Summary of Contents for Abode ADHSC3001 Pro+
- Page 1 pro+ Handheld Steam Cleaner User Guide Model No: ADHSC3001 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
……………………………………… Connection to the mains supply ……………………………………… Thank you for purchasing your Abode pro+ Handheld Steam Cleaner. Multi-purpose steam cleaning has never been so easy with your new Abode pro+ Handheld Steam Cleaner. With an impressive number of functions and attachments, steam clean your bathroom, windows, mirrors, upholstery and more. -
Page 3: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS, READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. - Page 4 Safety instructions • Do not direct steam at people, animals, electrical outlets, or equipment containing electrical components. • Unplug from outlet when not in use. Do not leave the steam cleaner unattended while plugged in. • Do not use with damaged cord or plug. •...
- Page 5 Safety instructions • Never remove parts from the appliance, such as the screws. • The filling aperture must not be opened during use. • Do not use appliance in an enclosed space filled with vapour given off by oil-based paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapours.
-
Page 6: Steam Cleaner Feature Diagram
Steam cleaner feature diagram Nozzle Handheld steam cleaner Safety cap Window cleaning attachment/upholstery & Safety pressure indicator (red pin) Steam trigger garment steaming tool Cloth Detergent solution control dial Handle grip Straight nozzle Water tank Round brush (nylon) Power and Steam ready indicator Round brush (metal) light (Red indicates power on and G. -
Page 7: Unpacking Your Steam Cleaner
Unpacking your steam cleaner Before using your steam cleaner Remove all packaging and lay out the separate components. Check the steam unit after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... -
Page 8: Using Your Steam Cleaner
Using: Filling the water tank Always unplug the unit before removing the safety cap. Place the steam cleaner on a level surface. Turn the safety cap anti-clockwise and remove Add 250ml of cold tap water to the filler cup. Empty the filler cup carefully into the water tank. - Page 9 Using: Filling the water tank Refit the safety cap, twisting it clockwise and tightening. Re-filling the water tank Unplug and allow the unit to cool. After approximately 5 minutes, when the unit has cooled sufficiently, the red pin on the safety cap will release to allow for removal.
- Page 10 Note: Ensure to use the recommended Abode detergent. Mixing detergents may be unsafe. Keep detergent away from children. Do not overfill the tank.
- Page 11 Using your steam cleaner Operating the steam cleaner Before you plug the appliance in, check the water tank is full. If it is not, refer to page 8. Plug the mains plug into a socket. The red power indicator light will illuminate. If the light does not illuminate, refer to page 17 for problem solving.
- Page 12 Using your steam cleaner Using the solution control dial The Solution Control Dial does not adjust the amount of steam, it only controls the amount of cleaning solution that is added to the steam. To clean with steam alone, simply turn the Solution Control Dial to “OFF”. Check the detergent tank is full, if not refer to page 10.
- Page 13 Using your steam cleaner Attaching the main tools The two main accessories for this product are the extension hose and concentration nozzle. They both attach to the unit in the same manner. 75cm flexible hose: For cleaning hard to reach areas. Attach to unit and use with the accessory nozzle attached.
- Page 14 Using: accessories Attaching the small tools NOTE: Nozzle extension must be attached before fitting small tools. If the cleaning effect of the steam alone is not acting as required for a specific task, there are many small tools included that may help. All tools attach to the nozzle extension, simply: •...
-
Page 15: Storing Your Steam Cleaner
Storing your steam cleaner When you have finished cleaning, switch the power off at the plug socket and remove the plug. Note: Do not leave any detergent or water in any tank after operation. Allow the device to cool before removing attachments. -
Page 16: Cleaning And Care
Cleaning and Care Before you clean the appliance, disconnect the mains plug from the wall socket. To clean the exterior of the device, use a damp, soft cloth and mild detergent. NEVER IMMERSE THE STEAM UNIT IN WATER. When wiping off the main body, do not allow moisture in the area around the indicator light. -
Page 17: Problem Solving
Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. Trouble assembling 1. There are a number of attachments that can be used attachments with this steam cleaner. For information on attaching the main tools, such as the flexible hose and the straight nozzle, refer to page 13 of the instruction manual provided. - Page 18 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. The cleaner has not 1. Once the water thank is filled, switch the cleaner on at had time to heat. the plug. This should illuminate the power indicator light red. Ensure you have waited 4 minutes for the water to heat up.
- Page 19 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. The water has not had 1. Wait 4 minutes or until the indicator light illuminates time to heat. green. Steam cleaner is emitting water 2. Too much water is in 2. Empty the water from tank and refill with up to 250ml the tank of water.
- Page 20 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION Parts have 1. An attachment has 1. Page 23 of the instruction manual provides details of broken/need broken or been lost. which attachments can be replaced. Call customer services replacing or visit the website detailed at the bottom of this page. 2.
-
Page 21: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 22: Customer Services
Customer services Attach your receipt to this page for proof of purchase. We’re here should you need us. For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com Produced for: G2S Limited... -
Page 23: Spare Parts
Spare parts The following spare parts are available to purchase online or by calling Product Care. Visit us at www.productcareuk.com Or call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Safety cap Straight nozzle Window cleaner/upholstery... -
Page 24: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V - 240V ~ 50/60HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. - Page 25 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or...
- Page 26 Model number: ADHSC3001...
