Summary of Contents for oset SPIDER 12.5
- Page 1 OWNERS MANUAL OSET SPIDER 12.5 OSET SPIDER 16.0 OSET CORP 146 W. Irvington Place, Denver, CO 80223. USA. 303 990-2390. http://www.OSETBIKES.com info@OSETBIKES.com (See distributor details on the back cover)
-
Page 2: Introduction
Your OSET has great capabilities, and can grow with the skills of the rider to very high levels, but it is IMPERITIVE that the responsible adult controls the entire learning process and gives full attention at all times. -
Page 3: Please Read
See distributor contact information on the back cover of this manual. OFF ROAD USE ONLY! OSET Mini Bikes are designed for off road use only and must not be used on public roads or sidewalks. Please check and obey all local laws. -
Page 4: Warnings, Cautions And Notes
Please read, understand and follow all Warning, Caution and Note notices on your OSET electric bike and those included in this Manual. If you do not understand any of this important information, please contact your selling dealer/distributor or the OSET Customer... - Page 5 WARNING: OFFROAD USE ONLY. It is illegal and hazardous to use this vehicle on streets and thoroughfares. Use on streets exposes the rider to hazards from motorists and other vehicles. Use on streets can lead to accidents resulting in death or serious injury, and property damage.
- Page 6 If you have any questions about the proper care and maintenance of this vehicle, consult your selling dealer/distributor or call OSET Customer Service on the number listed on the back cover of this manual. Before each ride, make sure that all bolts and nuts are fastened securely and that the tires are properly inflated.
- Page 7 Exceeding the weight limitations will adversely affect the handling of the machine, and potentially cause damage. • It’s the law; obey it: Obey all laws. OSET’s are for OFF-ROAD USE ONLY. OSET bikes can not be used on public roads or sidewalks. The purchaser, owner, and/or riders of this machine are directly responsible to know and obey all local, state, and federal laws regarding the riding and use of this machine.
- Page 8 PLEASE call OSET Customer Service. WARNING! OSET Mini Bikes are designed to operate at 24 volts only. Use of any battery voltage higher than 24 volts will result in motor failure. OSET CORP considers such modifications and/or changes to its products to be a...
-
Page 9: Table Of Contents
Introduction: Page 2 Please Read!: Page 3 Warnings, Cautions and Notes: Page 4 Contents: Page 9 Specifications – OSET Spider 12.5: Page 10 Specifications – OSET Spider 16.0: Page 11 Component Chart: Page 12 Unpacking and Assembly: Page 13 COMPONENT DETAILS:... -
Page 10: Specifications - Oset Spider 12.5
SPECIFICATIONS – OSET SPIDER 12.5 Performance: - Maximum Speed - 12-14mph - Maximum Range - 8 miles - Weight Limit (Rider) - 50 lbs NOTE! Many factors affect speed and range capabilities. Terrain, average speed, rider weight, tire pressures, wind, hills etc all have an impact. -
Page 11: Specifications - Oset Spider 16.0
SPECIFICATIONS – OSET SPIDER 16.0 Performance: - Maximum Speed - 15-17mph - Maximum Range - 8 miles - Weight Limit (Rider) - 85 lbs NOTE! Many factors affect speed and range capabilities. Terrain, average speed, rider weight, tire pressures, wind, hills etc all have an impact. -
Page 12: Component Chart
Riders should wear boots without laces, and not have any loose clothing that could be caught by the chain. The Spider 16.0 features a front disc brake, as opposed to the ‘V’ Brake on the Spider 12.5. -
Page 13: Unpacking And Assembly
NOTE! If you purchased your OSET at a local retailer your machine may be fully adjusted and ready to ride. If you purchased your OSET in the carton, please carefully follow the instructions below and any supplemental instructions to finish the assembly and adjustment of your OSET. -
Page 14: Switch Plate
SWITCH PLATE: The ‘switch plate’ is under the seat area and is the location for several important items, as follows: Please Note: All pictures are of pre-production Key Switch: prototypes, so could differ from the final The key switch turns the power on production machines. -
Page 15: Charge Indicator
WARNING! If power is turned on while the throttle is open, the bike will accelerate immediately. This is potentially very dangerous. The rider’s right hand should be used to switch the power on, with no hands on the throttle. WARNING! It is very important to keep everyone clear of the bike when changing and checking the speed setting. -
Page 16: Drive Train
DRIVE TRAIN: Your OSET features a traditional chain and sprockets, covered by a plastic chain-guard. It is direct drive, with no gears. With the motor mounted in the swingarm, suspension movement has no effect on tension. However, the chain does need to be checked and adjusted regularly, especially when the bike is new. -
Page 17: Motor Performance
The front suspension is of the telescopic variety, and is non-adjustable. Rear Suspension: Your OSET is equipped with a single coil spring type rear shock. For a harder/stiffer ride at the rear tighten the adjustment ring in a clockwise direction. -
Page 18: Cleaning
Check the tires for proper inflation. Also, inspect the tires for damage. CLEANING: Cleaning and maintaining your OSET correctly will provide a more enjoyable ownership and riding experience. By hand cleaning the bike, you can simultaneously inspect all of the components. We recommend cleaning be done with a damp cloth. -
Page 19: Rear Wheel Removal/Installation
REAR WHEEL REMOVAL AND INSTALLATION: 1. Ensure power is switched off. 2. Lift the bike onto a block or stand so the wheels are off the ground. 3. Remove the chain-guard by removing the 4 bolts securing it. 4. Release the band brake cable by undoing the cable pinch bolt (a). -
Page 20: Front Brake Adjustment - Oset 12.5
WARNING! OSET brakes are adjustable. Beginning riders should have the front brake ‘backed off’ somewhat so it does not bite too suddenly. As the rider gets better, the brake can be tightened up for a quicker action. -
Page 21: Battery Use, Care And Maintenance
If you have any questions about this battery or its usage, please do not hesitate to contact the OSET Customer Service Department. WARNING! Never short circuit the discharge terminals of the battery. A short circuit will damage the battery and could cause a fire resulting in severe injury or death, and property damage. -
Page 22: Charging Instructions
CHARGING INSTRUCTIONS: • Ensure that the Power Switch on your OSET is switched OFF before connecting the charger to the charge port. • Carefully align the connector pins and connect the charger to the bike by plugging the connector into the charger receptacle. -
Page 23: Important Notes About Charging
• It normally takes four to six hours to fully charge your batteries from a fully discharged condition. • Fully charge the batteries for at least twelve hours before using your OSET electric bike for the first time. • Fully charge the batteries for at least twelve hours for the first three charges after using your OSET bike. -
Page 24: Battery Removal And Installation
To Re-Install the batteries and bag, reverse the above procedure. LONG TERM STORAGE: If you do not plan to use your OSET for an extended period of time (1 month or more), remove the batteries from the bike for storage. -
Page 25: Setting Up Your Oset For Riding
NOTE! As the responsible adult, you must ensure that the OSET and its rider are ready to ride, every time. The bike must be set to the abilities of the rider, and you must ALWAYS supervise when, where and how the bike is ridden. Children can lose concentration quickly, and be distracted easily. -
Page 26: Riding Instructions And Safety Tips
RIDING INSTRUCTIONS & SAFETY TIPS (BEGINNERS AND LEARNERS): With the bike set up correctly, your OSET is ready to ride! For learning riders, please use these tips and instructions. The riders will get the most enjoyment if they feel safe and in control. Do not be tempted to start the riders too quickly. -
Page 27: First Ride
When stopped, turn the power off. WARNING! OFF ROAD USE ONLY! OSET Mini Bikes are designed for off road use only and must not be used on public roads or sidewalks. Please check and obey all local laws. -
Page 28: Learning To Stand Up
OSET bikes are designed to be ridden standing up. If the machine is too large for the child, they will have no leverage on the bike, and be unable to develop techniques. -
Page 29: Learning Some Technique
4. LEARNING SOME TECHNIQUE: Learning some correct ‘Trials’ style techniques will put the rider in a great position for all forms of riding that come later. The Trials rider learns how to control the machine at slow speeds, and use correct skills to execute tight turns and other techniques. -
Page 30: Contact Us
This manual should be enough to get you started. Further techniques can not be covered in this manual. When learning any technique the most important thing is to do so slowly and safely. Remember that OSET bikes are a Trials bike design, and therefore designed and developed for slow speed riding. -
Page 31: Limited Warranty
The liability of OSET hereunder is expressly limited to the replacement of goods complying with this warranty or at the sole election of OSET to the repayment of an amount equivalent to the purchase price of the product in question. CAUTION: Some states... - Page 32 UK - OSET Bikes Ltd 3-5 Horndean Road Bracknell Berkshire RG12 0XQ Tel. 07913 576425 http://www.osetuk.com info@osetuk.com AUSTRALIA OSET Bikes Australia Pty Ltd PO Box 3223 South Brisbane Quensland 4153 Australia. Tel. (07) 3846 3339 Mobile. 0403 260 779 http://www.osetbikes.com.au service@osetbikes.com.au...
