- Page 1 MiTraveler 970 Android 4.0 9.7” Tablet User Manual...
-
Page 2: Table Of Contents
Tablet of Contents Specifications………………………………………………………………….1 What’s inside the box…………………………………………………………1 Tablet Parts……………………………………………………………………2 Getting started………………………………………………………………...4 Connection to Internet………………………………………………………..7 Task Bar……………………………………………………………………….8 Install and Uninstall…………………………………………………………..9 Camera……………………………………………………………………… .9 HDMI………………………………………………………………………….11 Trouble Shooting…………………………………………………………….11... -
Page 3: Specifications
Specifications Display: 9.7 inch 1024X768 Resolution Capacitive screen CPU: Boxchip A10 RAM: 1GB DDR Internal Storage: 16GB Expansion Memory: USB & TF card, 32GB Max. Built-In Wireless: 802.11b/g/n AC Adapter: DC 5V-2A Operating System: Android 4.0 What’s Inside The box 9.7”... -
Page 4: Tablet Parts
Tablet Parts 1 Headset Port 2 5Pin USB Port 3 TF card slot 4 HOST 5 HDMI 6 DC Jack 7 Power ON/OFF button 8 RESET Button 9 Back Button 10 Volume + 11 Volume -... -
Page 5: Getting Started
Getting Started Battery Charging The tablet has a built-in rechargeable Li-polymer battery. 1. To charge connect the AC power adapter to the DC jack on the right side of the tablet. ” in the tablet, it show the battery is charging. 2. - Page 6 Removing TF card 1. Close all applications and documents which have been opened from the TF card. 2. Select “Setting” and find “ Storage” then click “Unmount SD card”. 3. A prompt will be seen on the screen saying “ SD card safe to remove” 4.
- Page 7 How to connect with computer Note: first, put the switch to Device status, Before transferring documents, you need set to store mode for the tablet. 1. Use USB cable to connect tablet with computer. Notice bar will appear notice cue. 2.
-
Page 8: Connection To Internet
Connection to Internet Wireless: 1. Select “ Settings” 2. Select “Wi-Fi” and slide OFF to ON status. 3. All detected wireless networks in the area will be listed on the right. Click to select desired wireless connection. 4. Enter WEP key or network key if necessary. 5. -
Page 9: Task Bar
Web Browsing Connect to the internet and launch the browser. Task Bar The Task Bar will show the following: SD card, Battery, Time, Return/Back, Desktop, Menu and Wireless micro SD card (TF card) Battery Time Return/Back Destktop Wifi network... -
Page 10: Install And Uninstall
Install and Uninstall Install from memory card or USB drive Please go to APK Manager，Select “Install” and then select the file with the extension name .apk in the memory card. Select “Install” to install the software. Install application from internet You can use App Market to search any application you want, after download finish it will automatic install ** Use Play Store application on the desktop to find more... - Page 11 1.Touch the icon at the bottom right and you can save your photos in DCIM/Camera directory in TF card. 2. Move the icon on the right and you can switch camera mode to film mode. 3. Touch the icon on the top right to see the previous picture and you can also delete, share, set it as the wallpaper or contact profile.
-
Page 12: Hdmi
HDMI You can switch the video to play it on the HDMI display equipment (such as TV with a HDMI interface) by HDMI. The maximum output resolution is 2160p and its method is shown as follows: 1. Turn on the Tablet; 2. - Page 13 Tap the application you want to close. A pop-up window will be displayed. Tap “Stop” to close that application. Mandatory Power off 1. Press and hold the power button for 7 seconds and the device will be powered off. 2. Press the reset button on the right and the device will be forced to be powered off.
