- Page 1 USER'S MANUAL...
-
Page 2: Table Of Contents
Demands of speaker location ..............5 Mounting ....................... 5 SETTING UP AND TRANSPORT ................5 CONNECTION ..................... 5 TOS-UNIT ......................6 CLEANING ......................6 ASCENDO GMBH HÖLDERLINWEG 6 73257 KÖNGEN GERMANY Phone: 0049 (0) 7024 9288 84 Fax: 0049 (0) 7024 9288 64 MAIL: MAIL@ASCENDO.DE... -
Page 3: Overview
Application The ASCENDO Loudspeaker C7 intended for use in small to mid-size rooms (< 100 m³ You can use the C7 with amplifiers in the power range of 10 W to 350 W. Safety Warning Warning This Loudspeaker can produce high sound-levels. This may damage your ears permanently! -
Page 4: Operating Modes
Operating modes You can use the C7 a single-amp setup (one power amplifier for high- and low-frequency unit) or in a bi-amp setup (one power amplifier for the low-frequency-unit, one for the high- frequency unit). If your setup is single-amp you must bridge the high- and low-frequency unit with a high quality speaker cable. -
Page 5: Installation
Setting up and Transport Demands of speaker location • Use the C7 in closed rooms only. Do not expose the speaker to high humidity, direct water and direct sunbeam. • Take care of a minimum distance of 2 m of the speaker to monitors (TV, computer) and magnetic devices (audio/video-cassettes, floppy-disks, etc.). -
Page 6: Tos-Unit
Switch (8) in position AUS (Hemisphere) • One-Point-Source with homogenous hemisphere diversity Cleaning Clean the enclosure and stand of the ASCENDO C7 with a dry and soft cloth. Don’t use water or other chemicals. Don’t touch the tweeter and the woofer.
