1-800-836-7432
Warning!
Improper installation,
adjustment, alteration, service,
or maintenance can cause
injury or property damage.
Please read instructions before
installing, operating or
servicing the TOPAZ unit.
Avertissement !
Le fait de modifier ou de mal
installer, régler, réparer ou
entretenir cet appareil peut
entraîner des blessures ou des
dommages matériels. On doit
lire attentivement les directives
d'installation, d'utilisation et
d'entretien avant de manipuler
l'unité TOPAZ
This manual is the property of
the owner. Leave with the unit
when set-up and start-up are
complete. TEMP-AIR Inc.
reserves the right to change
design and specifications
without prior notice.
P o r t a b l e A i r C o n d i t i o n e r s
Owner's Manual
Models: TZ-12AB - TZ-60AB4
Unit Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Rating Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
General Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Optional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Unit Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Replacement-Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Wiring Schematic, TZ-12AB, TZ-24AB and TZ-36AB . . . . . . . . . . . . . . . .14
Wiring Schematic, TZ-18AB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Wiring Schematic, TZ-60AB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Wiring Schematic, TZ-60AB4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Are you equipped to
handle the heat?
Advertisement
Table of Contents
Related Manuals for Topaz TZ-12AB
Summary of Contents for Topaz TZ-12AB
-
Page 1: Table Of Contents
Replacement-Parts List .........12 installing, operating or Wiring Schematic, TZ-12AB, TZ-24AB and TZ-36AB ....14 servicing the TOPAZ unit. -
Page 2: Unit Specifications
Portable Air Conditioners Unit Specifications Rating Information SPECIFICATIONS TZ-12AB TZ-18AB TZ-24AB TZ-36AB TZ-60AB TZ-60AB4 Cooling Capacity, BTU/hr 11,900 17,200 28,300 41,000 76,500 77,500 Power Supply Volts/Ph/Hz/Amps 115/1/60/15 115/1/60/15 208-230/1/60/20 208-230/1/60/30 208-230/1/60/60 460/3/60/20 Thermostat Control Mechanical Mechanical Mechanical Mechanical Mechanical Mechanical... -
Page 3: Inspection
Note: Wait four minutes to restart unit after high- pressure safety switch trips. General Requirements Topaz Portable Air Conditioners are designed for ease of Freeze Protection Control operation and rugged dependability. Follow installation The TZ-12AB, 24AB, 36AB, 60AB and 60AB4 models and maintenance instructions completely. -
Page 4: Optional Features
A hose runs from the unit to a convenient drain or outdoor location. Filter Cord Kit (LCDI) (TZ-12AB, 18AB, 24AB, 36AB) All units are equipped with removable, washable, The LCDI cord set provides both personal shock as well aluminum-mesh air filters. Located behind the return-air as cord arcing and fire protection. -
Page 5: Installation Instructions
The cooling circuit will cycle on and off. within fifteen working days. TOPAZ requires minimal installation. Plug unit in proper NEMA receptacle, and Press the COOL/FAN AUTO switch for cycling the it begins to cool immediately. - Page 6 Do not allow water to enter condenser fan outlet or the thermostat. Belt Tension, (models TZ-60AB and TZ-60AB4 only) Topaz models TZ-60AB and TZ-60AB4 are equipped with adjustable sheaves on the evaporator and condenser fans. Conditioned-air and condenser-air are controlled using double-inlet, forward-curved fans driven by belt and sheave combinations.
-
Page 7: Troubleshooting Guide
Setting may be too high. Check and reset. Thermostat may be out of calibration or defective. Replace. Electrical Panel Check output of transformer. -24-Volt transformer defective (TZ-12AB, 18AB, If not supplying 24 volts, replace. 24AB, 36AB and 60AB only) -Contactor coil defective Replace. - Page 8 Remove obstruction. and shuts unit down Freeze protection control not operating Check that control is securely attached to correctly (TZ-12AB, 24AB, 36AB, 60AB evaporator coil’s outlet and that insulation and 60AB4 only) is in place. Check wiring connections to freeze protection control.
-
Page 9: Installing Replacement Parts
Ceiling-Panel Duct Kit 1. Secure one end of the duct to the ceiling-panel adapter and the other end over the unit’s duct collar. Fan Motors (TZ-12AB through TZ-36AB) 2. Place the ceiling-panel adapter under suspended 1. Remove cabinet’s side panels. -
Page 10: Accessories
D e e s s c c r r i i p p t t i i o o n n NK-1 two, 4-in nozzles with attachment kit, TZ-12AB NK-2 two, 6-in nozzles with attachment kit, TZ-18AB, TZ-24AB and TZ-36AB... -
Page 11: Replacement-Parts List
Replacement parts List Description Part Number TZ-12AB TZ-18AB TZ-24AB TZ-36AB TZ-60AB TZ-60AB4 • • service valve, 5/16-in 88400.284 • service valve, 3/8-in 88400.249 • • • • • • service valve, 1/2-in 88400.250 service valve, 5/8-in 88400.251 • service valve, 3/4-in 88400.252... - Page 12 Description Part Number TZ-12AB TZ-18AB TZ-24AB TZ-36AB TZ-60AB TZ-60AB4 • • door handle 83800.004 • • • • • • condensate-pan switch 87500.128 • evaporator lter 83200.171 • • 83200.172 • 83200.173 • • 83200.174 • condenser lter 83200.160 •...
-
Page 13: Wiring Schematic, Tz-12Ab, Tz-24Ab And Tz-36Ab
Portable Air Conditioners Wiring Schematic, TZ-12AB, TZ-24AB and TZ-36AB TOPAZ Owner’s Manual ®... -
Page 14: Wiring Schematic, Tz-18Ab
Portable Air Conditioners Wiring Schematic, TZ-18AB... -
Page 15: Wiring Schematic, Tz-60Ab
Portable Air Conditioners Wiring Schematic, TZ-60AB TOPAZ Owner’s Manual ®... -
Page 16: Wiring Schematic, Tz-60Ab4
Portable Air Conditioners Wiring Schematic, TZ-60AB4... - Page 17 P o r t a b l e A i r C o n d i t i o n e r s...
- Page 18 TEMP-AIR 3700 West Preserve Boulevard Burnsville, Minnesota 55337-7746 1-800-836-7432 89500.316 © 2010 TEMP-AIR, Inc. Printed in USA TOPAZ Owner’s Manual ®...
