CONTROL SYSTEM

Fitting The Shark Control System
The Shark Controller should be mounted on the Powerchair using the bracketry supplied
and connected to the Powerchair electrical system.
The Shark Controller on your Powerchair determines which side you would like the
Controller located. (This should have been specified at the time your Powerchair was
ordered, but the machine is designed in such a way that it can be changed should this
prove necessary)
The sliding mounting arm should be secured to the underside of the controller, then the
arm should be located in its mounting bracket under the armrest pad, and secured in the
appropriate position with the screw fitting provided.
The Shark Controller is supplied with a battery charger indicator, all six lights indicate fully
charged batteries.
(See diagnostics section of this manual for further information).
Note 1: Changing the Controller from one side of the chair to the other involves the
relocation of the sliding mounting arm and relocation of the controller cable.
Note 2: The Shark Controller has a sleep mode, the controller will turn itself off after 10
minutes if not in use (this is to conserve battery power). To regain power simply depress
the power button or deflect the joystick.
Controller Arm
Adjustment
Speed Controller Joystick
5
