- Page 1 2 in 1 Steam Cleaner User Guide Model No: A21SM3001 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Thank you for purchasing your Abode pro Steam Cleaner. Multi-purpose steam cleaning has never been so easy with your new Abode pro 2 in 1 Steam Mop. With an impressive number of functions and attachments, steam clean your bathroom, windows, mirrors, upholstery and more. -
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Safety instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. -
Page 4: Safety Instructions
Safety instructions • Do not direct steam at people, animals, electrical outlets, or equipment containing electrical components. • Unplug from power outlet when not in use. Do not leave steam unit unattended while plugged in. • Do not use with damaged cord or plug. •... - Page 5 Safety instructions • The filling aperture must not be opened during use. • Do not use appliance in an enclosed space filled with vapor given off by oil-based paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors.
-
Page 6: Steam Cleaner Feature Diagram
Steam cleaner feature diagram Steam nozzle Extension pole Jet nozzle adaptor Water tank & cap Mop head Attachments Power indicator Microfibre mop Crevice brush light pad (x2) Steam dial Round Brush Steam button (nylon) Tube Release Small cloth Carpet glider button Lower cord hook Squeegee... -
Page 7: Unpacking Your Steam Cleaner
Unpacking your steam cleaner Before using your steam cleaner Remove all packaging and lay out the separate components. Check the steam unit after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... -
Page 8: Filling The Water Tank
Filling the water tank Always unplug the unit before removing the safety cap. Always make sure the steam control dial is set to “OFF” before removing the water tank cap. Place the steam cleaner on a level surface Twist the water tank cap anti-clockwise and remove. Fill the measuring jug provided with 200ml of cold tap water. - Page 9 Filling the water tank Refit the water tank cap, twisting it clockwise and tightening. Re-filling the water tank At any stage during use, you can refill the water tank. It is advised to turn the steam dial anti-clockwise to the “OFF” position. Read the note below before re-following the filling instructions.
-
Page 10: Assembling Your Steam Cleaner
Assembling your steam cleaner Attaching steam mop tools The main accessories required for the steam mop function include the extension pole and the steam mop head. Accessories that can be used with the steam mop include: the cotton cloth, steam glider and the mop pad. Refer to the accessories section on pages 11-17 for assembly and usage instructions regarding each specific part. - Page 11 Assembling your steam cleaner Attaching steam cleaner tools The mop head is suitable for cleaning large washable floor and wall areas. It can be used with or without the microfibre pad. Clean sensitive surfaces, i.e. wood (sealed), laminate (sealed) etc. with the pad attached.
- Page 12 Assembling your steam cleaner Attaching steam cleaner tools The two main accessories for this product are the jet nozzle adaptor and the utility head attachment. They attach to the steam unit in the same manner. NOTE: The utility head comes pre-assembled with the small cloth and squeegee attached.
- Page 13 Turn over the small cloth and utility head assembly, and locate the squeegee squeegee Hook the squeegee on to the assembly ‘over’ the cloth, and push down until it ‘clicks’ in to position. The squeegee is now assembled and ready to use. The squeegee is ideal for cleaning windows, mirrors, tiles and other smooth surfaces.
- Page 14 Assembling your steam cleaner Attaching small tools to the jet nozzle If the cleaning effect of steam alone is not ideal for your specific task, there are 2 small tools included to support cleaning: the round brush and the crevice brush. These tools are ideal for cleaning hard to reach areas.
-
Page 15: Using Your Steam Cleaner
Using your steam cleaner Operating the steam cleaner Before you plug the appliance in, check the water tank is full. If it is not, refer to page 8. Plug the mains plug into a socket and switch the cleaner on by turning the steam dial clockwise between MIN/MAX. - Page 16 Using your steam cleaner Steam mopping Before using the steam unit as a mop, attach the following parts: • The extension pole in the top of the main unit (fig 1, page 10.) • Place the microfibre pad over the steam mop head (fig 3, page 11.) •...
- Page 17 Using your steam cleaner Selecting steam settings Below is a general list of just some of the possible uses for the multi-purpose steamer, divided into recommended steam intensity settings. These are only a guideline for using your steamer, you will likely discover a wide variety of other uses around you home.
-
Page 18: Cleaning And Care
Cleaning and Care Before you clean the appliance, disconnect the mains plug from the wall socket. To clean the exterior of the device, use a damp, soft cloth and mild detergent. NEVER IMMERSE THE STEAM UNIT IN WATER. When wiping off the main body, do not allow moisture in the area around the indicator light or steam dial. -
Page 19: Problem Solving
Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. Trouble assembling 1. There are a number of attachments that can be used attachments with this steam cleaner. All attachments attach to the connector in the main body in the same manner. The black clip of the attachments should protrude through the hole in the connector to be secure. - Page 20 1. The steam dial has not 1. Turn the steam dial located on the main body above the been turned/The cleaner Abode logo clockwise, from ‘OFF’ to the desired setting. has not had time to heat. This should illuminate the power indicator light red.
- Page 21 Problem Solving PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION 1. What does the 1. The power indicator light on the main body of the indicator light mean steam unit illuminates red to show that the unit is plugged Indicator light in and the steam dial is turned past the ‘ON’ position. This means that the water is heating and the unit will stay on.
-
Page 22: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 23: Customer Services
Customer services Attach your receipt to this page for proof of purchase. We’re here should you need us. For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com Produced for: G2S Limited... -
Page 24: Spare Parts
Spare parts The following spare parts are available to purchase online or by calling Product Care. Visit us at www.productcareuk.com Or call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Carpet glider Jet nozzle adaptor Utility head and squeegee... -
Page 25: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V - 240V ~ 50/60HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. - Page 26 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or...
- Page 27 Model number: A21SM3001...
