINING YOUR VEHICLE into the passenger compartment. In addition, inspect the CAUTION! exhaust system each time the vehicle is raised for lubri- • The catalytic converter requires the use of un- cation or oil change. Replace as required. leaded fuel only. Leaded gasoline will destroy the WARNING! effectiveness of the catalyst as an emissions con- trol device and may seriously reduce engine per-...
Page 390 MAINTAINING YOUR VEHICLE 389 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 391: Cooling System
390 MAINTAINING YOUR VEHICLE Cooling System applicable). If coolant is dirty or rusty in appearance, the system should be drained, flushed, and refilled with WARNING! fresh coolant. Check the front of the radiator for any accumulation of bugs, leaves, etc. If dirty, clean by gently •...
Page 392 MAINTAINING YOUR VEHICLE 391 Cooling System – Drain, Flush, and Refill CAUTION! If the engine coolant (antifreeze) is dirty or contains a • Mixing of engine coolant (antifreeze) other than considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough specified HOAT engine coolant (antifreeze), may rinsing to remove all deposits and chemicals.
Page 393 392 MAINTAINING YOUR VEHICLE • The manufacturer recommends using MOPAR CAUTION! (Continued) Antifreeze/Coolant 5 Year/100,000 Mile Formula • This vehicle has not been designed for use with HOAT (Hybrid Organic Additive Technology) or propylene glycol-based engine coolant (anti- equivalent. freeze). Use of propylene glycol-based engine •...
Page 394 MAINTAINING YOUR VEHICLE 393 NOTE: Mixing engine coolant (antifreeze) types will WARNING! decrease the life of the engine coolant (antifreeze) and • The warning words “DO NOT OPEN HOT” on will require more frequent coolant changes. the cooling system pressure cap are a safety pre- Cooling System Pressure Cap caution.
Page 395 394 MAINTAINING YOUR VEHICLE Disposal of Used Coolant engine coolant (antifreeze) freeze point or replacing en- Used ethylene glycol-based engine coolant (antifreeze) is gine coolant (antifreeze). Advise your service attendant a regulated substance requiring proper disposal. Check of this. As long as the engine operating temperature is with your local authorities to determine the disposal satisfactory, the coolant bottle need only be checked once rules for your community.
Page 396: Brake System
MAINTAINING YOUR VEHICLE 395 • Make sure that the radiator and coolant recovery If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be bottle overflow hoses are not kinked or obstructed. safely driven.
Page 397 396 MAINTAINING YOUR VEHICLE Overfilling of fluid is not recommended because it may WARNING! cause leaking in the system. Riding the brakes can lead to brake failure and Add enough fluid to bring the level up to the require- possibly an accident. Driving with your foot resting ments described on the brake fluid reservoir.
Page 398 MAINTAINING YOUR VEHICLE 397 WARNING! WARNING! (Continued) • To avoid contamination from foreign matter or • Use only manufacturer’s recommended brake moisture, use only new brake fluid or fluid that fluid. Refer to “Fluids, Lubricants, and Genuine has been in a tightly closed container. Keep the Parts”...
Page 399: Clutch Hydraulic System - Manual Transmission (If Equipped)
398 MAINTAINING YOUR VEHICLE bottom of the fill hole. Add fluid, if necessary, to maintain WARNING! (Continued) the proper level. Refer to “Fluids, Lubricants, and Genu- • Do not allow petroleum based fluid to contami- ine Parts” in “Maintaining Your Vehicle” for further nate the brake fluid.
Page 400: Automatic Transmission - If Equipped
MAINTAINING YOUR VEHICLE 399 Automatic Transmission – If Equipped CAUTION! (Continued) Fluid Level Check • The fluid level is preset at the factory and it does Regular automatic transmission fluid level checks are not not require adjustment under normal operating required.
Page 401 400 MAINTAINING YOUR VEHICLE Fluid and Filter Changes Special Additives Refer to “Maintenance Schedule” for further information. Automatic Transmission Fluid (ATF) is an engineered product and its performance may be impaired by supple- If the transmission is disassembled for any reason, the mental additives.
Page 402: Rear Axle
MAINTAINING YOUR VEHICLE 401 Rear Axle extreme hot or cold weather and other extreme condi- tions will have an adverse effect on paint, metal trim, and Fluid Level Check underbody protection. Check the fluid level by removing the fill plug on the The following maintenance recommendations will enable axle.
Page 403 402 MAINTAINING YOUR VEHICLE Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR Car Wash or equiva- such as steel wool or scouring powder that will lent, or a mild car wash soap, and rinse the panels scratch metal and painted surfaces.
Page 404 MAINTAINING YOUR VEHICLE 403 • If you detect any stone chips or scratches in the paint, Wheel and Wheel Trim Care touch them up immediately. The cost of such repairs is All wheels and wheel trim, especially aluminum and considered the responsibility of the owner. chrome-plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
Page 405 404 MAINTAINING YOUR VEHICLE Stain Repel Fabric Cleaning Procedure – If Interior Care Equipped Use MOPAR Fabric Cleaner or equivalent to clean fabric Stain Repel seats may be cleaned in the following man- upholstery and MOPAR Carpet Cleaner or equivalent ner: for carpeting.
Page 406 MAINTAINING YOUR VEHICLE 405 solvents, detergents, or ammonia-based cleaners to clean Do not use abrasive cleaning components, solvents, steel your leather upholstery. Application of a leather condi- wool or other aggressive material to clean the lenses. tioner is not required to maintain the original condition. Glass Surfaces All glass surfaces should be cleaned on a regular basis WARNING!
Page 407 406 MAINTAINING YOUR VEHICLE Cleaning Plastic Instrument Cluster Lenses If the belts need cleaning, use MOPAR Total Clean or The lenses in front of the instruments in this vehicle are equivalent, a mild soap solution, or lukewarm water. Do molded in clear plastic. When cleaning the lenses, care not remove the belts from the vehicle to wash them.
Page 408: Fuses
MAINTAINING YOUR VEHICLE 407 FUSES CAUTION! Integrated Power Module (IPM) • When installing the integrated power module The Integrated Power Module (IPM) is located in the cover, it is important to ensure the cover is prop- engine compartment. This module contains fuses and erly positioned and fully latched.
Page 409 408 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 15 Amp Washer Motor — — — Blue 30 Amp — Windshield Wiper — 25 Amp Powertrain Control Pink Natural Module (PCM) 30 Amp —...
Page 410: Rear Power Distribution Center
MAINTAINING YOUR VEHICLE 409 Cavity Car- Mini- Description tridge Fuse Fuse — — — — — — — — — — — — Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays.
Page 411 410 MAINTAINING YOUR VEHICLE CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 412 MAINTAINING YOUR VEHICLE 411 Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse 60 Amp — Ignition Off Draw (IOD) 30 Amp — Heated Seats – If Yellow Pink Equipped Cavity 1 of the Rear Power Distribution —...
Page 413 412 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse 13 * — — — — — — — 10 Amp AC Heater Control/ — — — Cluster/Security Mod- — — — ule –...
Page 414 MAINTAINING YOUR VEHICLE 413 Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 10 Amp Door Modules/Power — 10 Amp Cargo Light/Vehicle In- Mirrors/Steering Con- formation Module – If trol Module (SCM) Equipped — —...
Page 415: Vehicle Storage
414 MAINTAINING YOUR VEHICLE * Cavities 11, 12, and 13 contain self-resetting fuses in the fresh air and high blower setting. This will (circuit breakers) that are only serviceable by an autho- ensure adequate system lubrication to minimize the rized dealer. The cluster and the driver seat switch are possibility of compressor damage when the system is fused by the 25 Amp circuit breaker in cavity 11.
Page 416: Bulb Replacement
MAINTAINING YOUR VEHICLE 415 All of the interior bulbs are glass wedge base or glass BULB REPLACEMENT cartridge types. Aluminum base bulbs are not approved Low Beam Headlamp, High Beam Headlamp, and should not be used for replacement. Park/Turn Lamp — Models with Halogen LIGHT BULBS –...
Page 417: Front/Rear Side Marker Lamp
416 MAINTAINING YOUR VEHICLE NOTE: WARNING! • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to A transient high tension occurs at the bulb sockets of scratch the paint. HID headlamps when the headlamp switch is turned ON.
Page 418: Tail/Turn And Stop Lamp
MAINTAINING YOUR VEHICLE 417 Tail/Turn and Stop Lamp 1. Open the trunk. 2. Using a screwdriver, remove the tail lamp retainer. 4. Pull back the trunk liner. 5. Remove the remaining fasteners from the back of the tail lamp assembly. 3.
Page 419 418 MAINTAINING YOUR VEHICLE 6. Pull the tail lamp assembly clear from the vehicle to 7. Push the electrical connector locking tab to the side. access the bulbs. 8. Disconnect the electrical connector. 9. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the tail lamp assembly.
Page 420: Center Tail/Backup Lamp
MAINTAINING YOUR VEHICLE 419 12. Reinstall the tail lamp assembly, fasteners, electrical Center Tail/Backup Lamp connector, and trunk liner. See your authorized dealer for bulb replacement. 13. Reinstall tail lamp retainer. Center High-Mounted Stop Lamp (CHMSL) The CHMSL uses LED lamps that are not serviceable separately.
Page 421: License Lamp
420 MAINTAINING YOUR VEHICLE License Lamp 1. Remove the screws securing the lamp to the rear fascia. 2. Remove the bulb and socket assembly. 3. Disconnect the bulb from the socket assembly and install the replacement bulb. 1 — License Lamp Bulb 2 —...
Page 422: Fluid Capacities
MAINTAINING YOUR VEHICLE 421 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 3.5 Liter Engine 18.5 Gallons 70 Liters 5.7 Liter Engine 19 Gallons 72 Liters Engine Oil with Filter 3.5 Liter Engine (SAE 10W-30, API Certified) 6 Quarts 5.7 Liters 5.7 Liter Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System *...
Page 423: Engine
422 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. Engine Oil – 3.5L Engine Use API Certified SAE 10W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 424: Chassis
MAINTAINING YOUR VEHICLE 423 Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Automatic Transmission – If MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Equipped ATF+4 product. Brake Master Cylinder MOPAR DOT 3, SAE J1703 or equivalent should be used.
Page 426 MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ..428 Emission Control System Maintenance ..426 Maintenance Schedule ....426...
Page 427 426 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE MAINTENANCE SCHEDULE The Scheduled Maintenance services listed in bold type, The oil change indicator system will remind you that it is must be done at the times or mileages specified to ensure time to take your vehicle in for scheduled maintenance. the continued proper functioning of the Emission Control On Electronic Vehicle Information Center (EVIC) System.
Page 428 MAINTENANCE SCHEDULES 427 NOTE: “Understanding Your Instrument Panel” or under “In- • The oil change indicator message will not monitor the strument Cluster Description/Odometer/Trip Odom- time since the last oil change. Change your vehicle’s eter” in “Understanding Your Instrument Panel” for oil if it has been six months since your last oil change, further information.
Page 429 428 MAINTENANCE SCHEDULES • Check the fluid levels of the coolant reservoir, brake Required Maintenance Intervals master cylinder, and power steering, and add as Refer to the Maintenance Schedules on the following needed. pages for the required maintenance intervals. • Check all lights and other electrical items for correct operation.
Page 430 MAINTENANCE SCHEDULES 429 6,000 Miles (10,000 km) or 12,000 Miles (20,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 431: Service Schedule
430 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 24,000 Miles (40,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 432 MAINTENANCE SCHEDULES 431 30,000 Miles (50,000 km) or 36,000 Miles (60,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 433 432 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 48,000 Miles (80,000 km) or 48 Months Maintenance Service 42 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 434 MAINTENANCE SCHEDULES 433 54,000 Miles (90,000 km) or 60,000 Miles (100,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 435 434 MAINTENANCE SCHEDULES 66,000 Miles (110,000 km) or 72,000 Miles (120,000 km) or 72 Months Maintenance Service 66 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 436 MAINTENANCE SCHEDULES 435 78,000 Miles (130,000 km) or 84,000 Miles (140,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 437 436 MAINTENANCE SCHEDULES 90,000 Miles (150,000 km) or 96,000 Miles (160,000 km) or 96 Months Maintenance Service 90 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 438 MAINTENANCE SCHEDULES 437 102,000 Miles (170,000 km) or 108,000 Miles (180,000 km) or 108 Months Maintenance Service 102 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 439 438 MAINTENANCE SCHEDULES 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary.
Page 440 MAINTENANCE SCHEDULES 439 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (5.7L Engine). ❏ Inspect the brake linings; replace if necessary. ❏...
Page 441 440 MAINTENANCE SCHEDULES 126,000 Miles (210,000 km) or 132,000 Miles (220,000 km) or 132 Months Maintenance Service 126 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 442 MAINTENANCE SCHEDULES 441 138,000 Miles (230,000 km) or 144,000 Miles (240,000 km) or 144 Months Maintenance Service 138 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate tires. ❏ Change the engine oil and engine oil ❏...
Page 443 442 MAINTENANCE SCHEDULES † This maintenance is recommended by the manufacturer 150,000 Miles (250,000 km) or to the owner, but is not required to maintain emissions 150 Months Maintenance warranty. Service Schedule ❏ Change the engine oil and engine oil WARNING! filter.
Page 444: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Suggestions For Obtaining Service For Your Vehicle......445 Speech Impaired (TDD/TTY) .
Page 445 444 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... 451 Publication Order Forms ....449 ▫...
Page 446: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 445 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 447: Chrysler Group Llc Customer Center
446 IF YOU NEED CONSUMER ASSISTANCE • Vehicle delivery date and mileage This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- Chrysler Group LLC Customer Center solved with this process. P.O.
Page 448: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 447 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 449: Warranty Information
448 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 450: In Canada
IF YOU NEED CONSUMER ASSISTANCE 449 If NHTSA receives similar complaints, it may open an defect to the Canadian government should contact Trans- investigation, and if it finds that a safety defect exists in port Canada, Motor Vehicle Defect Investigations and a group of vehicles, it may order a recall and remedy Recalls at 1-800-333-0510 or go to campaign.
Page 451 450 IF YOU NEED CONSUMER ASSISTANCE LLC vehicles. A complete working knowledge of the These Owner’s Manuals have been prepared with the vehicle, system, and/or components is written in assistance of service and engineering specialists to straightforward language with illustrations, diagrams, acquaint you with specific Chrysler Group LLC ve- and charts.
Page 452: Traction Grades
IF YOU NEED CONSUMER ASSISTANCE 451 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 453 452 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 454 INDEX...
Page 455 454 INDEX About Your Brakes ....273,276 Airbag, Window (Side Curtain) ... 50,53,56 ABS (Anti-Lock Brake System) .
Page 456 INDEX 455 Automatic Headlights ....128 Keyless Transmitter Replacement (RKE) ..25 Automatic Oil Change Indicator ... . . 172 Location .
Page 457 456 INDEX Bulb Replacement ..... 414,415 Check Engine Light Bulbs, Light ......75,414 (Malfunction Indicator Light) .
Page 458 INDEX 457 Connector Selection of Coolant (Antifreeze) ..391,421,422 UCI ....... . 218 Corrosion Protection .
Page 459 458 INDEX Dipsticks Electronic Power Distribution Center (Fuses) ..409 Oil (Engine) ......378 Electronic Speed Control (Cruise Control) .
Page 460 INDEX 459 Checking Oil Level ..... 378 Engine Oil Viscosity ..... . 380 Compartment .
Page 461 460 INDEX Flash-To-Pass ......131 Additives ......317 Flat Tire Changing .
Page 462 INDEX 461 Garage Door Opener (HomeLink ) ... 142 Hands-Free Phone (Uconnect™) ....85 Gas Cap (Fuel Filler Cap) ....319,374 Hazard Gasoline, Clean Air .
Page 463 462 INDEX Heater ....... 232 Instrument Panel Lens Cleaning ... . . 406 Heater, Engine Block .
Page 464 INDEX 463 Keys ....... . . 12 Brake Assist Warning ....286 Kicker Sound System .
Page 465 464 INDEX High Beam Indicator ....169 Theft Alarm (Security Alarm) ....174 High Beam/Low Beam Select .
Page 466 INDEX 465 Lumbar Support ......121 Exterior Folding ......82 Heated .
Page 467 466 INDEX Oil Change Indicator ....172,181 Operating Precautions ....374 Oil Change Indicator, Reset .
Page 468 INDEX 467 Distribution Center (Fuses) ....409 Radio Operation ......232 Door Locks .
Page 469 468 INDEX Remote Trunk Release ..... 34 Satellite Radio Antenna ....225 Replacement Bulbs .
Page 470 INDEX 469 Heated ......122 Settings, Personal ......189 Height Adjustment .
Page 471 470 INDEX Automatic Transmission ....246 Sun Roof ......149 Cold Weather .
Page 472 INDEX 471 TIREFIT ......340 Safety ......287,296 Tires .
Page 473 472 INDEX Trailer Towing ......324 Transmitter Programming Cooling System Tips ....335 (Remote Keyless Entry) .
Page 474 INDEX 473 Vanity Mirrors ......84 Water Variance, Compass ..... . . 187 Driving Through .
Page 475 Chrysler Group LLC 10D491-126-AD Printed in U.S.A. 4th Edition...

Dodge Challenger 2010 Owner's Manual

Challenger

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

Chapters

Related Manuals for Dodge Challenger 2010

Summary of Contents for Dodge Challenger 2010
