Specifi cations
Product Specifi cations
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VGA 15pin Mini D-sub
RGB/HV* 2 BNC (R,G,B,H,V)
HDMI HDMI Connector
DVD/HD* 2 BNC X 3
VIDEO1 BNC
VIDEO2* 2 BNC
S-VIDEO* 2 BNC X 2
Output Signal
DVI DVI-D 24pin
AUDIO
AUDIO STEREO Mini Jack
Input
HDMI Connector
DisplayPort Connector Digital Audio
AUDIO RCA (L/R)
Output
Speaker Output
Control
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible mounting interface
Power Management
Plug & Play
Power supply for Slot 2 type OPTION
Accessories
NOTE: Technical specifi cations are subject to change without notice.
80.0"/2032.2 mm diagonal
Pixel Pitch: 0.9225 mm
Resolution: 1920 x 1080
Color: Over 1073 million colors (depending on video card used)
Brightness: 460 cd/m 2 (Max.), 320 cd/m
Contrast Ratio: 5000:1
Viewing Angle: 88° (typ) @ CR>10
Horizontal: 15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical: 50.0 - 85.0 Hz
25.2 MHz - 162.0 MHz
1771.2 x 996.3 mm
Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV HDMI
Digital RGB VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz,
480i@60Hz
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Digital RGB DVI (HDCP)
Analog Audio Stereo L/R 0.5 Vrms
Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10W + 10W
RS-232C In: 9 Pin D-sub
RS-232C Out: 9 Pin D-sub (with daisy chain)
LAN: RJ-45 10/100 BASE-T
Remote IN: Stereo Mini jack 3.5
5.0 - 2.0 A @ 100-240V AC, 50/60Hz
Temperature* 3 : 0 - 40°C / 32 - 104°F
Humidity: 20 - 80% (without condensation)
Altitude: 0 - 3000 m (Brightness may decrease with altitude)
Temperature: -20 - 60°C / -4 - 140°F
Humidity: 10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1836.2 (W) x 1061.3 (H) x 86.9 (D) mm / 72.3 (W) x 41.8 (H) x 3.4 (D) inches
61.5 kg (135.6 lbs)
400 mm x 400 mm (M8, 4 Holes)
VESA DPM
VESA DDC2B, DDC/CI, DisplayPort
16 V/3.8 A
Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, Clamp x 1,
Screw x 1, CD-ROM
*3: When you use option board accessories, please contact your supplier for detailed information.
English-40
2 (Factory setting Typ.) @25°C
1 , 1920X1080 (60Hz), 1080p, 1080i
1 , 1920x1080 (60 Hz), 1080p, 1080i,
1 , 1920X1080 (60Hz)
1
, 1920X1080 (60Hz)
1
, 1920x1080 (60 Hz), 1080p, 1080i,
*1: Compressed image.
*2: Common terminal.
