PERFORMER
Owner's Guide
READ THE INSTRUCTIONS BEFORE
USING THE APPLIANCE
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid
4. If odour continues, keep away from the
appliance and immediately call your gas
supplier or your fi re service.
Leaking gas may cause a fi re or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use petrol or other
fl ammable vapours and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected for
use should not be stored in the vicinity
of this or any other appliance.
®
#78762
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
WARNING: Do not try to light the Weber
gas barbecue without fi rst reading the
"Lighting" instructions in this manual.
INFORMATION FOR THE INSTALLER:
This manual must remain with the owner,
who should keep it for future use.
ONLY TO BE USED OUTDOORS.
®
78762 GB 090905
Advertisement
Table of Contents
Related Manuals for Weber Performer 78762
Summary of Contents for Weber Performer 78762
- Page 1 DANGER If you smell gas: ® WARNING: Do not try to light the Weber 1. Shut off gas to the appliance. gas barbecue without fi rst reading the 2. Extinguish any open fl ames. “Lighting” instructions in this manual.
-
Page 2: Dangers And Warnings
DANGERS AND WARNINGS DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fi re or an explosion causing damage to property. WARNINGS Follow regulator connection instructions for your type of gas grill. Do not store a spare or disconnected LP disposable cartridge under or near this barbecue. -
Page 3: Warranty
Butane mix www.weber.com ® ©2005 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria; Kettle Silhouette , Smokey Joe, Weber, Benelux;... -
Page 4: General Instructions
WARNING: Accessible parts may be very hot. Keep young children away. Never operate the barbecue under any overhead combustible construction. Your Weber ® Barbecue is not intended to be installed in or on recreational vehicles and/or boats. Do not use combustible materials within 60cm of the top, bottom, back or sides of the grill. -
Page 5: Exploded View
EXPLODED VIEW Performer TNG 070104... -
Page 6: Exploded View List
Gas Control Cover This will also void your warranty. #8-18 x 5/8 Inch Screw GENERAL INSTRUCTIONS If you have questions or need advice regarding your grill or its safe operation, please log onto www.weber.com ® ® • These instructions will give you the minimum requirements for assembling your Weber barbecue. -
Page 7: Parts List
PARTS LIST TOOLS NEEDED: 1 ......... Phillips Screwdriver 11mm / 7 / 16 ˝ inch or an adjustable wrench Pliers 1 ......... Hammer 2 ......Block of Wood 1 ........... 1/4 x 20 1 1 / 4 ˝ Pan Head Bolt - 16 2 .............. - Page 8 ASSEMBLY (4 - (4 -...
- Page 9 ASSEMBLY (2 -...
- Page 10 ASSEMBLY (4 - (4 -...
- Page 11 ASSEMBLY DANGER Do not use the gas ignition feature if the retaining clip(1) locking the gas orifi ce(2) into the burner tube is missing. A missing retaining clip can cause serious bodily injury or death, and damage to property. Pull regulator hose to test orifi ce to burner tube connection.
- Page 12 ASSEMBLY (4 - 33 lbs. Max. (15Kg ) Maximum 30 lbs. / 13.7 kg. bag of charcoal. Bag of charcoal should be placed directly in CharBin ™ Storage Container. 30lb bag Charcoal Charcoal 30lb / 13.7kg...
- Page 13 If a leak persists after retightening the LP cartridge, turn OFF the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber. ® Check: Valve to-regulator connections.
- Page 14 OPERATING LIGHTING DANGER Open lid before lighting. Do not use any fl ammable liq- uids such as starting fl uid, petrol, alcohol or any form of self-lighting charcoal at any time, including when manually lighting. Failure to do so will cause serious bodily injury or death.
-
Page 15: Manual Lighting
OPERATING MANUAL LIGHTING WARNING: Do not attempt to light manually without using the match holder. DANGER Open lid before lighting. Do not use any fl ammable liq- uids such as starting fl uid, petrol, alcohol or any form of self-lighting charcoal at any time, including when manually lighting. - Page 16 If this happens, wear BBQ mitts and use long- handled tongs to move the charcoal from one side to the other so the heat is evenly distributed. For additional information and cooking times, consult the Weber ® Owner’s Guide.
-
Page 17: Troubleshooting
fl aking off. THIS IS NOT A DEFECT. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in ® your area using the contact information on our web site. Log onto www.weber.com... -
Page 18: Maintenance
® authorized replacement parts. Contact the Customer Service Representative in your area using the con- tact information on our web site. Log onto www.weber.com ® CAUTION: If the barbecue gas hose is damaged in any way or leaking, do not use the barbecue. - Page 19 MAINTENANCE INSECT ALERT Your Performer Grill, as well as any outdoor gas appliance, is a target for spiders and insects. They can nest in the venturi section (1) of the burner tube causing gas to fl ow back out of the air shutter. This could result in a fi...
-
Page 20: Ignition System
MAINTENANCE PERIODIC QUICK CLEANING We recommend that you periodically brush the outside of the burner slots with a brass wire brush and clean the burner tube through the combustion air vent with the tool we have provided. This can be done by locating the burner combustion air vent (1) underneath the bowl bracket and inserting the tool through each combustion air vent, rotating the tool.
