- Page 1 Steam Cleaner User guide Model No: ASC3001 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Thank you for purchasing your Abode pro Steam Cleaner. Multi-purpose steam cleaning has never been so easy with your new Abode pro Steam Cleaner. With an impressive number of functions and attachments, steam clean your bathroom, windows, mirrors, upholstery and more. -
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Safety instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. -
Page 4: Safety Instructions
Safety instructions • Do not direct steam at people, animals, electrical outlets, or equipment containing electrical components. • Unplug from power outlet when not in use. Do not leave steam unit unattended while plugged in. • Do not use with damaged cord or plug. •... - Page 5 Safety instructions • The filling aperture must not be opened during use. • Do not use appliance in an enclosed space filled with vapor given off by oil-based paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors.
-
Page 6: Steam Cleaner Feature Diagram
Steam cleaner feature diagram Red indicator light: power on Steam gun Green indicator light: ready to use Safety lock On/Off button Steam trigger Carry handle Floor cloth Safety cap Floor brush Floor brush slot Small cloth Elbow attachment Funnel Steam hose Measuring jug 3x Extension tubes... - Page 7 Steam cleaner feature diagram Steam cleaner Large round brush (nylon) Attachment base with wheels Round brush (metal) Base lever Scraping tool Window Cleaning/Garment tool Angled nozzle Jet nozzle adaptor Round brush (nylon)
-
Page 8: Unpacking Your Steam Cleaner
Unpacking your steam cleaner Before using your steam cleaner Remove all packaging and lay out the separate components. Check the steam unit after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... -
Page 9: Using Your Steam Cleaner
Using: Filling the water tank Always unplug the unit before removing the safety cap. Place the steam cleaner on a level surface. Turn the safety cap anti-clockwise and remove Fill the measuring jug with 750ml of cold tap water. Using the funnel, empty the measuring jug carefully into the water tank. - Page 10 Using: Filling the water tank Refit the safety cap, twisting it clockwise and tightening. Re-filling the water tank After approximately 5 minutes, when the unit has cooled sufficiently, the red pin on the safety cap will release to allow for removal. This is a pressure release valve.
- Page 11 Using your steam cleaner Operating the steam cleaner Before you plug the appliance in, check the water tank is full. If it is not, refer to page 9. Plug the mains plug into a socket and turn the cleaner on by pressing the on/off button. The red power indicator light will illuminate.
-
Page 12: Steam Hose
Using your steam cleaner Steam hose Before turning the cleaner on, place the hose into the steam socket. To place the steam hose and handle into the main steam cleaner: • Open the steam socket, • Press the hose in firmly until it clicks in place. •... - Page 13 Using: accessories Attaching the main tools The two main accessories for this product are the jet nozzle adaptor and the elbow attachment. They both attach to the steam gun in the same manner. NOTE: The elbow nozzle comes pre-assembled with the floor brush attached. Jet nozzle adaptor Attach this tool to the steam gun to give concentrated, direct steam.
- Page 14 Using: accessories Elbow attachment To connect or remove the elbow attachment, twist the elbow joint so that is faces downwards (the triangle lip should be exposed above the floor brush – diagram A.) Remove or fit the elbow attachment. When fitting, turn 180° till the elbow attachment represents diagram B.
- Page 15 Using: accessories Attaching the small tools NOTE: The jet nozzle adaptor must be attached before fitting small tools. If the cleaning effect of the steam alone is not acting as required for a specific task, the following small tools may help. All tools attach to the jet nozzle adaptor, simply: •...
-
Page 16: Storing Your Steam Cleaner
Storing your steam cleaner When you have finished cleaning, turn the steam cleaner off by pressing the OFF button. Turn the power off at the plug socket and remove the plug. Allow the device to cool before removing attachments. After approximately 5 minutes, when the unit has cooled sufficiently, the red pin on the safety cap will release to allow for removal - this is a pressure release valve. -
Page 17: Cleaning And Care
Cleaning and Care Before you clean the appliance, disconnect the mains plug from the wall socket. To clean the exterior of the device, use a damp, soft cloth and mild detergent. NEVER IMMERSE THE STEAM UNIT IN WATER. When wiping off the main body, do not allow moisture in the area around the indicator light. -
Page 18: Problem Solving
Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. Trouble assembling 1. There are a number of attachments that can be used attachments. with this steam cleaner. The steam gun clips in to the steam socket on the side of the cleaner. To detach the base, push the lever on the side of the base and lift the cleaner using the handle. - Page 19 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. The power button has 1. Press the power button located on the carry handle to not been pressed/The illuminate the indicator light. Ensure you have waited 5 cleaner has not had time minutes for the water to heat up sufficiently before trying to heat.
- Page 20 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. What do the indicator 1. With the steam knob facing you, the light on the left lights mean? illuminates red when there is power to the steam cleaner. Indicator lights This means the water is heating. After around 5 minutes when the water has heated, the light on the right will illuminate green to show that the cleaner is steam ready.
-
Page 21: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 22: Customer Services
Customer services Attach your receipt to this page for proof of purchase. We’re here should you need us. For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com Produced for: G2S Limited... -
Page 23: Spare Parts
Spare parts Safety cap Jet nozzle adaptor Window cleaner/upholstery attachment Garment steamer cloth Round brush (nylon) Round brush (metal) Large round brush Scraping tool Angled nozzle (nylon) Measuring jug Funnel Extension tubes Elbow attachment Floor brush/Floor cloth Steam gun... -
Page 24: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V - 240V ~ 50/60HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. - Page 25 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or...
- Page 26 Model number: ASC3001...
