  • Page 1 M-DVD5561R DVD RECEIVER 6.2” DISPLAY OWNER’S MANUAL...
  • Page 2 P r e c a u t i o n s Never disassemble or adjust the unit without any professional guide. For details, please consult any professional car shop / dealer for inquiry. If the front panel or TFT monitor is squalid, please use a clean silicone cloth and neutral detergent to wipe off the spot.

  • Page 3: Dolby Digital

    D e c l a r a t i o n s Manufactured under license from Dolby Laboratories. Dolby Digital: “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from Dolby Laboratories. Dolby Digital and Dolby Pro Logic II(x): “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories.

  • Page 4: Table Of Contents

    Contents Before using ....Front panel Pause..... 11 Remote control..... 02 Stop...... 11 Fast rewind Fast forward..Basic operations Play the next or previous file... Power on/off.
  • Page 5 Contents Voice transfer....18 Hang p....18 phone book... 18 Scan ..19 Look for calling record Play music....19 ....

  • Page 6: Before Using

    Before using Front panel M-DVD5561R 1.[NAV] key: Enter the GPS navigation system or exit 2.[MENU] key: Return to the home menu ] key: Turn on/off the screen brightness and enter the nighttime mode ] knob: ajust volume Turn mute on/off(short press) Turn the unit on or off(long press) 5.
  • Page 7 Before using Radio preset scan/Radio auto preset Select the following sources: MODE POWER RADIO DISC TITLE MENU ANGLE SUBTITLE iPod BAND GOTO REPT A-B REPT DVB-T SETUP AUX1 AUX2 Switch to the current playbck source and the main menu(DVD) ZOOM PROG Power on/off Select the title of DVD...
  • Page 8 Before using Notes of remote control using 1) Aim the remote control at the remote sensor on the unit. 2) Remove the battery from the remote control or insert a battery insulator if the battery has not been used for a month or longer. 3) DO NOT store the remote control under direct sunlight or in high temperature environment, or it may not function properly.

  • Page 9: Remote Control

    Basic operations Power on/off ； Turn on short-press knob in the front panel or [POWER] in the remote control Turn off: after being turned off by long-pressing in the front panel MUTE Short-press knob in the front panel or MUTE key in the remote control, to shut the audio output from system.

  • Page 10: Radio Mode

    Radio mode Select Radio mode Enter Main Menu and choose RADIO mode. 00:12AM Radio 87.50 90.00 98.00 87.50 106.00 108.00 87.50 BAND SCAN Select band [BAND] Press [BAND]in the remote control, [FM/AM] in the front panel or in the user interface, to choose a band among FM1, FM2, FM3, AM1 and Am2. Auto tuning Short press in the front panel, searching for a station along the...

  • Page 11: Eq Selection

    Radio mode selection Press the icon and enter the EQ setup Recall the preset stations When you want to listen the store station,select the P1-P6 on the list and fleetly listen to the station. 00:12AM Radio 87.50 90.00 98.00 87.50 106.00 108.00 87.50...

  • Page 12: Rds Mode

    RDS mode The unit provides basic functions of RDS, including AF (Alternative Frequency), TA (Traffic Announcement) and PTY (Program Type) Selection. AF function Alternative Frequencies Lists are used for the same program service and used in conjunction with the PI code (Program Identification code)to assist automatic tuning. Using this information, a radio can automatically search out another station that is playing the same material.

  • Page 13: Insert A Disc

    DVD mode Insert a disc Upon inserting a disc, the unit will switch to [DISC] mode automatically. Notes: ① Please confirm whether there is a disc in the unit before you insert another one. ② Some recorded discs, such as CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW cannot be played back because of different recording status.

  • Page 14: Onscreen Control Icons

    D V D播 放 源 DVD mode Onscreen control icons Disc type MP3/WMA Picture Icon Numeric Numeric Numeric Numeric Numeric keypad keypad keypad keypad keypad Display Display Display Display Display Setting Setting Setting Setting Setting Fast forward Fast forward Fast forward Fast forward Fast rewind Fast rewind Fast rewind...

  • Page 15: Dvd Mode

    DVD mode Continued Disc Picture(picture type MP3/WMA in disc can't Icon be read) MENU MENU PLAY ZOOM ZOOM ZOOM ZOOM ANGLE ANGLE display playback information Channel Channel AUDIO switching switching MUSIC Music file PHOTO Picture file Picture file VIDEO Vedio file Random Notice: “return the last menu”icon is always on the fixed position，...

  • Page 16: Play

    DVD mode Play Insert the disc into the disc slot with label side facing up and play starts automatically. Pause When play the audio/vedio file,press the to stop and the top left corner of screen shows[stop ], press the icon again and continue to play. Stop For audio files, press the...

  • Page 17: Repeat A-B

    DVD mode Repeat A-B When a DVD, VCD or CD disc is played back, you can play back the contents between the time points from A to B repeatedly: REPEAT A- REPEAT B- A- B CANCEL Random playback You can play audio tracks files in random order During play CD touch...

  • Page 18: Select A Particular File

    DVD mode Select a particular file During playing DVD disc,touch anywhere except for the upper left corner to display menu on the screen. For DVD touch the icon to display information and shown as below please input title: input area choose area of the track and number delete the input track and number affirm the input track and number...

  • Page 19: Playback Information

    DVD mode Playback information Touch the top center area of TFT LCD when playing back DVD and VCD discs and the playback information will be displayed on the top area of the TFT. Notice: Only when open the [OSD] mode. 、For DVD: 00: 01: 34 TT 1/11...

  • Page 20: Usb Mode

    USB mode Open the source menu and then select mode Notice: 1. If there are audio files supported in the USB stick, the system will enterthe audio files menu automatically. If there are no audio files, but there are video files supported in the USB stick, the system will enter the video files menu automatically.

  • Page 21: Playback Information Display

    USB mode Playback information display In the video full screen mode, press the [KEY] icon under the screen, the display control menu will appear. Press the [ OSD ] icon to select the playing back information display on the upper of screen. Rotate picture Press anywhere on the screen except the upper left corner, the display control menu will appear.

  • Page 22: Bluetooth Mode

    Answer Call Record Phone book Pairing Manual connect Search for Bluetooth device with the device " " Select M-DVD5561R in the pairing list Enter default password " 0000 " " " If pairing succeeds the user interface display BT Connected...

  • Page 23: Auto Answer

    Bluetooth mode Auto answer By default,all incoming calls are received automatically. Touch the icon turns bright if there is incoming call the call will switch Auto Answer to the mobile telephone automatically and display the phone number Touch the icon turns gray if there is incoming call you need to answer Auto...

  • Page 24: Look For Calling Record

    Bluetooth mode Look for call record Call Touch the icon on the bluetooth interface to enter the menu,then the Record menu list displays five options:Delete One、Delete All、Received Call、Missed Call、Dialed Call,touch the anyone to the menu. If you want to exit the menu,touch the [ ]. Call REC Delete One Delete All...

  • Page 25: Dvb-T

    DVB-T mode Factory Default...

  • Page 26: Ipod Mode

    iPod mode Select iPod as playing source Current source will switch to iPod automatically after the stable connection between the unit and the iPod player is constructed iPOD Composers Repeat Shuffle MODE Operation 1 Operate the main menu by pressing the icons on the left side of screen before the screen is not full screen 、...

  • Page 27: Other Modes

    Other modes External peripheral devices with RCA audio and video outputs can be connected with the unit. For more details,please refer to( Electrical Connections Overall Diagram). Open the 'SOURCE MENU',and select 'AUX-1' or 'AUX-2'to enter AUX IN mode. REARVIEW The reaview camera can be connected with the unit. For more details,please refer to (Electrical Connections Overall Diagram).

  • Page 28: Setup

    SETUP Setup Steps 1.Enter setup menu Press the [SETUP] icon on the main menu,the setup main menu shown as below: SETUP General Time Radio Video Calibration Volume Illumination setup Blue Reset setting Version 2.Setup Illumination setup Repeatedly press the on the screen to select the lamplight. Blue Reset setting Press the [OK] on the screen to start to reset the unit.

  • Page 29: Gps

    SETUP After the map card is inserted press the icon on the main source menu to enter navigation system The path is default shown as below SETUP General Time Radio Video Calibration Volume Notice: The path of the map stored for your reference.To access GPS mode,you can press the[NAV] button on the front panel or press the [GPS]icon on the main menu.

  • Page 30: Calibration

    SETUP Calibration When the touch operation is not sensitive or valid,you should calibrate the touch screen through TS CAL Screen function. SETUP General Time Radio Video Calibration Volume Do you want to Calibrate? Press the [Calibration] icon on the setup menu to enter.
  • Page 31 Audio control allows you to easily adjust the audio system to get the best possible sound effect. Procedures of EQ setup 1.Enter EQ setup mode Press the icon on the user interface. Audio BASS SUB OUT SUB FREQ:OFF EQ:USER LOUD:OFF 2.Select EQ mode a.There are following equalizer options: USER/POP/ROCK/CLASS.

  • Page 32: Troubleshooting

    Troubleshooting What appears to be trouble is not always serious. Please check the following points before calling a service center. Problem Cause Corrective action General Install new fuse with correct rating. Unit fuse blown. Unit can not Car battery fuse blown. Install new fuse with correct rating.
  • Page 33 Troubleshooting (Continued) Problem Cause Corrective action Disc playback A disc inside the unit already. Eject current disc and insert new one. Cannot insert disc Disc is warped or scratched. Use disc in good condition. Disc is dirty or wet. Clean disc with soft cloth. Disc does not Incompatible disc is used.

  • Page 34: Device Connection

    Device connections Notes of connection  This unit is designed to be used in a vehicle with a 12-volt battery and negative grounding. Before installing this unit to a recreational vehicle, a bus, or a truck, make sure the battery voltage is appropriate for this unit to be used, otherwise, install a transformer by professional to convert the output voltage to 12V.

  • Page 35: Device Connections

    Device connections Control Cables Auto Brightness Control To avoid the display being too bright at night time, if the headlight cable is connected to ILLUMI, turning on the headlight will dim the backlight of the TFT LCD and vice versa. Telephone Mute If the MUTE cable is connected to a car phone, other audio outputs mute when one call is received by the car phone.
  • Page 36 Device connections Parking Brake Cable Connections Parking Brake Lead Green Wire Battery Car Frame Brake Light Parking Brake Switch Parking Brake Switch Reverse Driving Cable Connections Reverse Driving Signal Light Car Frame Pink Cable Reverse Driving Cable Car Battery Car Frame Gearbox...

  • Page 37: Specifications

    Specifications Geneal 12V(DC) Reference Supply Voltage ............. Operating Voltage Range..........10.5～15.8V(DC) Max Operating Current................15A Grounding System..........Car Battery Negative Pole Dimensions(WXHXD)............178X100X173mm Weight(main unit)................2.5kg ≥ Signal Noise Ratio................55dB Residual Noise Sensitivity(S/N=30dB)..........18dBμV Frequency Response(±3dB)..........40Hz~12.5KHz Station Seeking Level..............20~28dBμV ≤ Distortion..................1.5％ ≥ Stereo Separation(1KHz)..............25dB Antenna Impedance................75Ω...
  • Page 38 Specifications Environment Operating Temperature............-10℃~＋60℃ Storing Temperature..............-20℃~＋70℃ Operating Humidity..............45%~80%RH Storing Humidity..............30%~90%RH Notice: When the unit is operated extremely, such as operated with maximum power output for a ° long time, or the temperature is over 70 C, it will enter heat protection mode, the volume will be lower automatically.

  • Page 39: Region Code

    Specifications Region code According to DVD sale region, the whole world is divided into six regions. A DVD disc can be played back only when its region code is compatible with that of the player in use. Region 1: USA, Canada, East Pacific Ocean Islands; Region 2: Japan, West Europe, North Europe, Egypt, South Africa, Middle East;...

  • Page 40: Appendix

    Appendix Overall wiring diagram Notice: connect the AV cable to the AV IN socket on the front panel.
  • Page 41 P/N:127075002658...
