Parasound Zamp Quattro Brochure & Specs

Zamp Quattro
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
360 Watt RMS Dual Zone Half Rack Space Power Amplifier
The Zamp Quattro is an ultra-compact class D amplifier that produces an impressive 50 watts x 4
90 watts x 4 4 with all channels driven. Class D amplifiers made for custom installation typically use
( Ω)
inexpensive car audio amp chips - and they sound like it. The Zamp Quattro uses a class AB input stage to
drive advanced Class D modules which use high-grade parts throughout. The result is sound
surpasses many full-size power amps
power output with less heat, unconditional stability with low impedance speaker loads and effective
protection from accidentally short-circuited speaker wires.
The Zamp Quattro can expand any audio system because we've included speaker level inputs to integrate
stereo receivers that don't have preamp outputs. An input bus switch makes it easy for Zone 1 and Zone
2 to play the same source. Level controls for each channel make volume setup easy and are rear-
mounted to prevent client tampering. The speaker terminals accept up to 12AWG wire and are
removable to make installation easier. Automatic turn on options include a 12-volt input and an audio
trigger with two sensitivity settings.
The Parasound Zamp Quattro is finished in anodized black with rack-mount capability. Optional
accessories include a matching blank panel to rack mount a single unit in a standard rack and a panel
coupler to rack mount any two Z Custom models. The half-rack width Zrack is also available to mount up
to five Z-Custom components.
Combine with 1 or 2 Sonos® Connects® to power multiple zones
Integrate with older or low-priced stereo receivers without pre-outs
Rack mount four Zamp Quattros for 16 channels in 2 rack spaces
Four Channel Amplifier
. The Zamp Quattro's numerous advantages include higher

Typical Zamp Quattro Applications

Power multiple zones from an AV receiver
Expand zones from any multi-room audio controller
8 and
( Ω)
quality that
