KIRK Repeater - Appearance and Components

Table 1-1 KIRK Repeater - Wall - Part Number
Variants of KIRK Repeaters
KIRK Repeater with external antenna 1.8 GHz,
2 channels
(Supported on KWS300, KWS500, KWS600,
KWS600v3 single and multi cell, KWS1500, KWS3000
and KWS6000).
KIRK Repeater with external antenna 1.8 GHz,
4 channels
(Supported on KWS300, KWS500, KWS600,
KWS600v3 single and multi cell, KWS1500, KWS3000
and KWS6000).
KIRK Repeater with external antenna 1.9 GHz,
4 channels
(Supported on KWS300, KWS500, KWS600,
KWS600v3 single and multi cell, KWS1500, KWS3000
and KWS6000).
The repeater connection panel includes the following:
• Power supply connection (connection for programming the repeater as
well).
Note: The power supply for the repeater is to be ordered separately (Part
no. UK version: 84642421, Part no. EU version: 84642420, Part no. US
version: 84642432).
• Antenna connector for repeaters supplied with external antenna
connection.
Note: The external antenna incl. antenna cable is to be ordered separately
(part no. 02319505).
• LED that indicates whether or not the unit is functioning.
Installing KIRK Repeater
Part Number
0244 0000
0244 1600
0244 0200
1–3
