Ascendo CCM5-P Owner's Manual

TECHNICAL DATA
CCM5-P
Point Source two-way Coaxial speaker
HF Driver:
Neodymium tweeter with soft dome
diaphragm
LF Driver:
130mm Woofer featuring Lightweight paper
cone and High-power, long-throw magnet
systems
Power Handling:
100W max (undistorted music program)
Frequency Range:
+/- 3dB from 80Hz to 20kHz (on wall)
Sensitivity:
1 W/1m 88dB
Nominal Impedance:
8 Ohm (6 Ohm minimum)
Speaker design:
Vented high absorbency, low resonance
enclosure
Terminals:
Gold-plated 4-way binding posts
Dimensions:
240 x 400 x 75mm (W x H x D)
ASCENDO Immersive Audio GmbH
Galgenmühle 5 | 91522 Ansbach
Germany
aia-cinema.com
mail@aia-cinema.com
CCM6-P
Point Source two-way Coaxial speaker
HF Driver:
Neodymium tweeter with soft dome
diaphragm
LF Driver:
165mm Woofer featuring Lightweight paper
cone and High-power, long-throw magnet
systems
Power Handling:
300W max (undistorted music program)
Frequency Range:
+/- 3 dB from 80Hz to 20kHz (on wall)
Sensitivity:
1 W/1m 93dB
Nominal Impedance:
8 Ohm (6 Ohm minimum)
Speaker design:
Vented high absorbency, low resonance
enclosure
Terminals:
Gold-plated 4-way binding posts
Dimensions:
260 x 440 x 88mm (W x H x D)
Marking by the "CE" symbol indicates
compliance of this device with the EMC
(Electromagnetic Compatibility) and LVD
(Low Voltage Directive) standards of the
European Community.
This product must be returned to the
separate collection system for electronic
products. Do not dispose this product
together with general household waste.
OWNER'S MANUAL
The information contained in this manual is subject to change without prior notice. The most current
version of this manual is available on our official website at: www.aia-cinema.com
Copyright © 2020. Ascendo Immersive Audio GmbH. All rights reserved.
CCM5-P
CCM6-P
PASSIVE MONITORS
Coaxial Cinema Series
On Wall & On Ceiling Speakers
