INSTRUCTION
manual
for
A V A L O N
PPP - MONO POWER AMPLIFIER
_____________________________________
This handcrafted product was special made for your high demands,
to display the music on ist finest way.
We guarantee,that this amplifier was carefully produced
and tested in all details.
_____________________________________________________________________
Advertisement
Table of Contents
Related Manuals for Audio Valve Avalon
Summary of Contents for Audio Valve Avalon
- Page 1 INSTRUCTION manual A V A L O N PPP - MONO POWER AMPLIFIER _____________________________________ This handcrafted product was special made for your high demands, to display the music on ist finest way. We guarantee,that this amplifier was carefully produced and tested in all details. _____________________________________________________________________...
- Page 2 This hand build instrument should give a lifetime of pleasure and with a little care and a full understanding of the operation recommendation in this manual the AVALON should provide trouble free performance. Please take time to read this manual thoroughly before using your amplifier.
- Page 3 WARNING This amplifier AVALON operates in class - A and is therefore capable of generating a moderately high temperatue which requires carefull placing to aviod any effect this heat may have on other equipment, funiture and fittings etc. Do not remove the top cover from this amplifier.
-
Page 4: Rear Panel
STAND BY of the amplifier. Switch down is operation STAND BY , ( the LED is off). REAR PANEL The facilities on the rear panel of the AVALON may seem not so complex. The rear panel incorporates all of the terminals for connecting the input signals and the output signals to the loadspeaker. - Page 5 INPUT TERMINALS Input terminals for this AVALON power amplifier are easily accsessible and fitted to the lower centre area of the rear panel. RCA INPUT. These standart type of RCA terminals are for use with unbalanced signals from most signal sources such as audio preamplifiers.
- Page 6 Speaker Mainplug 8 ohm 4 ohm Fuse...
-
Page 7: Installation And Operation
CHECK that the mains voltage printed on the rear of this amplifier is similar to the mains voltage normaly supplied to your area. If indoupt, please consult your AUDIO VALVE dealer. PLACEMENT AND VENTILATION This Audio Valve AVALON power amplifier is designed to operate at a moderately high temperature. - Page 8 HALF AUTOMATIC BIAS CONTROL FUNCTION Each power tube is controlled by plate current. The correct function of the power tubes is shown by 1 LEDs, next to each power tube. When the amplifier is operating, no LED is shinning. In case that any of the power tubes is faulty the LED, which are together at the side of the power tubes , immidiatly indicated.
- Page 9 AVALON - SPECIFICATIONS: prinzip: Parallel-push-pull power amp tubes: 1*12AU7, 1*12AX7, 8*beam power pentode for example: EL 84 operate: class - A power output: 60 Watt power consumption: 160 Watt - Stand by mode - 30 Watt max. short circuit 15 ampere between 2 ohm terminals current: input sen.
- Page 10 90-day period on the tubes from the purchase date. In the event of a failure of your amplifier , AUDIO VALVE will repair or readjust this unit or , should the occasion arise , will replace it provided that all conditions stipulated in this warranty are met.
-
Page 11: Warranty Registration
WARRANTY REGISTRATION Please fill out and return this warranty form to the US distributor within 15 days of the purchase date. MODEL : _______________________________________________ • SERIAL NUMBER : _______________________________________ • PURCHASE DATE : ______________________________________ • AUTHORIZED AUDIO - VALVE DEALER: •... - Page 12 8 pcs. EL 84 12AU7 12AX7 Rf - bandwide Driver stage Input stage Input sensitivity Pc - board top side...
