Installation and User Guide for Baseline Cell Modems in Pedestal Enclosures

Introduction

In order to remotely connect with your BaseStation 1000 or 3200 irrigation controller and take
advantage of BaseManager, the controller must be able to communicate over the Internet. Using a
cell modem is one option for wireless Internet communication. The cell modem sends and receives
data over a wireless carrier's network.
When you choose a cell modem communication package from Baseline, we provide the cell
modem hardware, the antenna, the SIM card from the wireless carrier, the firmware that activates
the connection from your controller, and a 1-year subscription to a data plan with the wireless
carrier.
When the controller and cell modem are ordered together, the cell modem is already installed in
the enclosure, but when the cell modem is ordered after the controller is in service, you will need
to complete the installation.
To install and establish communication through your cell modem, you need to perform the
following tasks:
Step 1 – Assemble the antenna riser.
Step 2 – Prepare the mounting location for the antenna riser.
Step 3 – Attach the antenna riser to the pedestal.
Step 4 – Install the cell modem hardware in your BaseStation 1000 or 3200 pedestal.
Step 5 – Check the firmware version on your controller and install an update if necessary.
Step 6 – Activate your SIM card with Baseline.
Step 7 – Verify the cell modem connection in the controller.

Gather the following tools and materials

•
Philips head screwdriver
•
Set of wrenches
•
Hobby knife with a fine point and sharp blade
•
Cell modem module with power cable and screws
•
Antenna and antenna cable with connectors
•
Ethernet cable
