By Pacifi c Energy
INSTALLATION & OPERATION GUIDE
ALDERLEA CAST IRON WOOD STOVE
MODELS T4, T5,T5 Classic, T6
SAFETY NOTICE
If this stove is not properly installed, a house fi re may result. For your safety,
follow the installation instructions. Contact local building or fi re officials about
restrictions and installation inspection requirements in your area.
PLEASE SAVE THESE INSTRUCTIONS
TESTED and LISTED to
CAN/ULC S627 AND UL 1482
Meets the Environmental Protection Agency's
July 1990 Particulate Emission Standards
310510-28 T4-5-6
5055.202
Advertisement
Table of Contents
Related Manuals for Alderlea T4
Summary of Contents for Alderlea T4
-
Page 1: Safety Notice
By Pacifi c Energy INSTALLATION & OPERATION GUIDE ALDERLEA CAST IRON WOOD STOVE MODELS T4, T5,T5 Classic, T6 SAFETY NOTICE If this stove is not properly installed, a house fi re may result. For your safety, follow the installation instructions. Contact local building or fi re officials about restrictions and installation inspection requirements in your area. -
Page 2: Table Of Contents
Blower Operation ....................18 APPENDIX A fire officials about Troubleshooting ....................19 r e s t r i c t i o n s a n d T4 Replacement Parts ..................20 installation inspection T5 Replacement Parts ..................21 T6 Replacement Parts requirements in your ..................22... -
Page 3: Safety And Maintenance
Replacement glass can be obtained from your dealer. Use ceramic glass only. Do not substitute with any other CAUTION: type. T4 – 16.250” x 10.5” x 5mm • do not overtighten, tighten screws very carefully T5 – 17.25” x 11.395” x 5mm •... -
Page 4: Creosote
Do not burn household trash, cardboard, plastics, construction lumber, treated or beach wood (salt from beach wood will corrode your fi replace and void your warranty). Do not leave the air inlet wide-open for extended periods of time. Keep a fi re extinguisher handy. 310510-28 T4-5-6... -
Page 5: In Case Of A Chimney Fire
We recommend that our woodburning hearth products be installed and serviced by professionals who are certifi ed in the U.S. by the National Fireplace Institute ® (NFI) as NFI woodburning Specialists or who are certifi ed in Canada by Wood Energy Technical Training (WETT). 310510-28 T4-5-6... -
Page 6: Appliance Dimensions
Appliance Dimensions Fig #1 26” 20 3/4” 5 3/4” MODEL T4 28 1/8” 25” 28 1/2” MODEL T5 & 10 1/8” T5 CLASSIC 29 3/4” 29 1/4” 28 5/8” 8 1/2” MODEL T6 29 13/16” 310510-28 T4-5-6... - Page 7 Outside Air Opening Dimensions 3 1/8" 4 1/8" OUTSIDE AIR INLET 1 1/4" ALT4 4 1/8" OUTSIDE AIR INLET 2 5/16" * CENTERLINE OF CHIM- NEY OUTLET ALT5 & ALT5 CLASSIC 4 1/8" OUTSIDE AIR INLET 3/8" ALT6 310510-28 T4-5-6...
-
Page 8: Installation - Residential
Clearances may be reduced with various heat insulating materials. Consult local fi re codes and authorities for approval. 3. Alternately, for close clearances, use a listed double-wall connector. See Figures #2a, #2c & #2e. Fig #2 Minimum Clearances to Combustibles – Residential MODEL T4 15” 10” 12" 11" 20.75”... -
Page 9: Minimum Clearances To Combustibles – Residential
11" Fig #2e 4" 6” 5" 18.75” 9” 10" 18" 17.5” 14.5” 20" 15" 12” 14" 15” 16" DOUBLE WALL 24.75” 26" 15” 16" 27.75” CONNECTOR 28" 4" ALCOVE: Min. Height 7 1/2 feet Max. Depth 4 feet 310510-28 T4-5-6... - Page 10 The CEILING HEIGHT chimney must be suitably supported CHIMNEY CONNECTOR by the chimney manufacturer's listed offset support. T4 - 56 3/4” (1441 mm) T5 - 55 1/4” (1403 mm) T6 - 56 1/2” (1409 mm) 48" (1219 mm) NON-COMBUSTIBLE...
-
Page 11: Installation Procedure
Use holes provided in collar to secure pipe with two screws. 5. Install the remaining lengths of pipe, one on top of the other, to the fi nished height of the chimney connector and secure to each other. 310510-28 T4-5-6... -
Page 12: Installation - Mobile Home
(see Figure #3, Page 9). Install all components to the connector or chimney manufacturer's installation requirements. Consult your chimney supplier for installation advice. Fig #4a Minimum Clearances to Combustibles – Mobile Home MODEL T4 DOUBLE WALL CONNECTOR 12” 8" 8"... -
Page 13: Minimum Clearances To Combustibles – Mobile Home
DOUBLE WALL CONNECTOR 8" 8" 18" 22" 16" 28" 8" Fig #4c Minimum Clearances to Combustibles – Mobile Home MODEL T6 DOUBLE WALL CONNECTOR 7” 5” 8" 8" 15.5” 18" 19.75” 22" 14” 16" 26.75” 28" 5” 8" 310510-28 T4-5-6... -
Page 14: Listed Chimney And Chimney Connector For Mobile Home Installation
CL48 SDP-P SDT-P 2' Chimney length T-24 HS 24 CL24 SDP-P SDT-P Roof fl ashing RF17 T-SFA 8RFFU SDP-F SDT-F Storm collar T-SC TGSC PL-ASCG SDP-SC SDT-SC Spark arrestor rain cap XCPE RCSA RCSA T-CT 6PL-MPC SDP-C SDT-C 310510-28 T4-5-6... -
Page 15: Floor Protector
T5 - 34” T6 - 36” T6 - 41 1/2” This protection must extend as follows: Minimum Overall Depth T4 - 43 1/4” Minimum Overall Depth T4 - 33 1/4” T5 - 40 1/2” T5 - 50 1/2” In Canada: 18" (457 mm) on the fi ring side... -
Page 16: Operation
It is damp if it turns black and lights within three minutes. If it sizzles, hisses and blackens without igniting in fi ve minutes it is soaked and should not be burnt. 310510-28 T4-5-6... -
Page 17: Lighting For The First Time
3. Use wood of different shape, diameter and length (up to 18"). Load your wood endwise (side to side with Model T4) and try to place the logs so that the air can fl ow between them. Always use dry wood. -
Page 18: Restarting After Extended Or Overnight Burns
Ash Chute Operation: Your Alderlea stove is equipped with an ash chute system to ease removal of ash from the ash lip area. To use this system, fi rst pull out the ash pan approximately 2”... -
Page 19: Disposal Of Ashes
Remove retaining pin located at the rear top of the fi rebox, just below the baffle. (Remove rail extensions in front of Baffle. T4 Only) Lift baffle up and pull forward to disconnect from the supply tube. Tilt baffle sideways to drop down and remove from fi rebox. -
Page 20: Troubleshooting
1. Combustion air supply blocked • Check outside air supply for obstruction • Check that room air cover is removed 2. Draft too low • Chimney plugged or restricted, -inspect and clean • Chimney oversized or otherwise unsuitable, -consult Dealer 310510-28 T4-5-6... -
Page 21: T4 Replacement Parts
T4 Replacement Parts #1 BAFFLE KIT ................VIST.BAFKIT #2 BRICK RAILS (2) ..............VIST.RAILSET #3 FLAME SHIELD ................VIST.2115 #4 DOOR ASSEMBLY LEFT ..........ALT4.4900LMBK ........RIGHT ..........ALT4.4900RMBK #5 FIREBRICK SET ................BRIC.VISTA #6 SIDE CASTING MBK (2) ............ALT4.4905MBK #7 TOP GRILL ASSEMBLY (3) .......... ALT4.TGASSYMBK #8 ASH DUMP ASSEMBLY ............ -
Page 22: T5 Replacement Parts
5b ...FIREBRICK - 4” x 4 1/2” x 1 1/4” (1) 22 ...DOOR STOP 5c ..FIREBRICK - 7 1/4” x 4 1/2” x 1 1/4” (1) #9 LEG CASTING (4) 5d ...FIREBRICK - 9” x 4 1/2” x 1 1/4” (16) 310510-28 T4-5-6... -
Page 23: T6 Replacement Parts
5b ...FIREBRICK - 4” x 4 1/2” x 1 1/4” (1) 22 ...DOOR STOP 5c ..FIREBRICK - 7 1/4” x 4 1/2” x 1 1/4” (1) #9 LEG CASTING (4) 5d ...FIREBRICK - 9” x 4 1/2” x 1 1/4” (16) 310510-28 T4-5-6... -
Page 24: Firebrick Installation Instructions
T4 Firebrick Installation Instructions This package contains 12 full-size fi rebricks, as well as 2 various cut bricks. If your heater came with an ash cleanout system, or an optional one is being installed, exclude one full-size brick. With the heater in the upright position, install fi rebricks as follows: Install 4 full-size fi rebricks against the rear wall. -
Page 25: Label T4
Label T4 CERTIFIED FOR CANADA AND U.S.A. DO NOT REMOVE THIS LABEL LISTED ROOM HEATER, SOLID FUEL TYPE. ALSO FOR USE IN MOBILE HOMES PACIFIC VISTA TESTED TO CAN/ULC S627-M93 AND UL 1482-98 VISTA CLASSIC WN# 16405 SERIES: MODEL: ALDERLEA T4 •... -
Page 26: Label T5
BURNS. SEE NAMEPLATE AND INSTRUCTIONS. U.S. ENVIRONMENTAL PROTECTION AGENCY DATE OF MANUFACTURE A S O N D CERTIFIED TO COMPLY WITH JULY, 1990, PARTICULATE EMISSION 2009 2010 2011 2012 2013 2014 STANDARDS MADE IN CANADA 250509 5050.75 SUP1-A2 310510-28 T4-5-6... -
Page 27: Label T6
BURNS. SEE NAMEPLATE AND INSTRUCTIONS. DATE OF MANUFACTURE A S O N D U.S. ENVIRONMENTAL PROTECTION AGENCY 2009 2010 2011 2012 2013 2014 CERTIFIED TO COMPLY WITH JULY, 1990, PARTICULATE MADE IN CANADA EMISSION STANDARDS 190509 5050.76 SUMM-A1 310510-28 T4-5-6... - Page 28 By Pacifi c Energy PACIFIC ENERGY FIREPLACE PRODUCTS LTD. Phone: 1-250-748-1184 Web site: www.pacifi cenergy.net 2975 Allenby Rd., Duncan, BC V9L 6V8 PRINTED IN CANADA 310510-28 T4-5-6...
