SA611XA
Smeg 60cm ceramic cooktop
finishes black ceramic surface, frameless
size 520mmD x 590mmW x 49mmH
installation built-in one-piece hob
capacity four zones —
2 x 1800 watt, 180mm diameter
2 x 1200 watt, 145mm diameter
thermostat 9 heat settings per zone
safety lock 'on'
four residual heat indicators
power ON indicator
warranty two years parts and labour
Please note: Smeg ceramic cooktops are highly-
efficient cooking surfaces. They are at their most
efficient with flat-based cooking vessels. We
recommend stainless steel exterior based vessels
— that is, the surface of the vessel making contact
with the ceramic surface be of stainless steel. This
flat stainless steel surface will help preserve the
unblemished look of the ceramic surface and help
avoid scratching and permanent marking.
TOUCH–SENSOR CONTROLS
Each cooking zone has nine heat levels that can be digitally
increased or decreased sequentially
HIGH-SPEED COOKING
With visible high heat in three seconds and full heat
obtained in less than seven seconds, economies are
achieved by the time saving and the efficient fast use of
energy.
SPACE-SAVING DESIGN
Two pairs of cooking zones are diagonally positioned for
ergonomic access and maximum space efficiency
RESIDUAL HEAT SAFETY
Each cooking zone's control area will flash 'H' for residual
heat if the zone is no longer in use but still retains a residual
heat of 60º Celsius or above.
INSTALLATION
With only a 45mm displacement into the benchtop, the
cooktop allows for easy installation underbench of either
oven, dishwasher, cupboard or drawers.
LOW MAINTENANCE
This longest of wearing cooktop surfaces is cleaned easily
with wipe-over cream cleansers and a non-abrasive cloth.
Ceramic glass conditioners are available. The control
knobs are easily removable for improved cleaning access.
The raised trim and gaskets around the control knob shafts
should contain any accidental spills and boilovers within the
hob area for easy sponging up, and protect the electrical
componentry below the ceramic surface.
.
.
ID030412
Code SA611XA
